Sharp XL-MP10H Service Manual

XL-MP10H
2
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[1] INTEGRATED CIRCUITS
IC101 VHILA4631++-1 AM Power Amp.,LA4631++
IC301 VHILV23002M-1 AS FM FRONT END/PLL (Tuner)/FM IF Det./FM Mpx./AM IF,
IC501 VHIBD3881FV-1 AP Record/Playback Amp.,BD3881FV
IC701 RH-IXA029SJZZ AY System Microcomputer,IXA029SJ
IC801 VHILC78690/-1 Servo/Signal,LC78690
IC802 VHILA6548ND-1 AL Focus/Tracking/Spin/Sled Driver,LA6548ND
[2] TRANSISTORS
Q101 VS2SB1370E+-1 AG Silicon,PNP,2SB1370 E+
Q102 VS2SC3052F+-1 AD Silicon,NPN,2SC3052 F+
Q103 VS2SC3052F+-1 AD Silicon,NPN,2SC3052 F+
Q104 VS2HC1815GR-1 AB Silicon,NPN,2HC1815 GR
Q301 VS2SC3052F+-1 AD Silicon,NPN,2SC3052 F+
Q302 VS2SC5477++-1 AD Silicon,NPN,2SC5477++
Q371 VS2SC5477++-1 AD Silicon,NPN,2SC5477++
Q502 VS2SC5395F+-1 AD Silicon,NPN,2SC5395 F+
Q503 VS2SC3052F+-1 AD Silicon,NPN,2SC3052 F+
Q701 VS2SC3052F+-1 AD Silicon,NPN,2SC3052 F+
Q702 VS2SC5395F+-1 AD Silicon,NPN,2SC5395 F+
Q703 VS2SC5395F+-1 AD Silicon,NPN,2SC5395 F+
Q704 VS2SC3052F+-1 AD Silicon,NPN,2SC3052 F+
Q705 VS2SC3052F+-1 AD Silicon,NPN,2SC3052 F+
Q706 VS2SC3052F+-1 AD Silicon,NPN,2SC3052 F+
Q801 VS2SA1235F+-1 AD Silicon,PNP,2SA1235 F+
Q802 VSKTC3200GR-1 AC Silicon,NPN,KTC3200 GR
Q805 VS2SC3052F+-1 AD Silicon,NPN,2SC3052 F+
Q808 VS2HC1815GR-1 AB Silicon,NPN,2HC1815 GR
Q809 VS2SB562-C/-1 AD Silicon,PNP,2SB562 C
Q810 VS2SB562-C/-1 AD Silicon,PNP,2SB562 C
[3] DIODES
!
D101 VHD1N5395//-1 Silicon,1N5395
!
D102 VHD1N5395//-1 Silicon,1N5395
!
D103 VHD1N5395//-1 Silicon,1N5395
!
D104 VHD1N5395//-1 Silicon,1N5395
D105 VHD1SS133//-1 AA Silicon,1SS133
D106 VHEMTZJ6R8B-1 AC Zener,6.8V,MTZJ6.8B
D107 VHD1N4148//-1 AA Silicon,1N4148
D108 VHD1N4148//-1 AA Silicon,1N4148
D109 VHD1N4148//-1 AA Silicon,1N4148
D110 VHD1N4148//-1 AA Silicon,1N4148
D111 VHD1N4148//-1 AA Silicon,1N4148
D112 VHD1N4148//-1 AA Silicon,1N4148
D302 VHD1SS133//-1 AA Silicon,1SS133
D303 VHD1SS133//-1 AA Silicon,1SS133
D305 VHCSVC347S/-1 AG Variable Capacitance,SVC347S
D306 VHCSVC201//-1 AE Variable Capacitance,SVC201
D307 VHCSVC201//-1 AE Variable Capacitance,SVC201
D308 VHEMTZJ3R6B-1 AC Zener,3.6V,MTZJ3.6B
D309 VHEMTZJ120B-1 AC Zener,12V,MTZJ12B
D310 VHD1N4148//-1 AA Silicon,1N4148
D311 VHD1N4148//-1 AA Silicon,1N4148
D501 VHD1SS133//-1 AA Silicon,1SS133
D701 VHEDZH06B1+-1 Zener,DZH06B1+
D703 VHD1SS133//-1 AA Silicon,1SS133
D704 VHD1SS133//-1 AA Silicon,1SS133
D705 VHD1N4148//-1 AA Silicon,1N4148
D706 VHD1N4148//-1 AA Silicon,1N4148
D707 VHD1N4148//-1 AA Silicon,1N4148
D708 VHD1N4148//-1 AA Silicon,1N4148
D709 VHD1N4148//-1 AA Silicon,1N4148
D710 VHD1N4148//-1 AA Silicon,1N4148
D801 VHD1N4148//-1 AA Silicon,1N4148
D802 VHD1N4148//-1 AA Silicon,1N4148
D803 VHD1N4148//-1 AA Silicon,1N4148
LED701 VHPMPG3372X-V AD LED,Green,MPG3372X
LED702 VHPMPG3372X-V AD LED,Green,MPG3372X
LED703 VHPMPG3372X-V AD LED,Green,MPG3372X
LED704 VHPMPG3372X-V AD LED,Green,MPG3372X
ZD801 VHEDZH05C2+-1 AB Zener,5.1V,DZH05C2+
ZD802 VHEDZH04B2+-1 AB Zener,3.9V,DZH04B2+
[4] FILTERS
CF301 RFILFA001SJZZ AE FM IF
CF302 RFILF0003AWZZ AK FM IF
CF303 RFILA0003SJZZ AF AM IF
CF304 RFILFA001SJZZ AE FM IF
CF306 RFILRA001SJZZ Band Pass Filter
[5] TRANSFORMERS
!
PT1 RTRNPA030SJZZ AW Power
