XL-DV5/DV50
– 1 –
INTEGRATED CIRCUITS
IC101 VHILM4733TA-1 J AY Power Amp.,LM4733TA
IC201 VHIKIA7805API J AF Voltage Regulator,KIA7805AP
IC202 VHIKIA7812API J AE Voltage Regulator,KIA7812API
IC203 VHILM2576T/-1 J AR Voltage Regulator,M2576T
IC204 VHIAN78L05/-1 J AE Constant Voltage Regulator,
AN78L05
IC301 VHITA7358AP-1 J AG FM Front End,TA7358AP
IC302 VHILC72131/-1 J AP PLL (Tuner),LC72131
IC303 VHILA1832S/-1 J AN FM IF Det./FM Mpx./AM IF,
LA1832S
IC601 VHILC75341M-1 J AM Signal Control,LC75341M
IC602 VHINJM4558D-1 J AH Buffer Amp.,NJM4558D or
AN4558
IC603 VHILC75341M-1 J AM Signal Contro,LC75341M
IC701 RH-IX0058SJZZ J BH System Microcomputer,
IX0058SJ
TRANSISTORS
Q101,102 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q107,108 VS2SC3052F+-1 J AD Silicon,NPN,2SC3052F+
Q109 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q110 VSKRA107M//-1 J AE Digital,PNP,KRA107 M
Q111 VSKRC107M//-1 J AC Digital,NPN,KRC107 M
Q112~115 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q116 VSKRC107M//-1 J AC Digital,NPN,KRC107 M
Q117 VS2SB562-C/-1 J AD Silicon,PNP,2SB562 C
Q118 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q201 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q202 VS2SC535-C/-1 J AC Silicon,NPN,2SC535 C
Q203 VSKTC3200GR-1 J AC Silicon,NPN,KTC3200 GR
Q204 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q205,206 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q207 VS2SC3052F+-1 J AD Silicon,NPN,2SC3052F+
Q208 VS2SA1235F+-1 J AD Silicon,PNP,2SA1235F+
Q213 VS2SB562-C/-1 J AD Silicon,PNP,2SB562 C
Q214 VS2SC3052F+-1 J AD Silicon,NPN,2SC3052F+
Q302 VS2SC535-C/-1 J AC Silicon,NPN,2SC535 C
Q306 VS2SC535-C/-1 J AC Silicon,NPN,2SC535 C
Q351 VSKRC104M//-1 J AC Digital,NPN,KRC104 M
Q360 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q502 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q503 VS2SB562-C/-1 J AD Silicon,PNP,2SB562 C
Q504 VSKTC3203Y/-1 J AC Silicon,NPN,KTC3203 Y
Q505 VSKTA1271Y/-1 J AC Silicon,PNP,KTA1271 Y
Q506,507 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q508 VSKTA1271Y/-1 J AC Silicon,PNP,KTA1271 Y
Q509 VSKTC3203Y/-1 J AC Silicon,NPN,KTC3203 Y
Q511 VSKTC3203Y/-1 J AC Silicon,NPN,KTC3203 Y
Q702 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q703~705 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
DIODES
D104~106 VHD1N4148//-1 J AA Silicon,1N4148
D107 VHD1N4004//-1 J AB Silicon,1N4004
D108 VHD1N4148//-1 J AA Silicon,1N4148
D109~112 VHD1N4004//-1 J AB Silicon,1N4004
D201 VHDTS6B04GM-1 J AP Silicon,TS6B04GM-1
D205 VHDKBP304GM-1 J AF Silicon,KBP304GM-1
D209~213 VHD1N4004//-1 J AB Silicon,1N4004
1 D214~217 VHD1N4004//-1 J AB Silicon,1N4004
D218,219 VHD1N4004//-1 J AB Silicon,1N4004
D231 VHD1N5822//-1 J Silicon,1N5822
D232 VHD1N4004//-1 J AB Silicon,1N4004
D301,302 VHD1N4148//-1 J AA Silicon,1N4148
D305~308 VHD1N4148//-1 J AA Silicon,1N4148
D604,605 VHD1N4148//-1 J AA Silicon,1N4148
D701 VHD1N4004//-1 J AB Silicon,1N4004
D702~705 VHD1N4148//-1 J AA Silicon,1N4148
D706 VHD1N4004//-1 J AB Silicon,1N4004
D708 VHD1N4004//-1 J AB Silicon,1N4004
D710,711 VHD1N4148//-1 J AA Silicon,1N4148
LED701 VHPLP3052A+-1 J AC LED,Red,LP3052A+
VD301 VHCSVC348S/-1 J AK Variable Capacitance,SVC348S
VD302,303 VHCKDV147B/-1 J AH Variable Capacitance,KDV147B
ZD101 VHEDZH06B2+-1 J AB Zener,6.2V,DZH06B2+
ZD201 VHEDZH3001+-1 J AB Zener,30V,DZH3001+
ZD202 VHEDZH06C2+-1 J AB Zener,6.2V,DZH06C2+
ZD351 VHEDZH05C2+-1 J AB Zener,5.1V,DZH05C2+
ZD701 VHEDZH03C3+-1 J AB Zener,3.3V,DZH03C3+
FILTERS
BF301 RFILR0008AWZZ J AE Band Pass Filter
CF302,303 RFILF0004SJZZ J AG FM IF,10.7 MHz
CF351 RFILF0003AWZZ J AK FM IF
CF352 RFILA0003SJZZ J AF AM IF
TRANSFORMERS
1 T201 RTRNPA005SJZZ J BC Power (Main)
1 T202 RTRNP0056SJZZ J AM Power (Sub)
T302 RCILA0007SJZZ J AG AM Antenna
T304 RCILI0005SJZZ J AF FM IF
T306 RCILB0009SJZZ J AG AM OSC.
T351 RCILI0004SJZZ J AF AM IF
COILS
L103 VP-DH100K0000 J AB 10 µH,Choke
L105 VP-DH2R2K0000 J AB 2.2 µH,Peaking
L206 RCILCA001SJZZ J 100 µH
L302 RCILR0003SJZZ J AD FM RF
L303 RCILB0016SJZZ J AD FM OSC.
L351,352 VP-DH101K0000 J AB 100 µH,Choke
L353 VP-DH102K0000 J AB 1 mH,Choke
L502,503 VP-DHR82K0000 J AE 0.82 µH,Choke
L601 VP-DH2R2K0000 J AB 2.2 µH,Peaking
L701~705 VP-DHR82K0000 J AE 0.82 µH,Choke
L901 RCILCA002SJZZ J 10 µH
L902~907 RBLN-A001SJZZ J Ferrite Bead,120 ohms
1 LF201 RCILZ0005SJZZ J AF Line Filter
VARIABLE RESISTORS
VR351 RVR-M0026AWZZ J AC 10 kohm (B),Semi-VR
[FM Mute Level]
VIBRATORS
X351 RCRM-0007SJZZ J AG VCO,456 kHz
X352 RCRSP0003SJZZ J AL Crystal,4.5 MHz
X701 RCRSPA007SJZZ J AE Crystal,32.768 kHz
X702 RCRM-0008SJZZ J AG Ceramic,8 MHz
CAPACITORS
C101,102 VCKYCY1HB221K J AA 220 pF,50V
C104,105 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C106 RC-GZA106AF1H J AB 10 µF,50V,Electrolytic
C107,108 RC-GZA476AF1H J AB 47 µF,50V,Electrolytic
C109 RC-GZA335AF1H J AB 3.3 µF,50V,Electrolytic
C119~121 VCKYCY1HF223Z J AA 0.022 µF,50V
C122,123 VCKYPA1HF223Z J AB 0.022 µF,50V
C124 VCKYCY1HF223Z J AA 0.022 µF,50V
C125 VCFYFA1HA104J J AC 0.1 µF,50V,Thin Film
C126 VCKYCY1HB104K J AD 0.1 µF,50V
C127,128 VCFYFA1HA104J J AC 0.1 µF,50V,Thin Film
C129 VCKYCY1HB104K J AD 0.1 µF,50V
C130 VCFYFA1HA104J J AC 0.1 µF,50V,Thin Film
C131~133 VCKYPA1HB472K J AB 0.0047 µF,50V
C134 RC-GZA336AF1C J AB 33 µF,16V,Electrolytic
C135,136 RC-GZA106AF1H J AB 10 µF,50V,Electrolytic
C137 VCKYPA1HB104K J AC 0.1 µF,50V
C138 VCKYCY1HB104K J AD 0.1 µF,50V
C139 RC-GZA476AF1H J AB 47 µF,50V,Electrolytic
C140 VCKYCY1HB222K J AA 0.0022 µF,50V
C141 RC-GZA335AF1C J AB 3.3 µF,16V,Electrolytic
C142 RC-GZA476AF1C J AB 47 µF,16V,Electrolytic
C162~164 VCKYCY1HB151K J AA 150 pF,50V
C165 VCKYCY1HB472K J AA 0.0047 µF,50V
C167 VCKYCY1HB472K J AA 0.0047 µF,50V
C169 VCKYCY1HB472K J AA 0.0047 µF,50V
C171 VCKYCY1HB221K J AA 220 pF,50V
C201 RC-GZA107AF1C J AB 100 µF,16V,Electrolytic
C202 VCKYPA1HF223Z J AB 0.022 µF,50V
