4 Main PWB unit
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
16
! QFS-K2005BHZZ
AF A FUSE (LT-5 T400mAL/250V) [F2]
17
QSW-S2411BHZZ
AK N B SLIDE SWITCH (JSS2601CS) [SW1]
18
RALMB5006SCZZ
AD B Buzzer (EFB-RD22C01) [BZ]
19
RC-EZ0011QCZZ
AH N C CAPACITOR (3300µF/25V) [C2]
20
RC-KZ1054CCZZ
AB C Capacitor (50WV 0.1µF) [C7,C11,C14,C15,C16]
21
RCRMZ6007RCZZ
AD B Resonator (4.19MHz) [X2]
22
RCRSP6676RCZZ
AG B X-TAL (32.768KHz) [X1]
23
RH-IX2004BHZZ
BA N B CPU (uPD780023A) [IC2]
24
VCCCPU1HH101J
AB C Capacitor (50WV 100pF) [C17,C18,C19,C20,C21]
25
VCCCTV1HH180J
AA C Capacitor (50WV 18pF) [C12]
26
VCCCTV1HH220J
AA C Capacitor (50WV 22PF) [C13]
27
VCEAGA1CW476M
AB C Capacitor (16WV 47µF) [C30 (G3-VDD JUMPER)]
VCEAGA1CW476M
AB C Capacitor (16WV 47µF) [C6]
28
VCEAGA1EW107M
AB C Capacitor (25WV 100µF) [C4]
29
VCEAGA1HW226M
AB C Capacitor (50WV 22µF) [C9]
30
VCEAGA1EW337M
AC C Capacitor (330µF/25V SD)(VCEAGD1EW337M) [C3]
31
VCKYPU1HB332K
AA C Capacitor (50WV 3300pF)(VCKYPA1HB332K) [C22,C23,C24,C25]
VCKYPU1HB332K
AA C Capacitor (50WV 3300pF)(VCKYPA1HB332K) [C29 (G3-JP1)]
32
VCKYTV1HF104Z
AA C Capacitor (50WV 0.10µF) [C8]
33
VCQYNA1HM333K
AA C Capacitor (50WV 0.033µF) [C1]
34
VCQYNU1HM104K
AB C Capacitor (50WV 0.10µF) [C5,C10]
35
VHD1N4002G/-1
AA B Diode (1N4002G) [D1,D2,D3,D4,D5,D6]
36
VHDDSS133HV-1
AA B Diode (DSS133HV) [D7,D8,D9,D10,D12]
VHDDSS133HV-1
AA B Diode (DSS133HV) [D13,D14,D15,D16,D17]
VHDDSS133HV-1
AA B Diode (DSS133HV) [D18,D19,D20]
37
VHEMTZJ7R5B-1
AC N B ZENER DIODE (MTZJ 7.5B) [ZD1]
38
VHIKID65083AP
AM B IC (KID65083AP) [IC4,IC5]
39
VHILB1268//-1
AK B IC (LB1268) [IC3]
40
VHIMC7806CT-1
AG N B REGULATOR IC (MCT7806CT) [IC1]
41
VHPD5680GL2-1
AQ N B LED (2 SEGMENT)(D568GWA) [LED1,LED2,LED3,LED4]
42
VRD-RC2EY101J
AA C Resistor (1/4W 100Ω ±5%) [R70]
43
VRD-RC2EY102J
AA C Resistor (1/4W 1.0KΩ ±5%) [R11,R28,R29,R30]
44
VRD-RC2EY103J
AA C Resistor (1/4W 10KΩ ±5%) [R31,R32,R33]
45
VRD-RC2EY105J
AA C Resistor (1/4W 1.0MΩ ±5%) [R2]
46
VRD-RC2EY221J
AA C Resistor (1/4W 22Ω ±5%) [R1]
47
VRD-RC2EY272J
AA C Resistor (1/4W 2.7KΩ ±5%) [R10]
48
VRD-RC2EY331J
AA C Resistor (1/4W 330KΩ ±5%) [R54,R56,R58,R60]
49
VRD-RC2EY471J
AA C Resistor (1/4W 470Ω ±5%) [R25]
50
VRD-RC2EY473J
AA C Resistor (1/4W 47KΩ ±5%) [R15,R16,R17,R18]
VRD-RC2EY473J
AA C Resistor (1/4W 47KΩ ±5%) [R19,R20,R23,R24]
51
VRD-RC2EY562J
AA C Resistor (1/4W 5.6KΩ ±5%) [R4]
52
VRD-RC2EY563J
AA C Resistor (1/4W 56KΩ ±5%) [R5,R12,R13]
53
VRD-RC2EY682J
AA C Resistor (1/4W 6.8KΩ ±5%) [R55,R57,R59,R61]
54
VRD-RC2EY683J
AA C Resistor (1/4W 68KΩ ±5%) [R3]
55
VRS-CY1JD000J
AA C Resistor (1/16W 0Ω ±5%)(Jumper/1608Type) [R26]
56
VRS-CY1JD102J
AA C Resistor (1/16W 1.0KΩ ±5%) [R7,R8]
57
VRS-CY1JD104J
AA C Resistor (1/16W 100KΩ ±5%) [R6]
58
VRS-CY1JD472J
AA C Resistor (1/16W 4.7KΩ ±5%) [R9]
59
VRS-CY1JD563J
AA C Resistor (1/16W 56KΩ ±5%) [R14]
60
VRS-CY2AY111J
AA N C CHIP RESISTOR (1/10W 110Ω ±5% 1608) [R34,R35,R36,R37,R38]
VRS-CY2AY111J
AA N C CHIP RESISTOR (1/10W 110Ω ±5% 1608) [R39,R40,R41,R42,R43]
VRS-CY2AY111J
AA N C CHIP RESISTOR (1/10W 110Ω ±5% 1608) [R44,R45,R46,R47,R48]
VRS-CY2AY111J
AA N C CHIP RESISTOR (1/10W 110Ω ±5% 1608) [R49]
61
VS2SC3198-/-1
AL B Transistor (2SC3198) [Q3]
62
VS2SD2170//-1
AH B Transistor (2SD2170) [Q1,Q2]
63
VSKTA1271//-1
AE B Transistor (KTA1271)(VS2SA1271-/-1) [Q6,Q7,Q8,Q9]
64
XBBSD30P06000
AA C Screw (3×6) [IC1]
(Unit)
901
CPWBF2915BH01
BP N E MAIN PWB UNIT
5 Slide SW I/F PWB unit
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
1
QCNCW2908BHZZ
AG N C SW CONNECTOR (5229-05APB)
(Unit)
901
CPWBF2916BH01
AV N E SLIDE SW I/F PWB UNIT
6 Articles for consumption
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
1
DPAPR1025CSZZ
AV S Roll paper (5 rolls/pack)
2
NROLR1022CC05
BA S Ink roller
XE-A101U/A
– 6 –
