PRICE
RANK
DESCRIPTION
NO.
PART CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
XL-HP700
INTEGRATED CIRCUITS
IC1 VHILC78646E-1 J AY CD Servo,LC78646E
IC2 VHIM63001FP-1 J AX Focus/Tracking/Spin/Sled Driver,
M63001FP
IC101 VHIAN7345K/-1 J AM Playback and Record/Playback
Amp.,AN7345K
IC301 VHITA7358AP-1 J AG FM Front End,TA7358AP
IC302 VHILC72131/-1 J AP PLL (Tuner),LC72131
IC303 VHILA1832S/-1 J AN FM IF Det./FM Mpx./AM IF,
LA1832S
IC601 VHILC75341/-1 J AM Audio Processor,LC75341
IC701 RH-IX0578AWZZ J AX System Microcomputer,
IX0578AW
IC851 VHIKIA7812AP1 J AF Constant Voltage Regulator,
KIA7812AP
IC852 VHIKIA7810AP1 J AF Constant Voltage Regulator,
KIA7810AP
IC853 VHIKIA7805AP1 J AF Constant Voltage Regulator,
KIA7805AP
IC854 VHIAN78L05/-1 J AE Constant Voltage Regulator,
AN78L05
IC901 VHISTK40212S1 J BB Power Amp.,STK402-120
TRANSISTORS
IC855 VSKTC2026//-1 J AF Silicon,NPN,KTC2026
Q1 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q2 VSKTC3203Y/-1 J AC Silicon,NPN,KTC3203 Y
Q101~104 VS2SC1845F/-1 J AC Silicon,NPN,2SC1845 F
Q105~108 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q109 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q110 VSKRC104M//-1 J AC Digital,NPN,KRC104 M
Q111 VSKTC3203Y/-1 J AC Silicon,NPN,KTC3203 Y
Q112 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q113,114 VSKRC104M//-1 J AC Digital,NPN,KRC104 M
Q302 VSKTC3194Y/-1 J AD Silicon,NPN,KTC3194 Y
Q360,361 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q500 VSKTA1273Y/-1 J AE Silicon,PNP,KTA1273 Y
Q501 VSKTA1271Y/-1 J AC Silicon,PNP,KTA1271 Y
Q601~604 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q701 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q702 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q801 VSKTA1274Y/-1 J AE Silicon,PNP,KTA1274 Y
Q841 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q901~905 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q906 VSKTC3203Y/-1 J AC Silicon,NPN,KTC3203 Y
DIODES
D301~305 VHDDS1SS133-1 J AB Silicon,DS1SS133
D500 VHDDS1SS133-1 J AB Silicon,DS1SS133
D701 VHDDS1SS133-1 J AB Silicon,DS1SS133
D703 VHDDS1SS133-1 J AB Silicon,DS1SS133
D705~709 VHDDS1SS133-1 J AB Silicon,DS1SS133
D802 VHDTS6B04GM-1 J AP Silicon,TS6B04GM-1
D803~806 VHDGD1N4004-1 J AB Silicon,GD1N4004
D842~845 VHDGD1N4004-1 J AB Silicon,GD1N4004
D846 VHDDS1SS133-1 J AB Silicon,DS1SS133
D851~853 VHDDS1SS133-1 J AB Silicon,DS1SS133
D855~859 VHDDS1SS133-1 J AB Silicon,DS1SS133
D860 VHDGD1N4004-1 J AB Silicon,GD1N4004
D905~907 VHDDS1SS133-1 J AB Silicon,DS1SS133
D911,912 VHDDS1SS133-1 J AB Silicon,DS1SS133
LED701 VHPSLR342VCJ1 J AC LED,Red,SLR342VC
VD301 VHCSVC348S/-1 J AK Variable Capacitance,SVC348S
VD302,303 VHCSVC211C/-1 J AG Silicon,SVC211C,Variable Cap
ZD1 VHEDZ3R3BSB-1 J AB Zener,3.3V,DZ3.3BSB
ZD2 VHEDZ3R9BSB-1 J AC Zener,3.9V,DZ3.9BSB
ZD351 VHEDZ5R1BSB-1 J AC Zener,5.1V,DZ5.1BSB
ZD801 VHEDZ6R2BSA-1 J AB Zener,6.2V,DZ6.2BSA
ZD803 VHEDZ300BSB-1 J AB Zener,30V,DZ300BSB
ZD852 VHEDZ9R1BSB-1 J AB Zener,9.1V,DZ9.1BSB
FILTERS
BF301 RFILR0008AWZZ J AE Band Pass Filter
CF302 RFILF0124AFZZ J AD FM IF,10.7 MHz
CF351 RFILF0003AWZZ J AK FM IF
CF352 RFILA0009AWZZ J AE AM IF
TRANSFORMERS
1 PT801 RTRNP0452AWZZ J BC Power (Main)
1 PT841 RTRNP0483AWZZ J AL Power (Sub)
T301 RCILB0065AWZZ J AC OSC,FM
T302 RCILI0017AWZZ J AB FM IF
T303 RCILA0052AWZZ J AE AM Antenna
T306 RCILB0067AWZZ J AD AM OSC
T351 RCILI0019AWZZ J AD AM IF
COILS
L1 VP-XHR82K0000 J AC 0.82 µH
L103 VP-MK331K0000 J AB 330 µH,Choke
L312 RCILR0056AWZZ J AB FM RF
L351,352 VP-DH101K0000 J AB 100 µH,Choke
L701 VP-DH101K0000 J AB 100 µH,Choke
VIBRATORS
X351 92LCRSTL1425A J AF Crystal,456 kHz
X352 RCRSP0019AWZZ J AF Crystal,4.5 MHz
XL1 RCRM-0047AWZZ J AE Ceramic,16.9344 MHz
XL700 RCRSP0003AWZZ J AH Crystal,4.19403 MHz
CAPACITORS
C1 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
C2 VCTYMN1CY103N J AA 0.01 µF,16V
C3 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
C4 VCKYMN1HB102K J AA 0.001 µF,50V
C5 VCQYKA1HM473K J AB 0.047 µF,50V,Mylar
C6 VCTYPA1CX104K J AB 0.1 µF,16V
C8 VCTYMN1CX272K J AA 0.0027 µF,16V
C9 VCEAZA1AW107M J AB 100 µF,10V,Electrolytic
C10 VCEAZA1HW106M J AB 10 µF,50V,Electrolytic
C11 VCEAZA1HW224M J AB 0.22 µF,50V,Electrolytic
C12 VCKYMN1HB101K J AA 100 pF,50V
C13 VCTYMN1EF223Z J AA 0.022 µF,25V
C14 VCEAZA1AW107M J AB 100 µF,10V,Electrolytic
C16 VCEAZA0JW337M J AC 330 µF,6.3V,Electrolytic
C18 VCEAZA1AW107M J AB 100 µF,10V,Electrolytic
C19 RC-EZ0004AWZZ J AD 3.3 µF,16V,Electrolytic
C22 VCTYMN1CY103N J AA 0.01 µF,16V
C23,24 VCEAZA1HW106M J AB 10 µF,50V,Electrolytic
C25,26 VCQYKA1HM152K J AB 0.0015 µF,50V,Mylar
C27 VCTYMN1EF223Z J AA 0.022 µF,25V
C28 VCKYMN1HB101K J AA 100 pF,50V
C30 VCKYMN1HB101K J AA 100 pF,50V
C32 VCKYMN1HB101K J AA 100 pF,50V
C33 VCTYMN1EF223Z J AA 0.022 µF,25V
C34 VCKYMN1HB101K J AA 100 pF,50V
C35 VCQYKA1HM473K J AB 0.047 µF,50V,Mylar
C36 VCEAZA1HW224M J AB 0.22 µF,50V,Electrolytic
C37 VCTYPA1CX104K J AB 0.1 µF,16V
C38 VCTYMN1CY103N J AA 0.01 µF,16V
C39 VCEAZA1AW107M J AB 100 µF,10V,Electrolytic
C40 VCEAZA0JW227M J AC 220 µF,6.3V,Electrolytic
C41 VCEAZA1AW107M J AB 100 µF,10V,Electrolytic
C42 VCTYMN1CY103N J AA 0.01 µF,16V
C43 VCEAZA1AW107M J AB 100 µF,10V,Electrolytic
C44 VCKYMN1HB102K J AA 0.001 µF,50V
C48 VCTYMN1EF223Z J AA 0.022 µF,25V
C50 VCCCMN1HH220J J AA 22 pF (CH),50V
C51 VCKYPA1HF223Z J AB 0.022 µF,50V
C52,53 VCKYMN1HB102K J AA 0.001 µF,50V
C54,55 VCTYMN1EF223Z J AA 0.022 µF,25V
C59 VCTYPA1CX103K J AA 0.01 µF,16V
C103,104 VCKYMN1HB181K J AA 180 pF,50V
C105,106 VCKYMN1HB561K J AA 560 pF,50V
C109,110 VCKYMN1HB331K J AA 330 pF,50V
C111,112 RC-EZY107AF1C J AB 100 µF,16V,Electrolytic
C113,114 VCTYPA1EX333K J AA 0.033 µF,25V
C115,116 VCKYMN1HB561K J AA 560 pF,50V
C117,118 RC-EZY476AF1E J AB 47 µF,25V,Electrolytic
C121 VCTYMN1EF223Z J AA 0.022 µF,25V
C123,124 VCKYMN1HB271K J AA 270 pF,50V
C125,126 RC-EZY226AF1C J AB 22 µF,16V,Electrolytic
C127,128 VCTYPA1CX223K J AA 0.022 µF,16V
C129,130 VCTYMN1CX332K J AA 0.0033 µF,16V
– 1 –
