Ref. No. Part No. ★ Description Code
Ref. No. Part No. ★ Description Code
VL-AD260U
L7402 VPAWM180J3R6N Peaking, 18µHAD
L7403 VPAWM470J6R4N Peaking, 47µHAC
L7404 VP-1M471J310N Peaking, 470µHAC
L7405 VPD9M181J190N Peaking, 180µHAC
L7406 VP-1M331J260N Peaking, 330µHAC
L7407 VPAWM330J4R4N Peaking, 33µHAC
L7408 VP-1M331J260N Peaking, 330µHAC
L7452 VPAWM8R2J2R3N Peaking, 8.2µHAD
L7453 VPAWM8R2J2R3N Peaking, 8.2µHAD
L8401 VPAWM1R8JR98N Peaking, 1.8µHAC
L8402 VPAWM2R2J1R1N Peaking, 2.2µHAC
L8404 VPD9M221J210N Peaking, 220µHAB
L8405 VP-1M391J330N Peaking, 390µHAB
L8451 VPAWM820J120N Peaking, 82µHAD
L8452 VPD9M221J210N Peaking, 220µHAB
å T900 RTRNW0008TAZZY Power Transformer AG
CAPACITORS
C201 VCKYCY0JB105K 1 6.3V Ceramic AC
C202 VCSATA0JJ156M 15 6.3V Tantalum AC
C203 VCKYCZ1CB103K 0.01 16V Ceramic AB
C204 VCKYCZ1CB103K 0.01 16V Ceramic AB
C205 VCKYCZ1AB104K 0.1 10V Ceramic AB
C206 VCKYCZ1AB104K 0.1 10V Ceramic AB
C207 VCCCCY1HH271J 270p 50V Ceramic AA
C208 VCKYCZ1AB104K 0.1 10V Ceramic AB
C209 VCKYCZ1AB104K 0.1 10V Ceramic AB
C210 VCKYCZ1CB103K 0.01 16V Ceramic AB
C211 VCKYCZ1CB103K 0.01 16V Ceramic AB
C212 VCKYCZ1CB103K 0.01 16V Ceramic AB
C213 VCKYCZ1CB103K 0.01 16V Ceramic AB
C214 VCKYCZ1CB103K 0.01 16V Ceramic AB
C215 VCKYCY0JB105K 1 6.3V Ceramic AC
C216 VCSATA0JJ156M 15 6.3V Tantalum AC
C217 VCKYCY0JB105K 1 6.3V Ceramic AC
C218 VCKYCZ1CB103K 0.01 16V Ceramic AB
C219 VCCCCY1HH471J 470p 50V Ceramic AA
C220 VCSATA0JJ156M 15 6.3V Tantalum AC
C221 VCKYCZ1CB103K 0.01 16V Ceramic AB
C222 VCKYCZ1CB103K 0.01 16V Ceramic AB
C223 VCKYCZ1CB103K 0.01 16V Ceramic AB
C225 VCKYCZ1CB103K 0.01 16V Ceramic AB
C226 VCKYCZ1CB103K 0.01 16V Ceramic AB
C227 VCKYCZ1CB103K 0.01 16V Ceramic AB
C228 VCKYCZ1CB103K 0.01 16V Ceramic AB
C229 VCSATA0JJ156M 15 6.3V Tantalum AC
C230 VCKYCZ1CB103K 0.01 16V Ceramic AB
C232 VCKYCZ1CB103K 0.01 16V Ceramic AB
C233 VCKYCZ1CB103K 0.01 16V Ceramic AB
C235 VCSATA0JJ156M 15 6.3V Tantalum AC
C236 VCKYCZ1CB103K 0.01 16V Ceramic AB
C237 VCKYCZ1CB103K 0.01 16V Ceramic AB
C238 VCSATA0JJ156M 15 6.3V Tantalum AC
C239 VCKYCZ1CB103K 0.01 16V Ceramic AB
C240 VCKYCZ1CB103K 0.01 16V Ceramic AB
C241 VCKYCZ1CB103K 0.01 16V Ceramic AB
C242 VCKYCZ1CB103K 0.01 16V Ceramic AB
C243 VCKYCZ1CB103K 0.01 16V Ceramic AB
C244 VCKYCZ1CB103K 0.01 16V Ceramic AB
C245 VCKYCZ1CB103K 0.01 16V Ceramic AB
C246 VCKYCZ1CB103K 0.01 16V Ceramic AB
C247 VCKYCZ1CB103K 0.01 16V Ceramic AB
C250 VCKYCZ1CB103K 0.01 16V Ceramic AB
C251 VCKYCZ1CB103K 0.01 16V Ceramic AB
C252 VCKYCZ1CB103K 0.01 16V Ceramic AB
C253 VCKYCZ1CB103K 0.01 16V Ceramic AB
C254 VCKYCY0JB105K 1 6.3V Ceramic AC
C255 VCKYCZ1CB103K 0.01 16V Ceramic AB
C256 VCKYCZ1CB103K 0.01 16V Ceramic AB
C257 VCSATA0JJ156M 15 6.3V Tantalum AC
C258 VCKYCZ1CB103K 0.01 16V Ceramic AB
C259 VCKYCZ1CB103K 0.01 16V Ceramic AB
C260 VCKYCZ1CB103K 0.01 16V Ceramic AB
C261 VCKYCZ1CB103K 0.01 16V Ceramic AB
C262 VCKYCZ1CB103K 0.01 16V Ceramic AB
C263 VCKYCZ1CB103K 0.01 16V Ceramic AB
C264 VCKYCZ1CB103K 0.01 16V Ceramic AB
C265 VCKYCZ1CB103K 0.01 16V Ceramic AB
C266 VCKYCZ1CB103K 0.01 16V Ceramic AB
C601 VCSATA1CJ225M 2.2 16V Tantalum AC
C602 VCKYTV1CF225Z 2.2 16V Ceramic AC
C603 VCEAPF0JW476M 47 6.3V Electrolytic AB
C604 VCSATE0YJ476M~ 47 7V Tantalum AD
C605 VCKYCZ1CB103K 0.01 16V Ceramic AB
C606 VCKYCZ1CB103K 0.01 16V Ceramic AB
C607 VCKYCZ1CB103K 0.01 16V Ceramic AB
C608 VCKYCZ1CB103K 0.01 16V Ceramic AB
C609 VCKYCY1CF334Z 0.33 16V Ceramic AA
C610 VCKYCZ1CB103K 0.01 16V Ceramic AB
C611 VCEAPF0JW226M 22 6.3V Electrolytic AB
C612 VCEAPH1HW474M 0.47 50V Electrolytic AB
C613 VCKYCZ1CB103K 0.01 16V Ceramic AB
C614 VCKYCZ1CB223K 0.022 16V Ceramic AC
C615 VCEAPH1HW105M 1 50V Electrolytic AB
C616 VCKYCZ1HB102K 1000p 50V Ceramic AB
C617 VCEAPF0JW336M 33 6.3V Electrolytic AB
C618 VCKYCY0JB105K 1 6.3V Ceramic AC
C619 VCSATA0JJ475M 4.7 6.3V Tantalum AC
C620 VCKYCZ1CB103K 0.01 16V Ceramic AB
C621 VCSATA0JJ475M 4.7 6.3V Tantalum AC
C622 VCSAPD1DJ474M 0.47 20V Tantalum AD
C623 VCSATA0JJ106M 10 6.3V Tantalum AD
C624 VCEAPF0JW476M 47 6.3V Electrolytic AB
C625 VCSATA0JJ475M 4.7 6.3V Tantalum AC
C626 VCKYCZ1CB103K 0.01 16V Ceramic AB
C627 VCKYCZ1CB103K 0.01 16V Ceramic AB
C628 VCKYCZ1EB682K 6800p 25V Ceramic AB
C629 VCKYCZ1HB332K 3300p 50V Ceramic AA
C630 VCKYCZ1CB103K 0.01 16V Ceramic AB
C631 VCSAPD1CJ105M 1 16V Tantalum AC
C632 VCKYCZ1HB222K 2200p 50V Ceramic AB
C633 VCKYCZ1AB104K 0.1 10V Ceramic AB
C634 VCKYCZ1AB104K 0.1 10V Ceramic AB
C635 VCKYCZ1CB103K 0.01 16V Ceramic AB
C636 VCSAPD1CJ105M 1 16V Tantalum AC
C637 VCEAPF0JW476M 47 6.3V Electrolytic AB
C638 VCKYCZ1CB223K 0.022 16V Ceramic AC
C641 VCKYCZ1CB103K 0.01 16V Ceramic AB
C701 VCKYCZ1HB102K 1000p 50V Ceramic AB
C702 VCKYCZ1HB102K 1000p 50V Ceramic AB
C703 VCKYCZ1HB102K 1000p 50V Ceramic AB
C704 VCKYCZ1HB102K 1000p 50V Ceramic AB
C705 VCKYCZ1HB102K 1000p 50V Ceramic AB
C706 VCKYCZ1HB102K 1000p 50V Ceramic AB
C707 VCKYCZ1HB102K 1000p 50V Ceramic AB
C708 VCKYCZ1AB104K 0.1 10V Ceramic AB
C709 RC-KZ0052TAZZ 4.7 16V Ceramic AC
C711 VCKYCY1AF105Z 1 10V Ceramic AC
C712 VCCCCZ1HH220J 22p 50V Ceramic AB
C713 VCCCCZ1HH180J 18p 50V Ceramic AB
C714 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C715 VCKYCZ1HB102K 1000p 50V Ceramic AB
C716 VCSATA0YJ106M 10 7V Tantalum AC
C717 VCKYCZ1AB104K 0.1 10V Ceramic AB
C718 VCKYCZ1AB104K 0.1 10V Ceramic AB
C720 VCKYCZ1AB104K 0.1 10V Ceramic AB
C721 VCCCCZ1HH330J 33p 50V Ceramic AB
C722 VCKYCZ1AB104K 0.1 10V Ceramic AB
C724 VCKYCZ1AB104K 0.1 10V Ceramic AB
C725 VCKYCZ1AB104K 0.1 10V Ceramic AB
C726 VCKYCZ1HB471K 470p 50V Ceramic AB
C727 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C728 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C729 VCKYCZ1AB104K 0.1 10V Ceramic AB
C730 VCKYCZ1AB104K 0.1 10V Ceramic AB
C731 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C732 VCSATA0YJ106M 10 7V Tantalum AC
C733 VCKYCY1AF105Z 1 10V Ceramic AC
C737 VCKYCZ1AB104K 0.1 10V Ceramic AB
C738 VCKYCZ1AB104K 0.1 10V Ceramic AB
