Sharp VH3 Mill - Specification

1-3 Specification
Table
Working surface length × width 1,300×300mm
Travel longitudinal × cross × vertical 950×320×470mm
T-slot nominal size × no. × pitch 16mm×3×70mm
Feeds 12 steps
Longitudinal × cross 60 Hz 13~621mm/min
Longitudinal × cross 50 Hz 11~517mm/min
Vertical (60 Hz) 7~361mm/min
Vertical (50 Hz) 6~263mm/min
Rapid
Traverse
Longitudinal × cross 60 Hz 2,960mm/min
Longitudinal × cross 50 Hz 2,467mm/min
Vertical (60 Hz) 1,520 mm/min
Vertical (50 Hz) 1,267 mm/min
Swivel table (left & right) OPTIONAL
Vertical Spindle
Spindle Nose ISO R297 No.40
Spindle Speed 120-3,600rpm
Change of Spindle Speed Infinitely variable
Quill feeds 0.048,0.096,0.192 mm/rev
Quill travel 130 mm
Swiveling angle of head(left & right) 45 deg
Cross travel ram 510mm
Horizontal rotating angle of ram 360 deg
Horizontal Spindle
Spindle nose ISO R297 No.40
Spindle speed 45-1,700 rpm
Distance from center of spindle to overarm 182mm
Distance from center of spindle to table 22-492mm
Motors
For Vertical spindle AC 3.7kW-4P
For Horizontal spindle AC 3.7kW-4P
For table feed and rapid traverse AC2.2kW-4P
Machine Size
Overall height 2,550mm
Floor area 670×1,200mm
New weight(approx) 2,650kgs
Standard accessories
:
Options
:
1.
C
utting flu
id equipment
1 unit
1.
D
igital read out
2.
C
utting arbor and sleeve
1 unit
2.
A
ir power draw bar
3.
A
djustment tools
1 set
4.
Tool box
1 set
5.
C
hip pan
1 pc
6.
D
raw bar
1 pc
7.
L
eveling blocks
4 pcs
8.
L
eveling bolts
4 pcs
