PARTS GUIDE LC-50LE440M(A)
No. PARTS CODE
PRICE
RANK
NEW
MARK
Part
Delivery
DESCRIPTION
CP7001
9JD06GG280029
AD
*
CONNECTOR PCB SIDE, A2001WV-8A
EL2401
9JD124116281A
AD
*
EYE LET, EYE LET XRY16X28BD
EL2402
9JD124120301A
AC
*
EYE LET, EYE LET XRY20X30BD
SH3801
9JD126D000045
AD
*
TERMINAL PIN, YQ-12
SH3802
9JD126D000044
AD
*
TERMINAL PIN, YQ-36
SH3803
9JD126D000045
AD
*
TERMINAL PIN, YQ-12
SH3804
9JD126D000044
AD
*
TERMINAL PIN, YQ-36
SH3805
9JD126D000044
AD
*
TERMINAL PIN, YQ-37
SH3806
9JD126D000044
AD
*
TERMINAL PIN, YQ-38
PCB270
9JDA3QQ14Q270
AT
N
*
OPERATION PCB ASS'Y, CEM897A
R2201
9JDR803R9682J
AD
*
RC, 6.8K OHM 1/16W
R2202
9JDR803R9272J
AD
*
RC, 2.7K OHM 1/16W
R2203
9JDR803R9182J
AD
*
RC, 1.8K OHM 1/16W
R2204
9JDR803R9113J
AD
*
RC,11K OHM 1/16W
C2201
9JDCS0PB0415K
AD
*
CC, 0.1 UF 50V B
C2202
9JDCS0PB0415K
AD
*
CC, 0.1 UF 50V B
SW2201
9JD0504101T34
AC
*
SWITCH,TACT, EVQ21505R
SW2202
9JD0504101T34
AC
*
SWITCH,TACT, EVQ21505R
SW2203
9JD0504101T34
AC
*
SWITCH,TACT, EVQ21505R
SW2204
9JD0504101T34
AC
*
SWITCH,TACT, EVQ21505R
SW2205
9JD0504101T34
AC
*
SWITCH,TACT, EVQ21505R
SW2206
9JD0504101T34
AC
*
SWITCH,TACT, EVQ21505R
CP2202
9JD06GG230019
AD
*
CONNECTOR PCB SIDE, A2001WR-3A
9JD120A155811
AL
N
*
CORD AC, MO27-019BK (SMEF-M-Middle East, Malaysia, Singapore)
9JD120Q1L9801
AQ
N
*
CORD AC,0S6M8802 (SMEF-N-Middle East and North Africa)
9JD120Q198904
AM
N
*
CORD AC, MO27-026BK (Philippines)
ANT001 9JD06JA300001 AL
N
*
ANT UNIT, MTV225L (Philippines)
BT001
9JD141U004021
AD
*
BATTERY,MANGAN, AAA(R03)
BT002
9JD141U004021
AD
*
BATTERY,MANGAN, AAA(R03)
CD301
9JD06EH146702
AG
N
*
CORD CONNECTOR, EH146702
CD502
9JD12C10I2801
AF
N
*
CORD JUMPER, FFC125182800510T1-G00
CD2201
9JD06EA255101
AF
N
*
CORD CONNECTOR, EA255101
CD2202
9JD06E8235401
AD
N
*
CORD CONNECTOR, E8235401
CD2801
9JD06DC51028A
AU
N
*
CORD CONNECTOR, DC51028A
MAIN001
9JD1564200021
BL
N
*
MAIN UNIT, T.VST59.91A_V59_DIVX
SP301
9JD070Y056014
AL
*
SPEAKER, S0412F41
SP302
9JD070Y056014
AL
*
SPEAKER, S0412F41
TM101
9JD076K0UW011
AP
N
*
TRANSMITTER, 001.A43.K0UW011R
V7201 9JDA3QQ14QFM0
DD N
* LED MODULE ASS'Y, T500HVN04.1-LED OR2
U6 9JDIN7J059XE1
BC
* TSUMV59XE-Z1
U4 9JDIN7J028570 AF * AIC2857FGR8TR
U1 9JDIM2F911170 AF * LC1117CLTR33
U2 9JDIM2F917CL0 AE * LC1117CLTRAD
UA1 9JDIM2C931100 AN * TPA3110LD2PWPR
UH1 9JDIN7K066331 AM * IT6633E-P/CX
T1 9JD0145E19001 AV * CDT-3SP5I2-36
*** CAPACITORS ***
RESISTOR
RC...................................C.ARBON RESISTOR
CAPACITORS
CC..................................C..E. RAMIC CAPACITOR
CE..................................ALUMI ELECTROLYTIC CAPACITOR
CP..................................P. OLYESTER CAPACITOR
CPP................................P.OLYPROPYLENE CAPACITOR
CPL................................P..L..ASTIC CAPACITOR
CMP...............................M...E..T. AL POLYESTER CAPACITOR
CMPL.............................M..ETAL PLASTIC CAPACITOR
CMPP.............................M. ETAL POLYPROPYLENE CAPACITOR
*** SWITCHES ***
*** OTHERS ***
OPERATION PCB ASS'Y
*** PCB ***
*** RESISTORS ***
*** AND OTHERS ***
*** CONNECTORS ***
*** AC CORD ***
CD501
*** OTHERS ***
*** MAIN PARTS IN MAIN UNIT ***
K6
