3. PART NAMES AND FUNCTION
For details on the use of each control.
Front view
When the cassette compartment door is open
Zoom lens Microphone
Terminal cover
AUDIO/VIDEO jack DC IN jack
Speaker
PC connection jack
Card slot door
Lens hood
Cassette holder
Shoulder strap loop Lithium battery holder
Cassette compartment door release
Cassette compartment
door
Rear view
Bottom view
Remote sensor
CHARGE indicator
MENU button
Operation buttons
DISPLAY button
LCD monitor screen
RECord START/STOP button
Power Zoom Wide angle/ Telephoto control VOLume control
Shoulder strap loop TAPE/CARD button Hand strap
Power switch (CAMERA/VCR select switch)
Battery compartment door release
Tripod socket
Battery compartment
door
