NO.
PRICE
RANK
DESCRIPTIONPARTS CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
XL-60H/70H
ACCESSORIES/PACKING PARTS (For Europe)
! QACCE0001SJZZ J AH AC Power Supply Cord
QANTL0002SJZZ J AM AM Loop Antenna
QANTW0002SJZZ J AH FM Antenna
SPAKA0040SJZZ J AG Packing Add.,Top
[For Europe Only]
SPAKA0041SJZZ J AG Packing Add.,Bottom
[For Europe Only]
SPAKA0052SJZZ J Packing Add.,Side
[For Europe Only]
SPAKC0101SJZZ J AM Packing Case [XL-60H]
SPAKC0103SJZZ J AQ Packing Case [XL-70H]
SPAKP0005SJZZ J AC Polyethylene Bag,Unit
[For Europe Only]
SPAKZ0019SJZZ J AC Protection Sheet,Top/Bottom
[For Europe Only]
SSAKA0002SJZZ J AE Polyethylene Bag,Accessories
TINSZ0056SJZZ J AM Operation Manual
TLABE0054SJZZ J Label,Bar Code,Packing Case
TLABM0022SJZZ J AC Label,Feature [XL-60H]
TLABM0024SJZZ J AD Label,Feature [XL-70H]
TLABZ0030SJZZ J AC Label,Saving Energy
[For Europe Only]
RRMCG0014SJSB J AS Remote Control
GFTAB1021AWSB J Battery Lid,Remote Control
ACCESSORIES/PACKING PARTS (For U.K.)
! 1 QACCB0001SJ00 J AW AC Power Supply Cord
2 QANTL0002SJZZ J AM AM Loop Antenna
3 QANTW0002SJZZ J AH FM Antenna
4 RRMCG0014SJSB J AS Remote Control
4-1 GFTAB1021AWSB J Battery Lid,Remote Control
5 SPAKA0043SJZZ J AK Packing Add.,Left/Right
[For U.K. Only]
6 SPAKC0110SJZZ J AN Packing Case [XL-60H]
6 SPAKC0111SJZZ J AN Packing Case [XL-70H]
7 SPAKP0002SJZZ J AD Polyethylene Sheet,Unit
[For U.K. Only]
8 SPAKP0003SJZZ J AC Polyethylene Sheet,AC Power
Supply Cord [For U.K. Only]
9 SSAKA0002SJZZ J AE Polyethylene Bag,Accessories
10 TINSE0037SJZZ J AE Operation Manual
11 TLABM0022SJZZ J AC Label,Feature [XL-60H]
11 TLABM0024SJZZ J AD Label,Feature [XL-70H]
12 TINSE0042SJZZ J AB Quick Guide [For U.K. Only]
13 TLABE0054SJZZ J Label,Bar Code,Packing Case
14 TCADN0001SJZZ J AE R-Card [For U.K. Only]
P.W.B. ASSEMBLY (Not Replacement Item)
PWB-A1~10 DCEKL0002SJ03 J — Main/Display/CD/LED/
Headphones/Open•Close
Switch/JOG Switch/Digital Out/
CD Lid/Washer
(Combined Ass'y)
! PWB-B1,2 DCEKJ0005SJ06 J — Power,Power Amp.
(Combined Ass’y)
PWB-C QPWBF3895AFZZ J AC CD Motor (PWB Only)
PWB-D 9GD192121303 J — Tape Mechanism
PWB-E 9GD192121304 J — Tape Mechanism
OTHER SERVICE PART
UDSKA0004AFZZ J AZ CD Pickup Lens Cleaner Disc
CP-XL60H
SPEAKER BOX PARTS
GBOXS0003SJZZ J BF Speaker Ass’y,Left/Right
701 HSY093SPK010 J Front Panel Ass’y
702 HSY093SPK020 J Net Frame Ass’y
703 HSY093SPK030 J Speaker Box Ass’y
704 9GDHSY041SPK04 J AK Spacer Board
705 9GDHSY042SPK03 J AH Duct Pipe
706 9GDHSY041SPK06 J AK Cord,Speaker
707 9GDHSY041SPK08 J AG Screw,ø4×16mm
708 HSY093SPK040 J Label,Specifications
709 PGUMM0001SJSB J Net Catcher
SP601,602 VSPA010PB054N J Speaker,Woofer
SP603,604 RALMB0001SJZZ J AH Speaker,Tweeter
PACKING PARTS
SPAKA0035SJZZ J Speaker Add. [Europe Only]
SPAKC0089SJZZ J Packing Case [Europe Only]
SPAKP0006SJZZ J Polyethylene Bag,Speaker
[For Europe]
SPAKZ0011SJZZ J Bottom Pad,Speaker
[Europe Only]
SPAKZ0012SJZZ J Center Pad,Speaker
[Europe Only]
1 9GDHSY041SPK10 J AE Polyethylene Bag,Speaker
[For U.K.]
2 SPAKA0045SJZZ J PackingAdd.,Top/Bottom,
Speaker [U.K. Only]
SPEAKER BOX PARTS
701 HSY094SPK010 J AP Net Frame Ass’y
702 HSY094SPK020 J AK Speaker Box Ass’y
703 9GDHSY042SPK03 J AH Duct Pipe
704 PGUMM0002SJSA J Net Catcher
705 HDECQ0035SJSA J Ring,Woofer
706 9GDHSY042SPK07 J AG Capacitor,3.3 µF,50V
707 LX-MZ0003SJFN J Screw,ø4×20mm
708 LX-MZ0002SJFN J AH Screw,ø3×12mm
709 HSY094SPK030 J AD Label,Specifications
710 9GDHSY042SPK09 J AG Absorber
711 9GDHSY041SPK06 J AK Speaker Cord A
712 9GDHSY042SPK05 J AG Speaker Cord B
SP601,602 VSPA010WB064N J AX Speaker,Woofer
SP603,604 VSP00DMTB194N J AX Speaker,Tweeter
PACKING PARTS
SPAKA0035SJZZ J Speaker Add. [Europe Only]
SPAKC0089SJZZ J Packing Case [Europe Only]
SPAKP0006SJZZ J Polyethylene Bag,Speaker
[For Europe]
SPAKZ0011SJZZ J Bottom Pad,Speaker
[Europe Only]
SPAKZ0012SJZZ J Center Pad,Speaker
[Europe Only]
1 9GDHSY041SPK10 J AE Polyethylene Bag,Speaker
[For U.K.]
2 SPAKA0047SJZZ J Packing Add.,Top/Bottom,
Speaker [U.K. Only]
CP-XL70H
– 6 –
