Sharp VL-PD3S User Manual

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
16-3
VL-PD3S/H/E
VL-PD3S/H/E
C711 VCKYCZ1HB102K 1000p 50V Ceramic AB
C712 VCKYCZ1HB102K 1000p 50V Ceramic AB
C713 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C714 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C715 VCKYCZ1CB103K 0.01 16V Ceramic AB
C1001 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C1401 VCKYCY1CF474Z 0.47 16V Ceramic AB
C1402 VCKYCY0JB105K 1 6.3V Ceramic AC
C1403 VCKYCY0JB105K 1 6.3V Ceramic AC
C1404 VCKYCY1CF474Z 0.47 16V Ceramic AB
C1405 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C1406 VCKYCY1CF474Z 0.47 16V Ceramic AB
C1407 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C1408 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C1409 VCSATE1AJ476M 47 10V Tantalum AD
C1410 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C1411 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C1412 VCKYCY1CF474Z 0.47 16V Ceramic AB
C1413 VCKYCY1CF474Z 0.47 16V Ceramic AB
C1414 VCSATE1AJ476M 47 10V Tantalum AD
C1415 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C1416 VCSATE0JJ107M 100 6.3V Tantalum AE
C1417 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C1418 VCSAPR1AJ475M 4.7 10V Tantalum AD
C1419 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C1420 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C1421 VCSAPR0JJ106M 10 6.3V Tantalum AD
C1423 VCSAPR1AJ475M 4.7 10V Tantalum AD
C1424 VCSATE0JJ107M 100 6.3V Tantalum AE
C1425 VCSAPR1AJ475M 4.7 10V Tantalum AD
C1426 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C1427 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C1428 VCSAPR0JJ106M 10 6.3V Tantalum AD
C1429 VCKYCY1CF474Z 0.47 16V Ceramic AB
C1430 VCKYCY1CF474Z 0.47 16V Ceramic AB
C1431 VCCCCZ1HH220J 22p 50V Ceramic AB
C1432 VCCCCZ1HH820J 82p 50V Ceramic AB
C1433 VCCCCZ1HH220J 22p 50V Ceramic AB
C1434 VCCCCZ1HH820J 82p 50V Ceramic AB
C1441 VCSATE1AJ476M 47 10V Tantalum AD
C1442 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C1447 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C3702 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C3703 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C3704 VCKYCZ1CB103K 0.01 16V Ceramic AB
C3705 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C3706 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C3707 VCKYTV1AB105K 1 10V Ceramic AD
C3708 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C4401 RC-KZ0083TAZZ Capacitor AD
C4402 RC-KZ0083TAZZ Capacitor AD
C4403 VCSATK0JJ476M 47 6.3V Tantalum AE
C4405 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C4406 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C4407 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C4408 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C4409 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C4410 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C4411 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C4412 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C4413 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C4414 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C4415 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C4416 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C4417 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C4418 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C4419 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C4420 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C4421 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C4422 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C4423 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C4424 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C4425 RC-KZ0083TAZZ Capacitor AD
C4426 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C4428 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C4429 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C4435 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C4436 VCSAPR0JJ106M 10 6.3V Tantalum AD
C4437 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C4441 VCSATA1AJ106M 10 10V Tantalum AC
C4442 VCCCCZ1HH220J 22p 50V Ceramic AB
C4445 VCCCCZ1HH220J 22p 50V Ceramic AB
C4446 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C4447 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C4448 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C4449 VCKYCZ1EB682K 6800p 25V Ceramic AB
C4450 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C4461 VCSAPR1AJ105M 1 10V Tantalum AD
C4462 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C4463 VCSATN1AJ106M 10 10V Tantalum AD
C4464 VCKYCY0JF105Z 1 6.3V Ceramic AB
C4465 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C4466 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C4468 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C4498 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C4499 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C4701 VCKYCY1AF105Z 1 10V Ceramic AC
C4702 VCKYCY1AF105Z 1 10V Ceramic AC
C4703 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C4704 VCKYCZ1AF104Z 0.1 10V Ceramic AB
RESISTORS
R153 VRS-CZ1JF102J 1k 1/16W Metal Oxide AA
R154 VRS-CZ1JF221J 220 1/16W Metal Oxide AA
R155 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R160 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R202 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R204 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R216 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R217 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R223 VRS-CZ1JF102J 1k 1/16W Metal Oxide AA
R226 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R252 VRS-CZ1JF101J 100 1/16W Metal Oxide AA
R253 VRS-CZ1JF102J 1k 1/16W Metal Oxide AA
R255 VRS-CZ1JF102J 1k 1/16W Metal Oxide AA
R256 VRS-CZ1JF102J 1k 1/16W Metal Oxide AA
R258 VRS-CZ1JF101J 100 1/16W Metal Oxide AA
R259 VRS-CZ1JF102J 1k 1/16W Metal Oxide AA
R260 VRS-CZ1JF222J 2.2k 1/16WMetal Oxide AA
R262 VRS-CZ1JF102J 1k 1/16W Metal Oxide AA
R263 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R401 VRS-CY1JF000J 0 1/16WMetal Oxide AA
R402 VRS-CY1JF000J 0 1/16WMetal Oxide AA
R403 VRS-CZ1JF102J 1k 1/16W Metal Oxide AA
R404 VRS-CZ1JF102J 1k 1/16W Metal Oxide AA
R405 VRS-CZ1JF102J 1k 1/16W Metal Oxide AA
R406 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R453 VRS-CZ1JF224J 220k 1/16W Metal Oxide AA
R454 VRS-CZ1JF224J 220k 1/16W Metal Oxide AA
R455 VRS-CZ1JF472J 4.7k 1/16WMetal Oxide AA
R456 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R457 VRS-CZ1JF101J 100 1/16W Metal Oxide AA
R458 VRS-CZ1JF105J 1M 1/16W Metal Oxide AA
R461 VRS-CZ1JF105J 1M 1/16W Metal Oxide AA
R463 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R464 VRS-CZ1JF222J 2.2k 1/16WMetal Oxide AA
R465 VRS-CZ1JF181J 180 1/16W Metal Oxide AA
R466 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R467 VRS-CZ1JF103J 10k 1/16W Metal Oxide AA
R468 VRS-CZ1JF224J 220k 1/16W Metal Oxide AA
R497 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R603 VRS-CZ1JF102J 1k 1/16W Metal Oxide AA
R609 VRS-CZ1JF102J 1k 1/16W Metal Oxide AA
R613 VRS-CZ1JF683J 68k 1/16W Metal Oxide AA
R614 VRK-SA1JF222J 2.2k 1/16W AB
Metal Composition
R616 VRS-CZ1JF683J 68k 1/16W Metal Oxide AA
R617 VRK-SA1JF222J 2.2k 1/16W AB
Metal Composition
R621 VRS-CZ1JF332J 3.3k 1/16WMetal Oxide AA
