Sharp XL-MP10H Service Manual

XL-MP10H
3
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[6] COILS
L101 VP-DH1R0K0000 AC 1 µ H
L102 RCILZA001SJZZ AC Line Filter
L103 RCILZA001SJZZ AC Line Filter
!
L104 RCILZ0005SJZZ AF Line Filter
L301 VP-DH1R0K0000 AC 1 µ H
L302 RCILAA002SJZZ AM Antenna
L303 VP-DH100K0000 AB 10 µ H,Choke
L304 RCILRA001SJZZ AA FM RF
L305 RCILIA001SJZZ AC AM IF
L306 RCILBA006SJZZ AM OSC.
L307 RCILBA005SJZZ AD FM OSC.
L308 VP-DH470K0000 AB 47 µ H,Choke
L501 RCILBA001SJZZ AE BIAS OSC.
L502 VP-DHR82K0000 AE 0.82 µ H,Choke
L702 VP-DH2R2K0000 AB 2.2 µ H,Peaking
L703 VP-DH220K0000 AB 22 µ H,Choke
L802 VP-DHR82K0000 AE 0.82 µ H,Choke
L803 VP-DHR82K0000 AE 0.82 µ H,Choke
L804 VP-DHR82K0000 AE 0.82 µ H,Choke
L805 RBLN-A003SJZZ AB Ferrite Bead,1 kohms
L806 RBLN-A003SJZZ AB Ferrite Bead,1 kohms
[7] VIBRATORS
X301 RCRSPA006SJZZ AF Crystal,75 kHz
X702 RCRSP0007SJZZ AE Crystal,32.768 kHz
X801 RCRSP0002SJZZ AL Crystal,16.93 MHz
[8] CAPACITORS
C101 VCKYCY1EF473Z AB 0.047 µ F,25V
C102 VCKYCY1HB472K AA 0.0047 µ F,50V
C103 VCKYCY1HB472K AA 0.0047 µ F,50V
C104 VCKYCY1EF104Z AA 0.1 µ F,25V
C105 VCKYCY1EF104Z AA 0.1 µ F,25V
C106 VCKYCY1HB472K AA 0.0047 µ F,50V
C107 VCKYCY1HB472K AA 0.0047 µ F,50V
C108 VCKYCY1EF104Z AA 0.1 µ F,25V
C109 VCKYCY1EF104Z AA 0.1 µ F,25V
C111 VCKYPA1HB331K AA 330 pF,50V
C112 VCKYCY1HB331K AA 330 pF,50V
!
C113 VCKYCY1EF104Z AA 0.1 µ F,25V
!
C114 VCKYCY1EF104Z AA 0.1 µ F,25V
C115 RC-GZV108AF1E AD 1000 µ F,25V,Electrolytic
C116 RC-GZV108AF1E AD 1000 µ F,25V,Electrolytic
C117 RC-GZA226AF1H AB 22 µ F,50V,Electrolytic
C118 RC-GZW338AF1E AG 3300 µ F,25V,Electrolytic
C119 RC-GZA107AF1C AB 100 µ F,16V,Electrolytic
C120 VCKYCY1EF104Z AA 0.1 µ F,25V
C121 RC-GZA475AF1H AB 4.7 µ F,50V,Electrolytic
C123 RC-GZA105AF1H AB 1 µ F,50V,Electrolytic
C124 VCKYCY1HB103K AA 0.01 µ F,50V
C125 RC-GZA105AF1H AB 1 µ F,50V,Electrolytic
C126 VCKYCY1HB222K AA 0.0022 µ F,50V
C127 VCKYCY1HB222K AA 0.0022 µ F,50V
C128 VCKYCY1EF104Z AA 0.1 µ F,25V
C129 RC-GZA227AF1C AB 220 µ F,16V,Electrolytic
C130 VCKYCY1HB472K AA 0.0047 µ F,50V
C131 VCKYCY1HB472K AA 0.0047 µ F,50V
C132 VCKYCY1HB472K AA 0.0047 µ F,50V
C133 VCKYCY1HB222K AA 0.0022 µ F,50V
C134 VCKYCY1HB222K AA 0.0022 µ F,50V
C140 RC-GZA475AF1H AB 4.7 µ F,50V,Electrolytic
!
C150 VCKYPA1HF472Z AB 0.0047 µ F,50V
C301 VCKYCY1HB102K AA 0.001 µ F,50V
C302 RC-GZA226AF1H AB 22 µ F,50V,Electrolytic
C303 VCKYCY1EF104Z AA 0.1 µ F,25V
C305 VCCCPA1HH120J AA 12 pF (CH),50V
C306 VCKYCY1HB103K AA 0.01 µ F,50V
C307 VCCUPA1HJ7R0D AA 7 pF (UJ),50V
C308 VCKYCY1EB183K AB 0.018 µ F,25V
C309 VCKYPA1HB102J AA 1000 pF,50V
C310 VCCCPA1HH270J AA 27 pF (CH),50V
C311 VCCSPA1HL561J AA 560 pF,50V
C312 VCKYCY1EF104Z AA 0.1 µ F,25V
C313 VCKYCY1EF104Z AA 0.1 µ F,25V
C314 VCKYCY1HB103K AA 0.01 µ F,50V
C315 RC-GZA107AF1H AC 100 µ F,50V,Electrolytic
C316 VCCUPA1HJ330D AA 33 pF (UJ),50V
C317 VCKYPA1HB102J AA 1000 pF,50V
C318 VCKYCY1HB103K AA 0.01 µ F,50V
C319 RC-GZA105AF1H AB 1 µ F,50V,Electrolytic
C320 VCCCCY1HH101J AA 100 pF (CH),50V
C321 RC-GZA334AF1H AA 0.33 µ F,50V,Electrolytic
C322 RC-GZA105AF1H AB 1 µ F,50V,Electrolytic
C323 RC-GZA474AF1H AA 0.47 µ F,50V,Electrolytic
C324 RC-GZA105AF1H AB 1 µ F,50V,Electrolytic
