Sharp XL-60H Service Manual

NO.
PRICE
RANK
DESCRIPTIONPARTS CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
XL-60H/70H
– 2 –
C209 RC-GZA476AF1C J AB 47 µF,16V,Electrolytic
C211,212 VCKYTV1HB332K J AA 0.0033 µF,50V
C213,214 RC-GZA475AF1H J AB 4.7 µF,50V,Electrolytic
C215,216 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C301,302 VCKYTV1HB102K J AA 0.001 µF,50V
C329 VCKYTV1EF223Z J AA 0.022 µF,25V
C330 VCCCPA1HH120J J AA 12 pF (CH),50V
C331 VCKYTV1EF473Z J AB 0.047 µF,25V
C332 VCKYPA1HF223Z J AB 0.022 µF,50V
C334 VCCUPA1HJ270J J AA 27 pF (UJ),50V
C335 VCKYTV1HB561K J AA 560 pF,50V
C337 VCKYPA1HF223Z J AB 0.022 µF,50V
C340 VCKYTV1HB102K J AA 0.001 µF,50V
C341 VCKYTV1EF223Z J AA 0.022 µF,25V
C343,344 VCCSTV1HL330J J AA 33 pF,50V
C345~347 VCKYTV1EF223Z J AA 0.022 µF,25V
C348 RC-GZA107AF1C J AB 100 µF,16V,Electrolytic
C349 VCKYTV1HB102K J AA 0.001 µF,50V
C350,351 VCKYTV1EF223Z J AA 0.022 µF,25V
C352 RC-GZA106AF1C J AB 10 µF,16V,Electrolytic
C353,354 VCKYTV1EF223Z J AA 0.022 µF,25V
C355 VCCSTV1HL220J J AA 22 pF,50V
C356 VCKYTV1HB102K J AA 0.001 µF,50V
C357 RC-GZA225AF1H J AB 2.2 µF,50V,Electrolytic
C358 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C360,361 VCKYTV1EF223Z J AA 0.022 µF,25V
C362 RC-GZA335AF1H J AB 3.3 µF,50V,Electrolytic
C363 VCKYTV1EF223Z J AA 0.022 µF,25V
C364 RC-GZA106AF1C J AB 10 µF,16V,Electrolytic
C365 VCKYTV1EF223Z J AA 0.022 µF,25V
C366 VCKYTV1HB102K J AA 0.001 µF,50V
C367,368 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C369 VCCSTV1HL560J J AA 56 pF,50V
C370~372 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C373,374 VCTYPA1CX153K J AA 0.015 µF,16V
C376 VCKYTV1HB102K J AA 0.001 µF,50V
C380 RC-GZA106AF1C J AB 10 µF,16V,Electrolytic
C381 VCCCTV1HH120J J AA 12 pF (CH),50V
C382 VCCCTV1HH150J J AA 15 pF (CH),50V
C383 VCKYTV1EF223Z J AA 0.022 µF,25V
C384 VCKYTV1HB102K J AA 0.001 µF,50V
C385 VCTYPA1CX103K J AA 0.01 µF,16V
C386 VCKYPA1HB331K J AA 330 pF,50V
C387 VCKYTV1EF223Z J AA 0.022 µF,25V
C391 RC-GZA476AF1C J AB 47 µF,16V,Electrolytic
C392 VCKYTV1HB102K J AA 0.001 µF,50V
C393 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C394 RC-GZA476AF1C J AB 47 µF,16V,Electrolytic
C395 VCKYTV1EF223Z J AA 0.022 µF,25V
C396 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
C397 VCKYTV1EF223Z J AA 0.022 µF,25V
C398 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
C399 VCKYPA1HF223Z J AB 0.022 µF,50V
C401~408 RC-GZA106AF1C J AB 10 µF,16V,Electrolytic
C411,412 VCKYTV1HB331K J AA 330 pF,50V
C415,416 RC-GZA106AF1C J AB 10 µF,16V,Electrolytic
C417,418 RC-GZA225AF1H J AB 2.2 µF,50V,Electrolytic
C419,420 VCKYTV1HB272K J AA 0.0027 µF,50V
C421~424 RC-QZA104AFYJ J AC 0.1 µF,50V,Mylar
C425,426 RC-GZA106AF1C J AB 10 µF,16V,Electrolytic
C429 RC-GZA336AF1C J AB 33 µF,16V,Electrolytic
C430 RC-GZA107AF1C J AB 100 µF,16V,Electrolytic
C521 RC-GZA106AF1C J AB 10 µF,16V,Electrolytic
C522 VCKYTV1HB331K J AA 330 pF,50V
C523 VCKYTV1EF104Z J AA 0.1 µF,25V
C524 VCKYTV1HB561K J AA 560 pF,50V
C525,526 VCCCTV1HH220J J AA 22 pF (CH),50V
C527 VCKYTV1EF104Z J AA 0.1 µF,25V
C535 RC-GZA476AF1C J AB 47 µF,16V,Electrolytic
C536 VCKYTV1EF223Z J AA 0.022 µF,25V
C537 VCKYPA1HF223Z J AB 0.022 µF,50V
C601 RC-GZA336AF1C J AB 33 µF,16V,Electrolytic
C602 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C603,604 VCKYPA1HB101K J AA 100 pF,50V
C605,606 RC-GZA475AF1E J AB 4.7 µF,25V,Electrolytic
C607,608 RC-GZA227AF1E J AB 220 µF,25V,Electrolytic
C609,610 RC-GZA476AF1H J AB 47 µF,50V,Electrolytic
C611,612 RC-QZA224AFYJ J AB 0.22 µF,50V,Mylar
C613,614 RC-GZV108AF1V J AD 1000 µF,35V,Electrolytic
C615 VCKYPA1HF223Z J AB 0.022 µF,50V
C616 RC-GZW228AF1H J AH 2200 µF,50V,Electrolytic
C617,618 VCKYPA1HB222K J AA 0.0022 µF,50V
C620 RC-GZV477AF1E J AC 470 µF,25V,Electrolytic
C621 RC-GZA107AF1E J AB 100 µF,25V,Electrolytic
C622 VCKYPA1HF223Z J AB 0.022 µF,50V
C624 VCKYPA1HF223Z J AB 0.022 µF,50V
C625 RC-GZA106AF1C J AB 10 µF,16V,Electrolytic
C626 RC-GZA476AF1C J AB 47 µF,16V,Electrolytic
C627 VCKYTV1EF223Z J AA 0.022 µF,25V
C629 RC-GZV227AF1H J AC 220 µF,50V,Electrolytic
C630 RC-GZW478AF1E J AG 4700 µF,25V,Electrolytic
C632,633 VCKYPA1HF223Z J AB 0.022 µF,50V
C636,637 VCKYPA1HF223Z J AB 0.022 µF,50V
C639,640 VCKYPA1HB471K J AA 470 pF,50V
C643,644 RC-QZA224AFYJ J AB 0.22 µF,50V,Mylar
C647 VCKYBT1HB331K J AA 330 pF,50V
C648 VCKYPA1HB122K J AA 0.0012 µF,50V
! C651 VCFYFA1HA104J J AC 0.1 µF,50V,Thin Film
! C654 VCFYFA1HA104J J AC 0.1 µF,50V,Thin Film
! C656~659 VCFYFA1HA104J J AC 0.1 µF,50V,Thin Film
C660 VCKYPA1HF102Z J 0.001 µF,50V
C661~663 VCKYPA1HB821K J AA 820 pF,50V
C683 RC-GZV228AF1C J AG 2200 µF,16V,Electrolytic
C684 VCFYFA1HA473J J AB 0.047 µF,50V,Thin Film
C685 RC-GZA476AF1C J AB 47 µF,16V,Electrolytic
C686 VCKYPA1HF223Z J AB 0.022 µF,50V
C688 VCKYPA1HF223Z J AB 0.022 µF,50V
C689 RC-GZA476AF1C J AB 47 µF,16V,Electrolytic
C693,694 VCKYPA1HB331K J AA 330 pF,50V
C695,696 VCKYPA1HB102K J AA 0.001 µF,50V
C701,702 VCCCTV1HH220J J AA 22 pF (CH),50V
C703,704 VCKYTV1EF223Z J AA 0.022 µF,25V
C710 VCKYTV1EB103K J AA 0.01 µF,25V
C711 RC-GZA335AF1H J AB 3.3 µF,50V,Electrolytic
C712 VCKYTV1EB103K J AA 0.01 µF,25V
C713 RC-GZA106AF1C J AB 10 µF,16V,Electrolytic
C714 VCKYTV1HB561K J AA 560 pF,50V
C715 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
C771 RC-GZA476AF1C J AB 47 µF,16V,Electrolytic
C772 VCKYTV1EB104K J AA 0.1 µF,25V
C773 RC-GZA476AF1C J AB 47 µF,16V,Electrolytic
C801 VCCSPA1HL101J J AA 100 pF,50V
C802 VCKYTV1EB153K J AB 0.015 µF,25V
C803 RC-GZA476AF1A J AB 47 µF,10V,Electrolytic
C804 VCKYTV1EB103K J AA 0.01 µF,25V
C805 VCKYTV1HB272K J AA 0.0027 µF,50V
C806 VCKYTV1HB472K J AA 0.0047 µF,50V
C807 VCKYTV1EB333K J AB 0.033 µF,25V
C809 VCKYTV1HB472K J AA 0.0047 µF,50V
C810 VCKYTV1HB102K J AA 0.001 µF,50V
C811 RC-GZA476AF1A J AB 47 µF,10V,Electrolytic
C812 VCKYTV1EF103Z J AA 0.01 µF,25V
C813 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
C817~819 VCKYTV1EB104K J AA 0.1 µF,25V
C820 VCKYTV1EF103Z J AA 0.01 µF,25V
C821 VCKYTV1EB104K J AA 0.1 µF,25V
C822 RC-GZA227AF1A J AB 220 µF,10V,Electrolytic
C823 VCKYTV1EF103Z J AA 0.01 µF,25V
C824,825 VCKYTV1EB563K J AA 0.056 µF,25V
C826,827 VCCCTV1HH150J J AA 15 pF (CH),50V
C828,829 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
C830 VCKYTV1EB563K J AA 0.056 µF,25V
C831,832 RC-GZA106AF1C J AB 10 µF,16V,Electrolytic
C833,834 VCKYTV1HB471K J AA 470 pF,50V
C835 VCKYTV1EB563K J AA 0.056 µF,25V
C836 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
C837 VCKYTV1HB471K J AA 470 pF,50V
C838 RC-GZA476AF1A J AB 47 µF,10V,Electrolytic
C839 VCCSTV1HL2R0C J AA 2 pF,50V
C840,841 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
C842 RC-GZA476AF1A J AB 47 µF,10V,Electrolytic
C843 VCKYTV1EF104Z J AA 0.1 µF,25V
C844 VCKYTV1HB682K J AA 0.0068 µF,50V
C845 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
C846,847 VCKYTV1EF104Z J AA 0.1 µF,25V
C848 VCCSTV1HL390J J AA 39 pF,50V
C849 VCKYTV1EB563K J AA 0.056 µF,25V
C850 RC-GZA227AF1A J AB 220 µF,10V,Electrolytic
C851 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
C852 VCQYKA1HM222J J AB 0.0022 µF,50V,Mylar
C855 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
C857 RC-GZA476AF1C J AB 47 µF,16V,Electrolytic
C859 RC-GZA477AF1A J AC 470 µF,10V,Electrolytic
C860 VCKYTV1EF104Z J AA 0.1 µF,25V
