Sharp XL-60H Service Manual

PRICE
RANK
DESCRIPTIONNO.
PARTS CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
XL-60H/70H
– 3 –
C861 VCKYPA1HB102K J AA 0.001 µF,50V
C862 VCKYPA1HB222K J AA 0.0022 µF,50V
C863 VCKYTV1HB471K J AA 470 pF,50V
C871 RC-GZA476AF1C J AB 47 µF,16V,Electrolytic
C872 VCKYTV1EB104K J AA 0.1 µF,25V
C887 VCKYTV1HB272K J AA 0.0027 µF,50V
C901 VCKYTV1HB102K J AA 0.001 µF,50V
C902 RC-GZA335AF1H J AB 3.3 µF,50V,Electrolytic
C903 RC-GZA107AF1E J AB 100 µF,25V,Electrolytic
C904,905 VCKYTV1HF223Z J AA 0.022 µF,50V
RESISTORS
VRS-TV2AB000J J AA 0 ohm,Jumper,1.25×2mm,Green
J920 VRS-TV2AB121J J AA 120 ohms,1/10W
J923 VRS-TV2AB121J J AA 120 ohms,1/10W
R7A0 VRS-TV2AB102J J AA 1 kohm,1/10W
R7A1 VRS-TV2AB102J J AA 1 kohm,1/10W
R7A2 VRS-TV2AB104J J AA 100 kohm,1/10W
R7A3 VRD-ST2EE101J J AA 100 ohm,1/4W
R7A4 VRS-TV2AB121J J AA 120 ohms,1/10W
R7A5 VRS-TV2AB103J J AA 10 kohm,1/10W
R7A6 VRS-TV2AB102J J AA 1 kohm,1/10W
R7A7 VRS-TV2AB102J J AA 1 kohm,1/10W
R7A8 VRS-TV2AB820J J AA 82 ohms,1/10W
R7A9 VRD-ST2CD332J J AA 3.3 kohms,1/6W
R7B0 VRS-TV2AB103J J AA 10 kohm,1/10W
R7B2 VRS-TV2AB473J J AA 47 kohms,1/10W
R7B3 VRS-TV2AB222J J AA 2.2 kohms,1/10W
R7D1 VRS-TV2AB820J J AA 82 ohms,1/10W
R7D2 VRS-TV2AB820J J AA 82 ohms,1/10W
R7D3 VRS-TV2AB820J J AA 82 ohms,1/10W
R7D4 VRS-TV2AB820J J AA 82 ohms,1/10W
R7D5 VRS-TV2AB820J J AA 82 ohms,1/10W
R7D6 VRS-TV2AB820J J AA 82 ohms,1/10W
R7D8 VRS-TV2AB820J J AA 82 ohms,1/10W
R7D9 VRS-TV2AB820J J AA 82 ohms,1/10W
R7E1 VRS-TV2AB820J J AA 82 ohms,1/10W
R80A VRS-TV2AB823J J AA 82 kohms,1/10W
R80B VRS-TV2AB683J J AA 68 kohms,1/10W
R80C VRS-TV2AB823J J AA 82 kohms,1/10W
R80E VRD-ST2CD823J J AA 82 kohms,1/6W
R80F VRS-TV2AB823J J AA 82 kohms,1/10W
R80G VRD-ST2CD683J J AA 68 kohms,1/6W
R101,102 VRD-ST2CD102J J AA 1 kohm,1/6W
R103,104 VRS-TV2AB121J J AA 120 ohms,1/10W
R105 VRS-TV2AB154J J AA 150 kohms,1/10W
R106 VRD-ST2CD154J J AA 150 kohms,1/6W
R107 VRD-ST2CD103J J AA 10 kohm,1/6W
R108 VRS-TV2AB103J J AA 10 kohm,1/10W
R109,110 VRS-TV2AB392J J AA 3.9 kohms,1/10W
R111,112 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R113,114 VRS-TV2AB332J J AA 3.3 kohms,1/10W
R115,116 VRS-TV2AB153J J AA 15 kohms,1/10W
R117,118 VRS-TV2AB223J J AA 22 kohms,1/10W
R119,120 VRS-TV2AB101J J AA 100 ohm,1/10W
R121~124 VRS-TV2AB472J J AA 4.7 kohms,1/10W
R125 VRS-TV2AB104J J AA 100 kohm,1/10W
R126 VRS-TV2AB562J J AA 5.6 kohms,1/10W
R131 VRD-ST2CD472J J AA 4.7 kohms,1/6W
R132 VRS-TV2AB472J J AA 4.7 kohms,1/10W
R133 VRS-TV2AB102J J AA 1 kohm,1/10W
R134 VRS-TV2AB104J J AA 100 kohm,1/10W
R138 VRD-ST2EE331J J AA 330 ohms,1/4W
R139 VRD-ST2CD272J J AA 2.7 kohms,1/6W
R140 VRS-TV2AB103J J AA 10 kohm,1/10W
R141 VRD-ST2CD331J J AA 330 ohms,1/6W
R151 VRS-TV2AB473J J AA 47 kohms,1/10W
R152 VRS-TV2AB104J J AA 100 kohm,1/10W
R153,154 VRS-TV2AB103J J AA 10 kohm,1/10W
R155 VRD-ST2EE560J J AA 56 ohms,1/4W
R156,157 VRD-ST2EE151J J AA 150 ohms,1/4W
R201 VRD-ST2CD822J J AA 8.2 kohms,1/6W
R202 VRS-TV2AB822J J AA 8.2 kohms,1/10W
R203,204 VRS-TV2AB104J J AA 100 kohm,1/10W
R205,206 VRS-TV2AB103J J AA 10 kohm,1/10W
R207 VRD-ST2CD473J J AA 47 kohms,1/6W
R208 VRD-ST2EE331J J AA 330 ohms,1/4W
R209 VRS-TV2AB103J J AA 10 kohm,1/10W
R210 VRD-ST2CD103J J AA 10 kohm,1/6W
R211 VRS-TV2AB272J J AA 2.7 kohms,1/10W
R212 VRD-ST2CD272J J AA 2.7 kohms,1/6W
R213~216 VRS-TV2AB123J J AA 12 kohms,1/10W
R217 VRD-ST2CD123J J AA 12 kohms,1/6W
R218 VRS-TV2AB122J J AA 1.2 kohms,1/10W
R323 VRS-TV2AB683J J AA 68 kohms,1/10W
R336 VRD-ST2CD103J J AA 10 kohm,1/6W
R343 VRD-ST2CD181J J AA 180 ohms,1/6W
R344 VRS-TV2AB681J J AA 680 ohms,1/10W
R345 VRS-TV2AB472J J AA 4.7 kohms,1/10W
R346 VRD-ST2CD331J J AA 330 ohms,1/6W
R347 VRS-TV2AB682J J AA 6.8 kohms,1/10W
R348 VRS-TV2AB681J J AA 680 ohms,1/10W
R349 VRS-TV2AB330J J AA 33 ohms,1/10W
R350 VRS-TV2AB272J J AA 2.7 kohms,1/10W
R351 VRS-TV2AB562J J AA 5.6 kohms,1/10W
R352 VRS-TV2AB102J J AA 1 kohm,1/10W
R353 VRS-TV2AB271J J AA 270 ohms,1/10W
R355 VRS-TV2AB332J J AA 3.3 kohms,1/10W
R356 VRS-TV2AB102J J AA 1 kohm,1/10W
R357 VRS-TV2AB474J J AA 470 kohms,1/10W
R358 VRS-TV2AB822J J AA 8.2 kohms,1/10W
R359 VRS-TV2AB182J J AA 1.8 kohms,1/10W
R360 VRS-TV2AB472J J AA 4.7 kohms,1/10W
R361,362 VRS-TV2AB123J J AA 12 kohms,1/10W
R363 VRD-ST2CD682J J AA 6.8 kohms,1/6W
R364 VRS-TV2AB682J J AA 6.8 kohms,1/10W
R365 VRS-TV2AB103J J AA 10 kohm,1/10W
R366 VRS-TV2AB222J J AA 2.2 kohms,1/10W
R369A VRS-TV2AB680J J AA 68 ohms,1/10W
R369B VRS-TV2AB820J J AA 82 ohms,1/10W
R371~374 VRS-TV2AB102J J AA 1 kohm,1/10W
R376 VRD-ST2CD103J J AA 10 kohm,1/6W
R377 VRD-ST2CD562J J AA 5.6 kohms,1/6W
R379 VRS-TV2AB222J J AA 2.2 kohms,1/10W
R380 VRD-ST2CD152J J AA 1.5 kohms,1/6W
R381 VRS-TV2AB103J J AA 10 kohm,1/10W
R382 VRD-ST2EE331J J AA 330 ohms,1/4W
R383 VRS-TV2AB562J J AA 5.6 kohms,1/10W
R384 VRD-ST2CD682J J AA 6.8 kohms,1/6W
R385 VRD-ST2CD562J J AA 5.6 kohms,1/6W
R386 VRD-ST2EE331J J AA 330 ohms,1/4W
R387 VRD-ST2CD562J J AA 5.6 kohms,1/6W
R391,392 VRD-ST2EE391J J AA 390 ohms,1/4W
R393 VRS-TV2AB102J J AA 1 kohm,1/10W
R395 VRD-ST2CD473J J AA 47 kohms,1/6W
R405,406 VRS-TV2AB273J J AA 27 kohms,1/10W
R407,408 VRS-TV2AB152J J AA 1.5 kohms,1/10W
R415~425 VRS-TV2AB102J J AA 1 kohm,1/10W
R435,436 VRS-TV2AB103J J AA 10 kohm,1/10W
R437,438 VRS-TV2AB682J J AA 6.8 kohms,1/10W
R439,440 VRS-TV2AB392J J AA 3.9 kohms,1/10W
R521 VRD-ST2CD473J J AA 47 kohms,1/6W
R528,529 VRD-ST2CD102J J AA 1 kohm,1/6W
R532 VRS-TV2AB103J J AA 10 kohm,1/10W
R533,534 VRD-ST2CD563J J AA 56 kohms,1/6W
R601,602 VRD-ST2CD102J J AA 1 kohm,1/6W
R603,604 VRD-ST2CD103J J AA 10 kohm,1/6W
R605,606 VRD-ST2CD820J J AA 82 ohms,1/6W
R607 VRD-ST2CD682J J AA 6.8 kohms,1/6W
R608 VRD-ST2CD102J J AA 1 kohm,1/6W
R609,610 VRD-ST2EE3R3J J AA 3.3 ohms,1/4W
R613,614 VRD-RT2HD271J J AA 270 ohms,1/2W
R615,616 VRD-ST2CD472J J AA 4.7 kohms,1/6W
R617 VRS-TV2AB333J J AA 33 kohms,1/10W
R619,620 VRD-ST2EE470J J AA 47 ohms,1/4W
R621 VRS-TV2AB223J J AA 22 kohms,1/10W
R623 VRS-TV2AB223J J AA 22 kohms,1/10W
R624 VRD-ST2EE102J J AA 1 kohm,1/4W
R625 VRS-TV2AB103J J AA 10 kohm,1/10W
R627 VRS-TV2AB103J J AA 10 kohm,1/10W
R628 VRD-ST2EE101J J AA 100 ohm,1/4W
R629 VRD-ST2EE821J J AA 820 ohms,1/4W
R631,632 VRD-ST2EE6R8J J AA 6.8 ohms,1/4W
R633 VRD-ST2EE100J J AA 10 ohm,1/4W
R634 VRD-ST2EE332J J AA 3.3 kohms,1/4W
R651 VRS-VV3LA681J J AC 680 kohms,3W,Metal Oxide Film
R661,662 VRD-ST2EE331J J AA 330 ohms,1/4W
R681 VRD-ST2CD470J J AA 47 ohms,1/6W
R682 VRD-ST2CD122J J AA 1.2 kohms,1/6W
R683 VRD-ST2CD470J J AA 47 ohms,1/6W
R684 VRD-ST2CD122J J AA 1.2 kohms,1/6W
R685 VRD-ST2CD103J J AA 10 kohm,1/6W
R686 VRD-ST2CD473J J AA 47 kohms,1/6W

Sharp XL-60H Specifications

General

Brand	Sharp
Model	XL-60H
Category	Stereo System
Language	English
