Ref. No. Part No. ★ Description Code
Ref. No. Part No. ★ Description Code
152
VL-SD20U
VL-NZ50S/H/E/W/NZ80H
VL-NZ100S/H/E
R627 VRS-CZ1JF103J 10k 1/16W Metal Oxide AA
R628 VRS-CZ1JF682J 6.8k 1/16W Metal Oxide AA
R629 VRS-CZ1JF182J 1.8k 1/16W Metal Oxide AA
R630 VRS-CZ1JF223J 22k 1/16W Metal Oxide AA
R631 VRS-CZ1JF333J 33k 1/16W Metal Oxide AA
R632 VRS-CZ1JF334J 330k 1/16WMetal Oxide AA
R633 VRS-CZ1JF273J 27k 1/16W Metal Oxide AA
R634 VRS-CZ1JF153J 15k 1/16W Metal Oxide AA
R635 VRS-CZ1JF123J 12k 1/16W Metal Oxide AA
R637 VRS-CZ1JF106J 10M 1/16W Metal Oxide AA
R638 VRS-CZ1JF562J 5.6k 1/16W Metal Oxide AA
R639 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
(NZ50S/H/E/W(Hong Kong)/
E(Australia, New Zealand/NZ80H))
R640 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R641 VRS-CZ1JF222J 2.2k 1/16W Metal Oxide AA
R642 VRS-CZ1JF222J 2.2k 1/16W Metal Oxide AA
R643 VRS-CZ1JF223J 22k 1/16W Metal Oxide AA
R645 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
(NZ50S/H/E/W(Hong Kong)/
E(Australia, New Zealand/NZ80H))
R2601 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R2606 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R2608 VRS-CZ1JF103J 10k 1/16W Metal Oxide AA
R2609 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R2610 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R2611 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R2612 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R2613 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R2614 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R2615 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R2616 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R2617 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R2619 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R2620 VRS-CZ1JF104J 100k 1/16W Metal Oxide AA
R2621 VRS-CZ1JF104J 100k 1/16W Metal Oxide AA
R2622 VRS-CZ1JF104J 100k 1/16W Metal Oxide AA
R2623 VRS-CZ1JF104J 100k 1/16W Metal Oxide AA
R2624 VRS-CZ1JF104J 100k 1/16W Metal Oxide AA
R2625 VRS-CZ1JF104J 100k 1/16W Metal Oxide AA
R2626 VRS-CZ1JF104J 100k 1/16W Metal Oxide AA
R2627 VRS-CZ1JF104J 100k 1/16W Metal Oxide AA
R2628 VRS-CZ1JF104J 100k 1/16W Metal Oxide AA
R2629 VRS-CZ1JF104J 100k 1/16W Metal Oxide AA
R2630 VRS-CZ1JF104J 100k 1/16W Metal Oxide AA
BALUNES
R601 RBLN-0029TAZZY Balun, BLN-0029TA AB
(NZ80H/NZ100S/H)
R602 RBLN-0029TAZZY Balun, BLN-0029TA AB
(NZ80H/NZ100S/H)
R644 RBLN-0029TAZZY Balun, BLN-0029TA AB
(NZ80H/NZ100S/H)
MISCELLANEOUS PARTS
P601 QPLGN0276TAZZ Plug, 2Pin AD
J601 QJAKE0060TAZZ Jack, 4Pin AE
(NZ80H/NZ100S/H)
SC2601 QSOCN1090TAZZY Socket, 10Pin AD
SC2602 QSOCN1160TAZZ Socket, 11Pin AD
SC2604 QCNCW3396TAZZY Connector, 33Pin AG
DUNTKB191PM02(VL-NZ80H/NZ100S/H/E/
E(HONG KONG)/
E(AUSTRALIA, NEW ZEALAND))
CARD PWB UNIT
TRANSISTORS
Q1501 VSKTA2014EY-1Y KTA2014EY AB
Q1502 VSHN2C01FU/-1 HN2C01FU AC
CAPACITORS
C1501 VCSATA0JJ336M 33 6.3V Tantalum AD
C1502 VCKYCZ1CB103K 0.01 16V Ceramic AB
C1503 VCKYCZ1AF104Z 0.1 10V Ceramic AB
RESISTORS
R1501 VRS-CZ1JF103J 10k 1/16W Metal Oxide AA
R1502 VRS-CZ1JF103J 10k 1/16W Metal Oxide AA
R1504 VRS-CZ1JF103J 10k 1/16W Metal Oxide AA
R1505 VRS-CZ1JF103J 10k 1/16W Metal Oxide AA
R1506 VRS-CZ1JF103J 10k 1/16W Metal Oxide AA
R1507 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R1508 VRS-CZ1JF103D 10k 1/16W Metal Oxide AB
R1509 VRS-CZ1JF103D 10k 1/16W Metal Oxide AB
R1510 VRS-CZ1JF104J 100k 1/16W Metal Oxide AA
R1511 VRS-CZ1JF152J 1.5k 1/16W Metal Oxide AA
R1512 VRS-CZ1JF222D 2.2k 1/16W Metal Oxide AA
R1513 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R1514 VRS-CZ1JF153D 15k 1/16W Metal Oxide AB
MISCELLANEOUS PARTS
SC1501 QSOCZ0075TAZZY Socket, 15Pin AM
SC1502 QCNCW2796TAZZ Connector, 27Pin AG
SW1501 QSW-MA001WJZZY Switch AD
DUNTKB192QA00
INVERTER PWB UNIT
TRANSISTOR
Q9801 VSCPH5504++-1Y CPH5504++ AE
COIL AND TRANSFORMER
L9801 RCiLP0349TAZZY Coil, 33µHAD
å T9800 RTRNZ0166TAZZY Transformer AK
CAPACITORS
C9800 RC-KZ0055TAZZ 3.3 16V Ceramic AD
C9802 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C9807 RC-CZ0061TAZZY 0.022 25V Ceramic AD
C9810 VCKYCY1HB332K 3300p 50V Ceramic AA
C9812 RC-KZ0351CEZZ 18p 3kV Ceramic AD
RESISTORS
R9803 VRS-CZ1JF152J 1.5k 1/16W Metal Oxide AA
R9804 VRS-CZ1JF152J 1.5k 1/16W Metal Oxide AA
R9808 VRS-CZ1JF271D 270 1/16W Metal Oxide AB
R9809 VRS-CZ1JF271D 270 1/16W Metal Oxide AB
MISCELLANEOUS PARTS
BAT9801QTANS9045TAFW Li Batt Terminal AC
BAT9802QTANS9046TAFW Li Batt Terminal AC
SC9801 QSOCN0924TAN1Y Socket, 9Pin AD
SC9802 QCNCWA021WJZZY Connector, 4Pin AE
SW9800 QSW-M0018TAZZ Switch, Eject SW AC
DUNTKB193PM00
OPERATION PWB UNIT
CAPACITOR
C2001 VCKYCZ1AF104Z 0.1 10V Ceramic AB
RESISTORS
R2001 VRS-CZ1JF750J 75 1/16W Metal Oxide AA
R2002 VRS-CZ1JF153J 15k 1/16W Metal Oxide AA
R2003 VRS-CZ1JF472J 4.7k 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
RMC2001 RRMCU0021TAZZY Remote Receiver AK
SC2001 QSOCN0624TAN1Y Socket, 6Pin AD
