PRICE
RANK
DESCRIPTIONNO.
PARTS CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
XL-60H/70H
– 5 –
SW718 QSW-K0002SJZZ J AC Switch,Key Type [SURROUND]
SW721 QSW-K0002SJZZ J AC Switch,Key Type
[MEMORY/SET]
SW722 QSW-K0002SJZZ J AC Switch,Key Type
[BASS/TREBLE]
SW723 QSW-K0002SJZZ J AC Switch,Key Type [BAND]
SW724 QSW-K0002SJZZ J AC Switch,Key Type [REC.PAUSE]
SW725 QSW-K0002SJZZ J AC Switch,Key Type [STOP/CLEAR]
SW726 QSW-K0002SJZZ J AC Switch,Key Type
[TUNING DOWN]
SW727 QSW-K0002SJZZ J AC Switch,Key Type [FUNCTION]
SW728 QSW-K0002SJZZ J AC Switch,Key Type
[VOLUME/JOG]
SW730 QSW-K0002SJZZ J AC Switch,Key Type
[CD Lid Open/Close]
SW802 QSW-B0001SJZZ J AG Switch,Lever Type [CD Lid]
SW901(237-7) 9GD640101210 J AE Switch,Leaf Type [Fool Proof]
SW902(237-8) 9GD640101210 J AE Switch,Leaf Type [Cam]
CD MECHANISM PARTS
301 NGERH0586AFZZ J AC Gear,Middle
302 NGERH0587AFZZ J AC Gear,Drive
303 MLEVP1054AFZZ J AC Rail,Guide
304 NSFTM0291AFFW J AD Shaft,Guide
305 PCUSG0613AFZZ J AC Cushion
! 306 DCTRH8004SJ01 J BC Pickup Unit Ass’y
306- 1 ———— — Pickup Unit
(Not Replacement Item)
306- 2 NGERR0043AFZZ J AC Gear,Rack
306- 3 MSPRC0961AFZZ J AA Spring,Rack
307 PCOVP1333AFSA J AF Cover,Mechanism
701 XBSSD26P06000 J AA Screw,ø2.6×6mm
702 XHBSD20P05000 J AA Screw,ø2×5mm
703 XBBSD20P03000 J AA Screw,ø2×3mm
704 LX-WZ1070AFZZ J AA Washer,ø1.5×ø3.8×0.25mm
NM801 RMOTV0409AFM1 J AN Motor with Gear [Sled]
NM802 RMOTV0408AFM3 J AN Motor with Chassis [Spindle]
NSW801 QSW-F9001AWZZ J AE Switch,Push Type [Pickup In]
CABINET PARTS
201 CPNLC1047SJ02 J Front Panel Ass’y [XL-60H]
201 CPNLC1047SJ04 J Front Panel Ass’y [XL-70H]
201- 1 ———— — Front Panel
(Not Replacement Item)
201- 2 JKNBZ0036SJSA J AE Button,Operation B
201- 3 PCOVS3004SJFW J AC Shield Cover
201- 4 PCUSG0003SJZZ J AC Cushion,Leg
201- 5 QCNWN0219SJZZ J AC Lead Wire with Lug
201- 6 GDORF0012SJSA J AH Cassette Holder [XL-60H]
201- 6 GDORF0013SJSA J AH Cassette Holder [XL-70H]
201- 7 HDECP0001SJSA J AF Decoration Plate,LCD Display
201- 8 HDECP0002SJSA J AF Decoration Plate,Cassette
Holder
201- 9 HDECQ0028SJSA J AE LCD Window
201-10 HDECQ0029SJSA J AE Cassette Holder Window
201-11 JKNBZ0035SJSB J AF Button,Operation A
201-12 MSPRD0006SJFJ J AC Spring,Cassette Holder
201-13 LX-EZ0001SJFN J AB Screw,ø2.5×10mm
203 CGERH0001SJ01 J AF Cassette Holder Damper Gear
Ass’y
204 HDECQ0034SJSA J AG Panel,CD Lid [XL-60H]
204 HDECQ0034SJSB J AF Panel,CD Lid [XL-70H]
205 LANGF0021SJFF J AF Bracket,CD Lid
206 MSPRC0006SJFJ J AB Spring,CD Eject Button
208 HDECQ0033SJSA J AD Ring,JOG Dial Knob
209 JKNBK0025SJSB J AC Knob,JOG Dial
210 GCABC1040SJSA J AK Top Cabinet [XL-60H]
210 GCABC1040SJSB J AK Top Cabinet [XL-70H]
212 GDORT0004SJSA J AG CD Lid [XL-60H]
212 GDORT0004SJSB J AK CD Lid [XL-70H]
214 JKNBZ0040SJSA J AE Button,CD Eject [XL-60H]
214 JKNBZ0040SJSB J AC Button,CD Eject [XL-70H]
216 CHLDM1002SJ01 J AH Stabilizer Ass’y
216- 1 ———— — Stabilizer
(Not Replacement Item)
216- 2 PMAGF0002AWZZ J AE Magnet
217 GITAS0003SJSA J AG Side Panel,Left [XL-60H]
217 GITAS0003SJSB J AK Side Panel,Left [XL-70H]
218 GITAS0004SJSA J AG Side Panel,Right [XL-60H]
218 GITAS0004SJSB J AK Side Panel,Right [XL-70H]
219 TLABS0003SJZZ J AD Label,Class 3A
220 TLABS0004SJZZ J AC Label,Laser
221 GCABB1022SJSB J AG Rear Panel
222 PCOVS3001SJFW J AG Bracket,FM/AM Socket/Video/
AUX/Speaker Terminal
223 LCHSM0004SJFW J AN Main Chassis
224 LANGF0023SJFW J AD Bracket,Sub Transformer
225 LHLDW1001SJZZ J AD Nylon Band
226 QCNWN0148SJZZ J AD Lead Wire with Lug
! 227 QFSHD0001AWZZ J AB Holder,Fuse
228 LANGK0019SJFW J AB Bracket,Display PWB/Main PWB
229 PRDAR0017SJFW J AP Heat Sink,Power Amp. PWB
230 PRDAR0018SJFW J AH Heat Sink,Main PWB
231 PCOVS3003SJFW J AD Shield Cover,Main PWB
232 PSHEP0001SJZZ J AF Sheet,LCD Display
233 LHLDZ1010SJSA J AE Holder,LCD Display
234 LHLDZ1022SJSA J AB Holder,LED
237 CMECB0004SJ01 J BC Tape Mechanism Ass’y
237- 1 94R19210703 J AE Belt,FF/REW
237- 2 9GD19210943 J AG Belt,Main
237- 3 94R192104309 J AG Pinch Roller Arm Ass’y
237- 4(SOL901)9GD19212118 J AP Solenoid Ass’y
237- 5 9GD62161401 J AN Head,Erase
237- 6 94R62010111 J AT Head,Record/Playback
237- 7(SW901) 9GD640101210 J AE Switch,Leaf Type [Fool Proof]
237- 8(SW902) 9GD640101210 J AE Switch,Leaf Type [Cam]
237- 9(M901) 9GD192112344 J AY Motor with Pulley [Tape]
237-10(PWB-D) 9GD192121303 J AZ Tape Mechanism PWB Ass’y
237-11(PWB-E) 9GD192121304 J AW Tape Mechanism PWB Ass’y
238 QCNWN0147SJZZ J AC Lead Wire with Lug
240 LHLDZ1023SJZZ J AD Holder,JOG Motor
241 LHLDZ1024SJZZ J AC Holder,JOG Motor Tray
242 LHLDZ1026SJZZ J AC Holder,JOG Motor Guide
243 NBLTK0001SJZZ J AA Belt,JOG Motor
244 NGERW0001SJZZ J AD Gear,Worm,JOG Motor
245 NGERW0002SJZZ J AD Wheel,JOG Worm
246 NPLYP0001SJZZ J AB Pulley,JOG Motor
247 PCOVU9001SJZZ J AC Sheet,JOG Motor Guide Holder
248 LANGF0011SJZZ J AD Bracket,Heat Sink,
Power Amp. PWB
249 LANGT0001SJFW J AD Bracket,Power Amp.
PWB/Main PWB
250 PCOVP1001SJSB J AG Cover,Heat Sink,
Power Amp. PWB
251 NPLYP0001SJZZ J AB Pulley,CD Lid Motor
252 LHLDZ1031SJZZ J AE Holder,CD Lid Motor
253 NBLTK0002SJZZ J AC Belt,CD Lid Motor
254 NGERW0001SJZZ J AD Gear,Worm,CD Lid Motor
255 NGERW0003SJZZ J AD Gear,CD Lid Motor Worm Gear
256 TSPC-0107SJZZ J AC Label,Specifications
[XL-60H for Europe]
256 TSPC-0108SJZZ J AC Label,Specifications
[XL-60H for U.K.]
256 TSPC-0111SJZZ J AC Label,Specifications
[XL-70H for Europe]
256 TSPC-0112SJZZ J AC Label,Specifications
[XL-70H for U.K.]
257 TLABN0070SJZZ J AC Label,Serial No. [XL-60H]
257 TLABN0072SJZZ J Label,Serial No. [XL-70H]
601 XEBSD25P10000 J AA Screw,ø2.5×10mm
603 XEBSF25P08000 J AA Screw,ø2.5×8mm
604 XJBSD30P08000 J AA Screw,ø3×8mm
605 LX-JZ0001SJFD J AA Screw,ø3×10mm
608 XHBSD20P05000 J AA Screw,ø2×5mm
609 XEBSD25P14000 J AA Screw,ø2.5×14mm
610 XESSD25P12000 J Screw,ø2.5×12mm
611 XESSD30P10000 J AA Screw,ø3×10mm
612 XHBSD30P06000 J AA Screw,ø3×6mm
613 XJBSF30P10000 J AA Screw,ø3×10mm
614 XJBSD30P10000 J AA Screw,ø3×10mm
615 LX-EZ0001SJFN J AB Screw,ø2.5×10mm
616 XEBSF25P10000 J AC Screw,ø2.5×10mm
617 XHBSD40P06000 J AA Screw,ø4×6mm
To Next Page
