Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
16-1
VL-PD3S/H/E
VL-PD3S/H/E
16.REPLACEMENT PARTS LIST/
EXPLODED VIEWS
ELECTRICAL PARTS LIST
Parts marked with " å " are important for maintaining the safety of the
set. Be sure to replace these parts with specified ones for maintaining
the safety and performance of the set.
" HOW TO ORDER REPLACEMENT PARTS "
★MARK : SPARE PARTS-DELIVERY SECTION : ALL JAPAN
To have your order filled promptly and correctly, please furnish
the following informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
5. PRICE CODE
å MARK: SAFETY RELATED PARTS
Ref. No. Part No. ★ Description Code
IC3701 RH-iX0709TAZZ IX0659TA(SVART/LENS AX
CONTROL MICON)
IC3703 VHiTC7S04U/-1 INVERTER AE
IC4441 VHiTC4W53U/-1 V 0+1 SW AF
IC4453 RH-iX0625TAZZ IX0625TA(DIGITAL BC
ADC/DAC)
IC4701 VHiMB88344F-1 D/A CONVERTER AV
IC4702 VHiBU4051FV-1 MUX AF
TRANSISTORS
Q251 VS2SB12956/-1 2SB12956 AB
Q601 VSFMG12////-1 FMG12 AD
Q602 VSXP4313///-1 XP4313 AC
Q606 VSXP4313///-1 XP4313 AC
Q701 VS2PA1774R/-1 2PA1774R AB
Q702 VSUN9214///-1 UN9214 AB
Q1401 VSiMD16A///-1 IMD16A AD
Q1402 VS2PA1774R/-1 2PA1774R AB
Q1403 VSUPUMZ1///-1 UPUMZ1 AC
Q1404 VSUPUMZ1///-1 UPUMZ1 AC
Q1413 VS2PA1774R/-1 2PA1774R AB
Q1414 VS2PA1774R/-1 2PA1774R AB
Q1415 VSUPDC144EE-1 UPDC144EE AB
Q1416 VSUPDC144EE-1 UPDC144EE AB
Q4431 VSXP1213///-1 XP1213 AB
Q4432 VS2PA1774R/-1 2PA1774R AB
Q4433 VS2PA1774R/-1 2PA1774R AB
Q4434 VS2PA1774R/-1 2PA1774R AB
Q4441 VS2PC4617R/-1 2PC4617R AB
Q4442 VSXP6401///-1 XP6401 AB
Q4461 VSUPUMZ1///-1 UPUMZ1 AC
Q4462 VSUPUMZ1///-1 UPUMZ1 AC
Q4463 VSUPUMZ1///-1 UPUMZ1 AC
Q4464 VSUPUMZ1///-1 UPUMZ1 AC
Q4465 VSUPUMZ1///-1 UPUMZ1 AC
Q4701 VSUPDA114EE-1 UPDA114EE AB
DIODES
D451 VHDHVC362//-1 Diode, DHVC362 AE
D452 VHDHVC362//-1 Diode, DHVC362 AE
D701 VHDDA221///-1 Diode, DDA221 AB
D1401 VHDMA133///-1 Diode, DMA133 AB
D1402 VHDBAV756S/-1 Diode, DBAV756S AC
D4441 VHDKV1812K/-1 Diode, DKV1812K AD
D4442 VHDKV1812K/-1 Diode, DKV1812K AD
PACKAGED CIRCUITS
X452 RCRSC0109TAZZ Crystal AM
X701 RCRSC0032TAZZ Crystal AG
X4441 RCRSC0153TAZZ Crystal AN
FILTERS AND COILS
FL701 RFiLC0071TAZZ Filter AE
FL702 RCiLB0040TAZZ Oscillation Coil AF
FL3701 RFiLC0079TAZZ Filter AE
L151 VPD9M100KR86N Peaking 10µHAC
L201 VPAWM100K1R5N Peaking 10µHAC
L202 VPAWM100K1R5N Peaking 10µHAC
L203 VPAWM100K1R5N Peaking 10µHAC
L251 VPD9M100KR86N Peaking 10µHAC
L252 VPD9M100KR86N Peaking 10µHAC
L253 VPAWM100K1R5N Peaking 10µHAC
L451 VPCBM4R7MR25N Peaking 4.7µHAC
L452 VPCBM4R7MR25N Peaking 4.7µHAC
L453 VPCBM4R7MR25N Peaking 4.7µHAC
L454 RCiLC0014TAZZ Coil AC
L455 VPCBM4R7MR25N Peaking 4.7µHAC
L601 VPBSM220K1R7N Peaking 22µHAD
L602 VPBSM220K1R7N Peaking 22µHAD
L603 VPBSM220K1R7N Peaking 22µHAD
L701 VPM6N100MR75N Peaking 10µHAC
L1401 VPCBM470K2R4N Peaking 47µHAC
L1402 VPCBM470K2R4N Peaking 47µHAC
L1407 VPBWM470K2R6N Peaking 47µHAC
L3701 VPAWM100K1R5N Peaking 10µHAC
PRINTED WIRING BOARD ASSEMBLIES
(NOT REPLACEMENT ITEM)
DUNTK2871PM02 MAIN1 PWB Unit(VL-PD3S) –
DUNTK2871PM03 MAIN1 PWB Unit(VL-PD3H) –
DUNTK2871PM04 MAIN1 PWB Unit –
(VL-PD3E/EW/EX)
DUNTK2872PM02 MAIN2 PWB Unit(VL-PD3S) –
DUNTK2872PM03 MAIN2 PWB Unit(VL-PD3H) –
DUNTK2872PM04 MAIN2 PWB Unit –
(VL-PD3E/EW/EX)
DUNTK2873QA02 CAMERA HEAD PWB Unit –
DUNTK2874PM01 POWER PWB Unit –
DUNTK2875QA02 LCD PWB Unit –
RAMP-0028TAN1 HEAD AMP Unit –
RUNTK0341TAZZ JOINT PWB Unit AU
RUNTK0343TAZZ REMOTE CONTROL AM
RECEIVER Unit
DUNTK2871PM02 MAIN1 PWB UNIT(VL-PD3S)
DUNTK2871PM03 MAIN1 PWB UNIT(VL-PD3H)
DUNTK2871PM04 MAIN1 PWB UNIT(VL-PD3E/EW/EX)
INTEGRATED CIRCUITS
IC151 VHiADS933Y/-1 10-BIT ANALOG TO AR
DIGITAL CONVERTER
IC201 RH-iX0620TAZZ IX0620TA(DIGITAL BC
SIGNAL PROCESS)
IC251 RH-iX0608TAZZ IX0608TA BB
(ELECTRIC ZOOM)
IC252 VHiM5412450-1 4.7M FIELD MEMORY BC
IC253 VHiM5412450-1 4.7M FIELD MEMORY BC
IC401 RH-iX0629TAZZ IX0629TA(CODEC) BF
IC402 RH-iX0494TAZZ IX0494TA(CODEC/ BD
EXTERNAL MEMORY)
IC451 RH-iX0468TAZZ IX0468TA(CLOCK AR
GENERATOR)
IC601 VHiBH7761KV-1 AUDIO I/O AS
IC701 RH-iX0693TAZZ IX0657TA(SYSTEM AY
CONTROL MICON)
IC702 RH-iX0695TAZZ IX0660TA(CHARACTER) AN
IC703 VHiM24C08W6-1 E
2
PROM AH
IC1401 VHiC111306F-1 VIDEO OUTPUT AX
PROCESS
