98
Ref. No. Part No. ★ Description Code
Ref. No. Part No. ★ Description Code
VL-AD260U
D910 VHDFS1J3///-1 FS1J3 AD
D930 VHDFS1J3///-1 FS1J3 AD
D931 VHDDA227///-1 DA227 AB
D934 VHDDA227///-1 DA227 AB
D940 VHDF1J2H///-1 F1J2H AD
D960 VHDF1J2H///-1 F1J2H AD
D1802 RH-EX1399CEZZ Zener, EX1399CE AB
D2909 RH-EX1397CEZZ Zener, EX1397CE AB
D2910 VHDF1J2H///-1 F1J2H AD
D2912 VHDBAS316//-1 BAS316 AB
D2913 VHDF1J2H///-1 F1J2H AD
D2914 VHD1SS355//-1 1SS355 AB
D3800 VHDHVC359TR-1 HVC359TR AD
PACKAGED CIRCUITS
TH3800 VHHT1103K44-1 Thermistor AD
X701 RCRSC0170TAZZ Crystal, CRSC0170TA AG
X702 RCRSC0032TAZZ Crystal, CRSC0032TA AG
COILS AND TRANSFORMER
FL5701 RFiLC0168TAZZ Filter, FiLC0168TA AF
L201 VPAWM100K1R5N Peaking, 10µHAC
L202 VPAWM6R8J2R1N Peaking, 6.8µHAC
L203 VPAWM100K1R5N Peaking, 10µHAC
L204 VPCQM220K1R0N Peaking, 22µHAB
L205 VPAWM220K2R7N Peaking, 22µHAC
L206 VPAWM4R7MR70N Peaking, 4.7µHAC
L601 VPCQM101K4R3N Peaking, 100µHAB
L602 VPCCM101K2R1N Peaking, 100µHAC
L603 VPCQM220K1R0N Peaking, 22µHAB
L701 VPCCM4R7MR13N Peaking, 4.7µHAB
L702 VPCCM4R7MR13N Peaking, 4.7µHAB
L800 VPAWM100K1R5N Peaking, 10µHAC
L801 VPAWM330K4R8N~ Peaking, 33µHAB
L900 RCiLP0343TAZZ Coil, 10µHAD
L901 RCiLP0344TAZZ Coil, 4.7µHAD
L902 RCiLP0271TAZZ Coil, 33µHAE
L903 VPCCM2R2MR09N Peaking, 2.2µHAC
L904 VPCCM2R2MR09N Peaking, 2.2µHAC
L905 VPAWM100J2R6N Peaking, 10µHAC
L910 RCiLP0271TAZZ Coil, 33µHAE
L911 RCiLP0344TAZZ Coil, 4.7µHAD
L912 RCiLP0271TAZZ Coil, 33µHAE
L913 VPCQM100KR41N Peaking, 10µHAC
L920 RCiLP0287TAZZ Coil, 47µHAD
L921 VPCCM2R2MR09N Peaking, 2.2µHAC
L930 VPAWM100K1R5N Peaking, 10µHAC
L931 VPAWM100K1R5N Peaking, 10µHAC
L933 VPAWM100K1R5N Peaking, 10µHAC
L934 VPAWM100K1R5N Peaking, 10µHAC
L940 RCiLP0343TAZZ Coil, 10µHAD
L941 RCiLP0344TAZZ Coil, 4.7µHAD
L942 RCiLP0343TAZZ Coil, 10µHAD
L943 VPCQM2R2MR15N Peaking, 2.2µHAC
L944 VPCCM2R2MR09N Peaking, 2.2µHAC
L950 RCiLP0344TAZZ Coil, 4.7µHAD
L951 RCiLP0271TAZZ Coil, 33µHAE
L952 RCiLP0271TAZZ Coil, 33µHAE
L960 RCiLP0344TAZZ Coil, 4.7µHAD
L961 RCiLP0343TAZZ Coil, 10µHAD
L962 RCiLP0344TAZZ Coil, 4.7µHAD
L1401 VPAWM2R7J1R2N Peaking, 2.7µHAC
L1402 VPAWM1R0JR70N Peaking, 1µHAC
L1451 VPAWM100K1R5N Peaking, 10µHAC
L1452 VPAWM100K1R5N Peaking, 10µHAC
L1453 VPAWM120J2R8N Peaking, 12µHAD
L1914 RCiLP0343TAZZ Coil, 10µHAD
L3801 VPD9M150J2R2N Peaking, 15µHAC
L3802 VPAWM100J2R6N Peaking, 10µHAC
L5701 VPAWM100K1R5N Peaking, 10µHAC
L5702 VPAWM100K1R5N Peaking, 10µHAC
L6401 VPAWM820J120N Peaking, 82µHAD
L6402 VP-1M331J260N Peaking, 330µHAC
L6403 VPAWM680J110N Peaking, 68µHAC
L7401 VPAWM1R5JR90N Peaking, 1.5µHAC
Q975 VSHN2A01FU/-1 HN2A01FU AC
Q976 VSKRX202U++-1~ KRX202U++ AC
Q977 VSKRC404E++-1~ KRC404E++ AB
Q978 VSKRA303E++-1~ KRA303E++ AB
Q979 VSKTC3265Y+-1~ KTC3265Y+ AC
Q980 VSKRC403E++-1~ KRC403E++ AB
Q981 VSKTA1298Y+-1~ KTA1298Y+ AC
Q982 VSHN2C01FU/-1 HN2C01FU AC
Q983 VSKRX202U++-1~ KRX202U++ AC
Q984 VSKTC4075EY-1~ KTC4075EY AB
Q985 VSKRX202U++-1~ KRX202U++ AC
Q986 VSKTC4075EY-1~ KTC4075EY AB
Q987 VSHN2A01FU/-1 HN2A01FU AC
Q988 VSKRC404E++-1~ KRC404E++ AB
Q989 VSKRX202U++-1~ KRX202U++ AC
Q1401 VSKTA2014EY-1~ KTA2014EY AB
Q1402 VSKTA2014EY-1~ KTA2014EY AB
Q1403 VSKTC4075EY-1~ KTC4075EY AB
Q1404 VSKTC4075EY-1~ KTC4075EY AB
Q1451 VSKRC402E++-1~ KRC402E++ AB
Q1800 VS3LN01S///-1 3LN01S AC
Q1801 VSKTX101UY+-1~ KTX101UY+ AC
Q1802 VSKTX101UY+-1~ KTX101UY+ AC
Q2401 VSHN2C01FU/-1 HN2C01FU AC
Q2402 VSKTA501UY+-1~ KTA501UY+ AC
Q2403 VSKTC601UY+-1~ KTC601UY+ AC
Q2405 VSKTX101UY+-1~ KTX101UY+ AC
Q2406 VSKRC402E++-1~ KRC402E++ AB
Q2407 VSKTA2014EY-1~ KTA2014EY AB
Q2408 VSKTC4075EY-1~ KTC4075EY AB
Q2901 VSCPH6303++-1 CPH6303++ AE
Q2903 VSFTS1001//-1 FTS1001 AG
Q2905 VS2SB1205S/-1 2SB1205S AE
Q2906 VSKRC852U++-1~ KRC852U++ AC
Q2907 VSKRC852U++-1~ KRC852U++ AC
Q2910 VSKRX202U++-1~ KRX202U++ AC
Q2911 VS2SB1121T/-1 2SB1121T AC
Q2912 VSKRC402E++-1~ KRC402E++ AB
Q2913 VSKTA2014EY-1~ KTA2014EY AB
Q2914 VSKTX101UY+-1~ KTX101UY+ AC
Q2915 VSKRC403E++-1~ KRC403E++ AB
Q3601 VSKRC404E++-1~ KRC404E++ AB
Q3602 VSKRX202U++-1~ KRX202U++ AC
Q3801 VSKRC402E++-1~ KRC402E++ AB
Q5701 VSKRX202U++-1~ KRX202U++ AC
Q6401 VSHN2C01FU/-1 HN2C01FU AC
Q6402 VSHN2C01FU/-1 HN2C01FU AC
Q6404 VSKTC4075EY-1~ KTC4075EY AB
Q7401 VSKTX101UY+-1~ KTX101UY+ AC
Q7403 VSKRX202U++-1~ KRX202U++ AC
Q7404 VSHN2C01FU/-1 HN2C01FU AC
Q7406 VSKTA2014EY-1~ KTA2014EY AB
Q7407 VSKTC4075EY-1~ KTC4075EY AB
Q7408 VSKTA501UY+-1~ KTA501UY+ AC
Q7409 VSKRC653U++-1~ KRC653U++ AC
Q7410 VSKTC4075EY-1~ KTC4075EY AB
Q7452 VSKTC4075EY-1~ KTC4075EY AB
Q7453 VSKRC403E++-1~ KRC403E++ AB
Q7454 VSKRX202U++-1~ KRX202U++ AC
Q7455 VSKTX101UY+-1~ KTX101UY+ AC
Q8401 VSKTX101UY+-1~ KTX101UY+ AC
Q8404 VSKTC4075EY-1~ KTC4075EY AB
Q8405 VSKTA2014EY-1~ KTA2014EY AB
Q8451 VSKTC801UY+-1~ KTC801UY+ AC
Q8452 VSKTC801UY+-1~ KTC801UY+ AC
Q8453 VSKRA311E++-1~ KRA311E++ AB
DIODES
D601 VHDMA132K//-1 MA132K AA
D701 VHD1SS355//-1 1SS355 AB
D702 RH-DX0182TAZZ DX0182TA AD
D703 VHDMA132K//-1 MA132K AA
D704 RH-DX0182TAZZ DX0182TA AD
D900 VHDF1J2H///-1 F1J2H AD
D901 VHDMA2S111/-1 MA2S111 AC
