Sharp XL-MP333H Service Manual

XL-MP333H/XL-MP444H
1 – 2
[2] SPECIFICATIONS
FOR A COMPLETE DESCRIPTION OF THE OPERATION OF THIS UNIT, PLEASE REFER
TO THE OPERATION MANUAL.
■ General
■ Amplifier
Power source AC 230 V, 5 0 Hz
Power consumption
XL-MP333H Power on: 48 W
Power stand-by: 0.6 W
XL-MP444H Power on: 90 W
Power stand-by: 0.6 W
Dimensions Width: 160 m m (6-5/16")
Height: 240 mm (9-7/16")
Depth: 300 mm (11-13/16")
Weight
XL-MP333H 4.8 kg (10.6 lbs.)
XL-MP444H 5.9 kg (13.0 lbs.)
Output power
XL-MP333H PMPO: 120 W
MPO: 60 W (30 W + 30 W) (DIN 45 324)
RMS: 40 W (20 W + 20 W) (DIN 45 324)
RMS: 30 W (15 W + 15 W) (DIN 45 500)
XL-MP444H Front speakers:
PMPO: 180 W
MPO: 90 W (45 W + 45 W) (DIN 45 324)
RMS: 60 W (30 W + 30 W) (DIN 45 324)
RMS: 45 W (22.5 W + 22.5 W) (DIN 45 500)
Subwoofer:
PMPO: 120 W
MPO: 60 W (DIN 45 324)
RMS: 40 W (DIN 45 324)
RMS: 30 W (DIN 45 500)
Output terminals Headphones: 16 - 50 ohms
(recommended : 32 ohms)
Video output: RCA type 1
(XL-MP333H)
Speakers: 6 ohms
(XL-MP444H)
Front speakers and subwoofer: 6 ohms
Input terminals Video/Auxiliary (audio signal):
500 mV/47 k ohms
Video input: RCA type 1
USB input: USB type 1
■ CD player
■ Tuner
■ Speaker section
(XL-MP333H)
Speaker
Type 5-disc multi-play compact disc player
Signal readout Non-contact, 3-beam semiconductor laser
pickup
D/A converter 1-bit D/A c onverter
Frequency response 20 - 20,000 Hz
Dynamic range 90 dB (1 kHz)
Frequency range FM:87.5-108MHz
AM: 522 - 1,62 0 kHz
Type 2-way type speaker system
(magnetic shield)
4 cm (1.5") tweeter
10 cm (4") woofer
Maximum input
power
40 W
Rated input power 20 W
Impedance 6 ohms
Dimensions Width: 165 mm (6-1 /2")
Height: 240 mm (9-7/16")
Depth: 210 mm (8-1/4")
Weight 2.4 kg (5.3 lbs.)/each
(XL-MP444H)
Front speaker
Subwoofer
Type 2-way type speaker system
(magnetic shield)
4cm(1.5")tweeter
10 cm (4") woofer
Maximum input
power
60 W
Rated input power 30 W
Impedance 6ohms
Dimensions Width: 165 mm (6-1/2")
Height: 240 mm (9-7/16")
Depth: 210 mm (8-1/4")
Weight 2.4kg(5.3lbs.)/each
Type 13 cm (5-1/8") subwoofer system
(magnetic shield)
Maximum input
power
80 W
Rated input power 40 W
Impedance 6ohms
Dimensions Width: 160 mm (6-5/16")
Height: 240 mm (9-7/16")
Depth: 240 m m (9-7/16")
Weight 2.8 kg (6.2 lbs.)
Specifications for this model are subject to change without prior notice.
