4) REWIND MOTOR
When the rewind motor is driven by the signal of the CPU.
5) DRAWER
DRAWER OPEN signal :Output high signal between 50ms
6) DETECTING "LOW VOLTAGE"
•
Values obtained by AD conversion and averaging
Register value: 138 (
2.7V) or less No voltage
139 - 154 (
2.7V - 3.0V) Low voltage
more than 154
OK
7) DESTINATION DETECTION port
U and A version
P66 L
5ms
10ms
15ms
PRINTER
MOTOR
REWIND
MOTOR
