Sharp XL-60H Service Manual

– 3 –
XL-60H/70H
SPECIFICATIONS
XL-60H/70H
CP-XL70H
Specifications for this model are subject to change without
prior notice.
CP-XL60H
FOR A COMPLETE DESCRIPTION OF THE OPERATION OF THIS UNIT, PLEASE REFER
TO THE OPERATION MANUAL.
● Cassette deck section
Frequency
response: 50 - 14,000 Hz (Normal tape)
Signal/noise ratio: 50 dB
Wow and flutter:
(For Europe)
0.3 % (DIN 45 511)
● Speaker section
Type: 2-way [10 cm (4") woofer and
1.5 cm (9/16") tweeter]
Rated input
power: 20 W
Maximum input
power: 40 W
Impedance: 4 ohms
Dimensions: Width; 160 mm (6-5/16")
Height; 240 mm (9-1/2")
Depth; 190 mm (7-7/16")
Weight: 1.8 kg (4.0 lbs.)/each
Type: 2-way [10 cm (4") woofer and
2.5 cm (1") semi dome
tweeter]
Rated input
power: 20 W
Maximum input
power: 40 W
Impedance: 4 ohms
Dimensions: Width; 160 mm (6-5/16")
Height; 240 mm (9-1/2")
Depth; 189 mm (7-1/16")
Weight: 2.4 kg (5.3 lbs.)/each
● General
Power source: AC 230 V, 50 Hz
Power
consumption: 50 W
Dimensions: Width; 160 mm (6-5/16")
Height; 241 mm (9-1/2")
Depth; 298 mm (11-3/4")
Weight: 3.6 kg (7.9 lbs.)
● Amplifier section
Output power:
(For Europe)
PMPO; 120 W (total)
MPO; 60 W (30 W + 30 W)
(DIN 45 324)
RMS; 40 W (20 W + 20 W)
(DIN 45 324)
Output terminals: Speakers; 4 ohms
Headphones; 16-50 ohms
(recommended; 32 ohms)
CD digital output (optical)
Input terminals: Video/Auxiliary (audio signal);
500 mV/47 k ohms
● Tuner section
Frequency range: FM; 87.5-108 MHz
AM; 522-1,620 kHz
● Compact disc player section
Type: Compact disc player
Signal readout: Non-contact, 3-beam semi-
conductor laser pickup
D/A converter: 1-bit D/A converter
Filter: 8-times oversampling digital
filter
Frequency
response: 20 - 20,000 Hz
Wow and flutter: Unmeasurable
(less than 0.001% W. peak)
Output power:
(For U.K.)
RMS; 40 W (20 W + 20 W)
(10 % T.H.D.)
Wow and flutter:
(For U.K.)
0.25 % (WRMS)
