Sharp XL-60H Service Manual

NO.
PRICE
RANK
DESCRIPTIONPARTS CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
XL-60H/70H
– 4 –
R701 VRD-ST2CD103J J AA 10 kohm,1/6W
R702 VRS-TV2AB103J J AA 10 kohm,1/10W
R705 VRD-ST2CD562J J AA 5.6 kohms,1/6W
R706 VRD-ST2CD392J J AA 3.9 kohms,1/6W
R707 VRD-ST2CD272J J AA 2.7 kohms,1/6W
R708 VRS-TV2AB222J J AA 2.2 kohms,1/10W
R709 VRD-ST2CD152J J AA 1.5 kohms,1/6W
R710,711 VRS-TV2AB122J J AA 1.2 kohms,1/10W
R714 VRD-ST2CD562J J AA 5.6 kohms,1/6W
R715 VRD-ST2CD392J J AA 3.9 kohms,1/6W
R716 VRD-ST2CD272J J AA 2.7 kohms,1/6W
R717 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R718 VRD-ST2CD152J J AA 1.5 kohms,1/6W
R719,720 VRD-ST2CD122J J AA 1.2 kohms,1/6W
R721,722 VRS-TV2AB103J J AA 10 kohm,1/10W
R723 VRS-TV2AB473J J AA 47 kohms,1/10W
R724 VRS-TV2AB122J J AA 1.2 kohms,1/10W
R725 VRS-TV2AB103J J AA 10 kohm,1/10W
R727 VRS-TV2AB473J J AA 47 kohms,1/10W
R728 VRS-TV2AB102J J AA 1 kohm,1/10W
R729 VRS-TV2AB473J J AA 47 kohms,1/10W
R730~735 VRS-TV2AB102J J AA 1 kohm,1/10W
R737~746 VRS-TV2AB102J J AA 1 kohm,1/10W
R747~749 VRD-ST2CD102J J AA 1 kohm,1/6W
R750,751 VRS-TV2AB102J J AA 1 kohm,1/10W
R752 VRD-ST2CD102J J AA 1 kohm,1/6W
R753,754 VRS-TV2AB102J J AA 1 kohm,1/10W
R755 VRD-ST2CD102J J AA 1 kohm,1/6W
R757~777 VRS-TV2AB102J J AA 1 kohm,1/10W
R778~781 VRS-TV2AB473J J AA 47 kohms,1/10W
R782,783 VRS-TV2AB333J J AA 33 kohms,1/10W
R784 VRD-ST2CD473J J AA 47 kohms,1/6W
R785 VRS-TV2AB102J J AA 1 kohm,1/10W
R786 VRD-ST2CD473J J AA 47 kohms,1/6W
R787 VRD-RT2HD2R2J J AA 2.2 ohms,1/2W
R789 VRD-ST2CD473J J AA 47 kohms,1/6W
R792 VRD-ST2CD473J J AA 47 kohms,1/6W
R793 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R794~797 VRD-ST2CD181J J AA 180 ohms,1/6W
R798 VRD-ST2CD822J J AA 8.2 kohms,1/6W
R799 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R801 VRD-ST2CD103J J AA 10 kohm,1/6W
R802 VRS-TV2AB473J J AA 47 kohms,1/10W
R804 VRS-TV2AB104J J AA 100 kohm,1/10W
R806 VRS-TV2AB153J J AA 15 kohms,1/10W
R807 VRS-TV2AB103J J AA 10 kohm,1/10W
R808 VRS-TV2AB332J J AA 3.3 kohms,1/10W
R809 VRS-TV2AB103J J AA 10 kohm,1/10W
R810 VRS-TV2AB332J J AA 3.3 kohms,1/10W
R811 VRS-TV2AB222J J AA 2.2 kohms,1/10W
R812 VRS-TV2AB332J J AA 3.3 kohms,1/10W
R813 VRD-ST2EE100J J AA 10 ohm,1/4W
R814 VRS-TV2AB332J J AA 3.3 kohms,1/10W
R815,816 VRD-ST2CD103J J AA 10 kohm,1/6W
R817,818 VRS-TV2AB102J J AA 1 kohm,1/10W
R819 VRD-ST2CD221J J AA 220 ohms,1/6W
R820 VRS-TV2AB102J J AA 1 kohm,1/10W
R821 VRD-ST2CD151J J AA 150 ohms,1/6W
R822 VRD-ST2EE220J J AA 22 ohms,1/4W
R823 VRD-ST2CD102J J AA 1 kohm,1/6W
R824 VRS-TV2AB273J J AA 27 kohms,1/10W
R825 VRS-TV2AB823J J AA 82 kohms,1/10W
R826 VRS-TV2AB272J J AA 2.7 kohms,1/10W
R827 VRS-TV2AB273J J AA 27 kohms,1/10W
R828 VRS-TV2AB122J J AA 1.2 kohms,1/10W
R829 VRD-ST2CD683J J AA 68 kohms,1/6W
R843 VRD-ST2CD102J J AA 1 kohm,1/6W
R851 VRD-ST2CD331J J AA 330 ohms,1/6W
R852~855 VRS-TV2AB104J J AA 100 kohm,1/10W
R861~863 VRS-TV2AB222J J AA 2.2 kohms,1/10W
R872 VRD-RT2HD2R2J J AA 2.2 ohms,1/2W
R873 VRD-ST2CD562J J AA 5.6 kohms,1/6W
R874 VRS-TV2AB222J J AA 2.2 kohms,1/10W
R876 VRS-TV2AB154J J AA 150 kohms,1/10W
R877 VRS-TV2AB683J J AA 68 kohms,1/10W
R880 VRS-TV2AB473J J AA 47 kohms,1/10W
R901 VRD-ST2CD152J J AA 1.5 kohms,1/6W
R902 VRD-ST2CD563J J AA 56 kohms,1/6W
R903 VRS-TV2AB473J J AA 47 kohms,1/10W
R904 VRS-TV2AB271J J AA 270 ohms,1/10W
R905 VRS-TV2AB103J J AA 10 kohm,1/10W
R906 VRD-ST2CD152J J AA 1.5 kohms,1/6W
R907 VRD-ST2CD103J J AA 10 kohm,1/6W
R909 VRS-TV2AB183J J AA 18 kohms,1/10W
R910 VRS-TV2AB333J J AA 33 kohms,1/10W
OTHER CIRCUITRY PARTS
BI605/CNS605 QCNWN0179SJZZ J AF Connector Ass’y,7/7Pin
BI651/CNS651 QCNWN0177SJZZ J AC Connector Ass’y,2/2Pin
BI652/CNS652 QCNWN0194SJZZ J AC Connector Ass’y,2/2Pin
BI702/CNS702 QCNWN0181SJZZ J AF Connector Ass’y,13/13Pin
BI706/CNS706 QCNWN0185SJZZ J AC Connector Ass’y,3/3Pin
BI707/CNS707 QCNWN0125SJZZ J AE Connector Ass’y,3/3Pin
BI801/CNS801 QCNWN0186SJZZ J AF Connector Ass’y,8/8Pin
BI802/CNS802 QCNWN0187SJZZ J AE Connector Ass’y,7/7Pin
BI803/CNS803 QCNWN0188SJZZ J AE Connector Ass’y,6/6Pin
BI805/CNS805 QCNWN0189SJZZ J AD Connector Ass’y,3/3Pin
BI901/CNS901 QCNWN0176SJZZ J AE Connector Ass’y,7/7Pin
CFM901 ———— — Flat Wire,2Pin
(Supplies at REF.No.PWB-D)
CFW601 QCNWN0201SJZZ J AB Flat Wire,5Pin
CFW701 QCNWN0200SJZZ J AB Flat Wire,2Pin
CFW704 QCNWN0183SJZZ J AD Flat Wire,12Pin
CFW806 QCNWN0191SJZZ J AB Flat Wire,3Pin
CFW807 QCNWN0182SJZZ J AB Flat Wire,2Pin
CNP101 QCNCM931HAFZZ J AC Plug,8Pin
CNP301 QCNCM602BAFZZ J AA Plug,2Pin
CNP604 QCNCM010NAWZZ J AC Plug,13Pin
CNP605 QCNCM705GAFZZ J AB Plug,7Pin
CNP651 QCNCM998BAFZZ J AC Plug,2Pin
CNP652,653 QCNCM998BAFZZ J AC Plug,2Pin
CNP702 QCNCM004NSJZZ J AC Plug,13Pin
CNP703 QCNCM010MAWZZ J AC Plug,12Pin
CNP705 QCNCM932BAFZZ J AA Plug,2Pin
CNP706 QCNCM932CAFZZ J AA Plug,3Pin
CNP707 QCNCM603CAFZZ J AB Plug,3Pin
CNP803 QCNCM932FAFZZ J AC Plug,6Pin
CNP804 QCNCM931BAFZZ J AA Plug,2Pin
CNP805 QCNCM999CAFZZ J AG Plug,3Pin
CNP901 ———— — Plug,7Pin
(Supplies at REF.No.PWB-D)
CNS101 QCNWN0175SJZZ J AG Connector Ass’y,8Pin
CNS604 QCNCW010NAWZZ J AC Socket,13Pin
CNS703 QCNCW010MAWZZ J AD Socket,12Pin
CNS704 QCNCW623MAFZZ J AC Socket,12Pin
CNS705 QCNWN0184SJZZ J Connector Ass’y,2Pin
CNS804 QCNWN0193SJZZ J AB Connector Ass’y,2Pin
! F651 QFS-C322ASJNI J AF Fuse,T3.15A L 250V
! F652 QFS-C132ASJNI J AH Fuse,T1.25A L 250V
FE301 RTUNS0012AWZZ J AV FM Front End
J601 QJAKM0001SJZZ J AG Jack,Headphones
J801 VHPGP1F32T/-1 J AP Jack,CD Digital Output
LCD701 RV-LX0007SJZZ J AR LCD Display
M701 RMOTV0409AFZZ J AL Motor [JOG]
M801 RMOTV0409AFZZ J AL Motor [CD Lid]
M901(237-9) 9GD192112344 J AY Motor with Pulley [Tape]
NM801 RMOTV0409AFM1 J AN Motor with Gear [Sled]
NM802 RMOTV0408AFM3 J AN Motor with Chassis [Spindle]
NSW801 QSW-F9001AWZZ J AE Switch,Push Type [Pickup In]
PH901 ———— — Photo Interrupter
(Supplies at REF.No.PWB-E)
! RLY601 RRLYD0004SJZZ J AG Relay
RX701 VHLN64H380A-1 J AK Remote Sensor,N64H380A
SO301 QTANC0001SJZZ J AF Socket,FM Antenna
SO401 QSOCJ0003SJZZ J AG Jack,Video/AUX
SO601 QTANA0007SJZZ J AF Terminal,Speaker
! SO651 QSOCA0004SJZZ J AH Socket,AC Power Input
SOL901(237-4) 9GD19212118 J AP Solenoid Ass’y
SW700 QSW-Z0001SJZZ J AF Switch,Push Type [JOG]
SW709 QSW-K0002SJZZ J AC Switch,Key Type
[ON/STAND-BY]
SW710 QSW-K0002SJZZ J AC Switch,Key Type
[CLOCK/TIMER/SLEEP]
SW711 QSW-K0002SJZZ J AC Switch,Key Type [TUNING UP]
SW712 QSW-K0002SJZZ J AC Switch,Key Type
[PLAY/CD PAUSE]
SW713 QSW-K0002SJZZ J AC Switch,Key Type
[VOLUME SELECT]
SW714 QSW-K0002SJZZ J AC Switch,Key Type
[DISPLAY MODE]
SW715 QSW-K0002SJZZ J AC Switch,Key Type [ASPM]
SW716 QSW-K0002SJZZ J AC Switch,Key Type [EON]
SW717 QSW-K0002SJZZ J AC Switch,Key Type [PTY.TI]
