PRICE
RANK
DESCRIPTION
NO.
PART CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
XL-1700/1700C
– 1 –
INTEGRATED CIRCUITS
IC101 VHILA4282//-1 J AM Power Amp.,LA4282
IC201 VHIKIA4558P-1 J AC Surround Control ,KIA4558P
IC302 VHILC72131/-1 J AP PLL (Tuner),LC72131
IC303 VHILA1832S/-1 J AN FM IF Det./FM Mpx./AM IF,
LA1832S
IC401 VHILC75342M-1 J AN Function/Volume Equalizer,
LC75342M
IC681 VHIAN78L05/-1 J AE Constant Voltage Regulator,
AN78L05
IC701 RH-IX0043SJZZ J AX
System Microcomputer/FL Driver,
IX0043SJ
IC801 VHITC94A14F-1 J AY Servo/Signal Control,TC94A14F
IC802 VHITA2157F/-1 J AN Head Amp.,TA2157F
IC803 VHIMM1469PH-1 J Focus/Tracking/Spin/Sled Driver,
MM1469PH
IC804 VHITA7291S/-1 J AH CD LID Motor Driver,TA7291S
TRANSISTORS
Q101~104 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q105,106 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q108 VSKRA107M//-1 J AE Digital,PNP,KRA107 M
Q109 VSKRC107M//-1 J AC Digital,NPN,KRC107 M
Q201 VS2SK2541//-1 J AC FET,2SK2541
Q203 VSKRC107M//-1 J AC Digital,NPN,KRC107 M
Q301 VS2SC380-O/-1 J AC Silicon,NPN,2SC380 O
Q351 VSKRC104M//-1 J AC Digital,NPN,KRC104 M
Q360 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q601 VSKTC3200GR-1 J AC Silicon,NPN,KTC3200 GR
Q602,603 VS2SD2012Y/-1 J AF Silicon,NPN,2SD2012 Y
Q604 VSKTC3200GR-1 J AC Silicon,NPN,KTC3200 GR
Q605 VS2SD2012Y/-1 J AF Silicon,NPN,2SD2012 Y
Q606 VSKRA102M//-1 J AC Digital,PNP,KRA102 M
Q607 VSKRC107M//-1 J AC Digital,NPN,KRC107 M
Q683 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q701 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q702,703 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q706 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q707,708 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q709 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q801 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q802 VS2SB562-C/-1 J AD Silicon,PNP,2SB562 C
Q804 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q806,807 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q808 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q809 VSKRA102M//-1 J AC Digital,PNP,KRA102 M
Q810 VSKRC107M//-1 J AC Digital,NPN,KRC107 M
DIODES
D101,102 VHD1N4148//-1 J AA Silicon,1N4148
D201 VHD1N4148//-1 J AA Silicon,1N4148
D301~304 VHD1N4148//-1 J AA Silicon,1N4148
D308 VHD1N4148//-1 J AA Silicon,1N4148
D401~403 VHD1N4004//-1 J AB Silicon,1N4004
D601,602 VHD1N4148//-1 J AA Silicon,1N4148
1 D651~654 VHD1N5402M/-1 J AE Silicon,1N5402M
1 D657~660 VHD1N4004//-1 J AB Silicon,1N4004
1 D681~685 VHD1N4004//-1 J AB Silicon,1N4004
D688,689 VHD1N4004//-1 J AB Silicon,1N4004
D701,702 VHD1N4148//-1 J AA Silicon,1N4148
D720~723 VHD1N4148//-1 J AA Silicon,1N4148
D801~806 VHD1N4148//-1 J AA Silicon,1N4148
LED701~704 VHPLP3052D+-1 J AN LED,LP3052D
LED801 VHPLP99B+++-1 J AM LED,LP99B
VD301 VHCSVC348S/-1 J AK Variable Capacitance,SVC348S
ZD351 VHEDZ5R1BSB-1 J AC Zener,5.1V,DZ5.1BSB
ZD601 VHEDZ130BSA-1 J AC Zener,13V,DZ130A
ZD602 VHEDZ8R2BSC-1 J AB Zener,8.2V,DZ8.2BSC
ZD701 VHEDZ3R3BSB-1 J AB Zener,3.3V,DZ3.3BSB
ZD801 VHEDZ5R1BSB-1 J AC Zener,5.1V,DZ5.1BSB
ZD802 VHEDZ3R9BSB-1 J AC Zener,3.9V,DZ3.9BSB
FILTERS
CF301,302 RFILF0072AFZZ J AG FM IF
CF351 RFILF0003AWZZ J AK FM IF
CF352 RFILA0003SJZZ J AF AM IF
TRANSFORMERS
T302 RCILA0007SJZZ J AG AM Antenna
T306 RCILB0009SJZZ J AG AM OSC.
T351 RCILI0004SJZZ J AF AM IF
1 T651 RTRNP0083SJZZ J Power Transformer (Main)
1 T681 RTRNP0056SJZZ J AM Power Transformer (Sub)
COILS
L101,102 RCILZ0024AWZZ J AC 3 µH,Choke
L105 VP-DH100K0000 J AB 10 µH,Choke
L106 VP-DH2R2K0000 J AB 2.2 µH,Peaking
L342 VP-DH2R2K0000 J AB 2.2 µH,Peaking
L351,352 VP-DH101K0000 J AB 100 µH,Choke
L353 VP-DH102K0000 J AB 1 mH,Choke
L401 VP-DH2R2K0000 J AB 2.2 µH,Peaking
L402 RCORF0018AWZZ J AG Core
L521 VP-DH2R2K0000 J AB 2.2 µH,Peaking
L701 VP-DH100K0000 J AB 10 µH,Choke
L704 RCILC0353AFZZ J AB Tip Solid Induction,100mA
L801,802 VP-DH2R2K0000 J AB 2.2 µH,Peaking
L804 VP-XHR82K0000 J AC 0.82 µH
L805 VP-DH2R2K0000 J AB 2.2 µH,Peaking
L851~853 RCILC0353AFZZ J AB Tip Solid Induction,100mA
VARIABLE RESISTOR
VR351 RVR-M0026AWZZ J AC 10 kohm (B),Semi-VR
VIBRATORS
X351 RCRM-0007SJZZ J AG VCO,456 kHz
X352 RCRSP0006SJZZ J AF Crystal,4.5 MHz
X701 RCRM-0008SJZZ J AG Ceramic,8 MHz
X702 RCRSP0007SJZZ J AE Crystal,32.768 kHz
X801 RCRSP0002SJZZ J AL Crystal,16.93 MHz
CAPACITORS
RR-HZ0001AWZZ J AE 4.7 Mohms,1/2W
C101 RC-GZA107AF1C J AB 100 µF,16V,Electrolytic
C103,104 VCKYPA1HB471K J AA 470 pF,50V
C105,106 VCQYKA1HM823J J AC 0.082 µF,50V,Mylar
C107,108 RC-GZA107AF1E J AB 100 µF,25V,Electrolytic
C109,110 RC-GZV477AF1E J AC 470 µF,25V,Electrolytic
C111~114 VCFYFA1HA104J J AC 0.1 µF,50V,Thin Film
C115 RC-GZA106AF1H J AB 10 µF,50V,Electrolytic
C116~122 VCKYPA1HF223Z J AB 0.022 µF,50V
C123,124 VCKYPA1HB222K J AA 0.0022 µF,50V
C127 VCKYPA1HB102K J AA 0.001 µF,50V
C128 RC-GZA335AF1C J AB 3.3 µF,16V,Electrolytic
C129 VCKYPA1HF223Z J AB 0.022 µF,50V
C130 RC-GZA476AF1E J AB 47 µF,25V,Electrolytic
C131 RC-GZW228AF1H J AH 2200 µF,50V,Electrolytic
C137 RC-GZA474AF1H J AA 0.47 µF,50V,Electrolytic
C138 VCKYCY1HB472K J AA 0.0047 µF,50V
C201,202 VCKYCY1HB562K J AA 0.0056 µF,50V
C203,204 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C208 RC-GZA107AF1C J AB 100 µF,16V,Electrolytic
C209 RC-GZA476AF1C J AB 47 µF,16V,Electrolytic
C211,212 VCKYCY1HB332K J AA 0.0033 µF,50V
C213,214 RC-GZA475AF1H J AB 4.7 µF,50V,Electrolytic
C215,216 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C301 VCKYCY1EF123Z J 0.012µF,25V
C302 VCKYCY1HB102K J AA 0.001 µF,50V
C329 VCKYCY1EF223Z J AB 0.022 µF,25V
C330 VCCCPA1HH8R0D J AA 8 pF (CH),50V
C331 VCKYCY1EF473Z J AB 0.047 µF,25V
C332 VCKYPA1HF223Z J AB 0.022 µF,50V
C334 VCCUPA1HJ270J J AA 27 pF (UJ),50V
C335 VCKYCY1HB561K J AA 560 pF,50V
C337 VCKYPA1HF223Z J AB 0.022 µF,50V
C341 VCKYCY1EF223Z J AB 0.022 µF,25V
C343 VCCSCY1HL330J J AD 33 pF,50V
C345~347 VCKYCY1EF223Z J AB 0.022 µF,25V
C348 RC-GZA107AF1C J AB 100 µF,16V,Electrolytic
C349 VCKYCY1HB102K J AA 0.001 µF,50V
C350,351 VCKYCY1EF223Z J AB 0.022 µF,25V
C352 RC-GZA106AF1C J AB 10 µF,16V,Electrolytic
To Next Page
