Sharp VL-AD260U User Manual

97
Ref. No. Part No. ★ Description Code
Ref. No. Part No. ★ Description Code
VL-AD260U
DUNTK3106QA00
VCR UNIT
INTEGRATED CIRCUITS
IC201 VHiCXD2310A-1 CXD2310A, A/D Converter AV
IC203 RH-iX0788TAZZ IX0788TA, DSP BB
IC204 VHiM5412450-1 M5412450, 4.7M Memory BC
IC205 RH-iX0738TAZZ IX0738TA, Electric Zoom AV
Image Stabilizer
IC601 VHiLA7458W/-1 LA7458W, Sig Process AT
IC701 VHiRH5RZ30C-1~ RH5RZ30C, 3V Reg AF
IC702 VHiRN5VD25A-1 RN5VD25A, 2.5V DET AE
IC704 VHiRS5C313/-1 RS5C313, Clock AL
IC705 VHiM24C08W6-1 M24C08W6, E
2
PROM AH
IC706 RH-iX0921TAZZQ IX0921TA, System/Servo BC
Control
IC707 RH-iX0923TAZZ~ IX0923TA, OSD. IC AN
IC708 VHiTA75S01F-1 TA75S01F, Amp AD
IC710 VHiBU4053V/-1 BU4053V AE
IC712 VHiTC7W74U/-1 TC7W74U AD
IC800 VHiMM1323XV-1 MM1323XV, LCD Interface AN
IC900 VHiMB3881++-1 MB3881++, Power Control AT
IC901 VHiBU4051FV-1 BU4051FV, Multiplexer AF
IC902 VHiNJM2904M-1 NJM2904M, Error Amp AE
IC903 VHiTA75S01F-1 TA75S01F, Amp AD
IC1451 VHiTK15440M-1 TK15440M, Driver AF
IC2701 VHiMB88344F-1 MB88344F, D/A Converter AV
IC2901 VHiMM1332GF-1 MM1332GF, Charge Control AH
IC2902 VHiNJU7012F-1 NJU7012F, Over Current AE
Detector
IC3800 VHiNJM2107F-1 NJM2107F, AFC LPF AE
IC3801 VHiLZ9GH17/-1 LZ9GH17, LCD Controler AP
IC5701 RH-iX0922TAZZQ IX0922TA, Card Micon BC
IC5702 VHiSP3220E+-1 Y SP3220E+ AM
IC5703 RH-iX3272CEZZ IX3272CE, 16MBit DRAM AX
TRANSISTORS
Q201 VSKTA2014EY-1~ KTA2014EY AB
Q202 VSKTX101UY+-1~ KTX101UY+ AC
Q206 VSKTA2014EY-1~ KTA2014EY AB
Q207 VSKTA1298Y+-1~ KTA1298Y+ AC
Q208 VSKRC653U++-1~ KRC653U++ AC
Q601 VSKTA1298Y+-1~ KTA1298Y+ AC
Q602 VSKRC404E++-1~ KRC404E++ AB
Q603 VSKTC4075EY-1~ KTC4075EY AB
Q704 VSKTX101UY+-1~ KTX101UY+ AC
Q705 VSHN2C01FU/-1 HN2C01FU AC
Q707 VSKTC801UY+-1~ KTC801UY+ AC
Q708 VSKRA754U++-1~ KRA754U++ AC
Q709 VSKTC801UY+-1~ KTC801UY+ AC
Q710 VSKTA2014EY-1~ KTA2014EY AB
Q711 VSKTA501UY+-1~ KTA501UY+ AC
Q900 VS2SA2010//-1 2SA2010 AD
Q901 VS2SA1362GR-1 2SA1362GR AC
Q902 VSKRC852U++-1~ KRC852U++ AC
Q903 VSKTA1298Y+-1~ KTA1298Y+ AC
Q904 VSHN2A01FU/-1 HN2A01FU AC
Q906 VSKRC404E++-1~ KRC404E++ AB
Q910 VS2SA2010//-1 2SA2010 AD
Q911 VSKTA1298Y+-1~ KTA1298Y+ AC
Q912 VSKTC4075EY-1~ KTC4075EY AB
Q913 VSKTA1298Y+-1~ KTA1298Y+ AC
Q914 VSKTC4075EY-1~ KTC4075EY AB
Q920 VSCPH6702++-1 CPH6702++ AD
Q930 VSCPH3215++-1 CPH3215++ AD
Q941 VS2SB1121T/-1 2SB1121T AC
Q950 VSCPH6702++-1 CPH6702++ AD
Q951 VSCPH6702++-1 CPH6702++ AD
Q960 VS2SA2010//-1 2SA2010 AD
Q961 VSKTC4075EY-1~ KTC4075EY AB
Q970 VSKRX202U++-1~ KRX202U++ AC
Q971 VSKRC404E++-1~ KRC404E++ AB
Q972 VSKTC601UY+-1~ KTC601UY+ AC
Q973 VSKTA2014EY-1~ KTA2014EY AB
Q974 VSKTC4075EY-1~ KTC4075EY AB
10. REPLACEMENT PARTS LIST/
EXPLODED VIEWS
ELECTRICAL PARTS LIST
Parts marked with " å " are important for maintaining the safety of the set.
Be sure to replace these parts with specified ones for maintaining the
safety and performance of the set.
Les pièces marquéss " å " sont importantes pour maintenir la sècurité de
l'appareil. Ne remplacer ces pieces que par des pièces dont le numéro
est spécifié pour maintenir la sécurité et protéger le bon fonctinnement
de l'appareil.
" HOW TO ORDER REPLACEMENT PARTS "
in USA: Contact your nearest SHARP Parts Distributor. For loca-
tion of SHARP Parts Distributor,
Call Toll-free 1-IBE800-SHARP
in CANADA: Contact SHARP Electronics of Canada Limited
Phone (416) 890-2100.
★MARK : SPARE PARTS-DELIVERY SECTION:ALL JAPAN
To have your order filled promptly and correctly, please furnish
the following informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
5. PRICE CODE
å MARK: SAFETY RELATED PARTS
å PIECES: RELATIVES A LA SECURITE
PWB ASSEMBLY IS NOT REPLACEMENT ITEM
L'ASSEMBLANGE P.C.I. EST UN ARTICLE NON REMPLACABLE
Ref. No. Part No. ★ Description Code
PRINTED WIRING BOARD ASSEMBLIES
(NOT REPLACEMENT ITEM)
DUNTK3106QA00 VCR Unit —
DUNTK2934QA03 CAMERA Unit —
DUNTK3110PM00 CARD Unit —
DUNTK2936QA02 HEAD AMP Unit —
DUNTK2800PM03 CCD Unit —
TUNER AND ASSEMBLY UNITS
RUNTK0352TAZZ AV Jack Unit —
RUNTK0354TAZZ Lithium Battery Unit —
RUNTK0356TAZZ 6-cell Detection Unit —
RUNTK0404TAZZ VCR Operation SW Unit —
