Sharp XL-HP515 - Page 13

XL-HP515
3 – 4
Figure 4
Figure 5
Figure 6
(G1) x1
ø3x6mm
(H1) x4
ø4x6mm
(J1) x1
ø3x6mm
(G2) x2
(G2) x2
Terminal PWB
Main PWB
Power PWB
(K2) x8
ø2.6x8mm
(L1) x4
ø3x10mm
(M1) x1
ø3x10mm
(K3) x1
(K1) x1
Front Panel
Headphones
PWB
Cassette
Holder
Display PWB
Tape
Mechanism
(N1) x2
ø3x10mm
(N2) x2
(N3) x1
(P1) x2
ø3x10mm
(P1) x2
ø3x10mm
CD Changer
Unit
CD Servo PWB
Figure 7
STEP REMOVAL PROCEDURE FIGURE
Woofer/
Tweeter
1. Net Frame................(A1) x1
2. Catching Holder.......(A2) x4
3. Screw.......................(A3) x4
4. Front Panel..............(A4) x1
5. Screw.......................(A5) x6
8
Figure 8
(P2) x4
ø2.6x10mm
CD Changer
Unit
CD Mechanism
Net Frame
(A1)x1
Screwdriver
(A5)x2
ø3.5x14mm
(A3)x2
ø3.5x16mm
(A2)x2
(A2)x2
(A3)x2
ø3.5x16mm
(A5)x4
ø3.5x14mm
Woofer
Front Panel
(A4)x1
Tweeter
