Sharp XL-MP110E

8
XL-MP110E
Preparation for Use
System connections
RATED SPEAKER IMPEDANCE:
6 OHMS MIN.
AC INPUT
ANTENNA
RIGHT
RIGHT LEFT
FM
75 OHMS
AM
LOOP
VIDEO/AUX
IN
SUBWOOFER
PRE-OUT
SPEAKERS
LEFT
Left speaker
Right speaker
Wall socket
(AC 230 - 240 V, 50 Hz)
Speaker connection (see page 9)
AM loop aerial
FM aerial
Make sure to unplug the AC power lead before any connections.
Aerial connection (see page 9)
AC power connection (see page 10)
