Sharp XL-MP333H Service Manual

XL-MP333H/XL-MP444H
2
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[1] INTEGRATED CIRCUITS
IC101 VHILM4733TA-1 AY Power Amp.,LM4733TA
IC201 VHIKIA7805API AF Voltage Regulator,KIA7805API
IC202 VHIKIA7812API AE Voltage Regulator,KIA7812API
IC203 VHIKIA7808API AF Voltage Regulator,KIA7808API
IC205 VHIAN78L05/-1 AE Constant Voltage Regulator,AN78L05
IC302 VHILC72131/-1 AP PLL (Tuner),LC72131
IC303 VHILA1832S/-1 AN FM IF Det./FM Mpx./AM IF,LA1832S
IC321 VHILC72723M-1 AS RDS Circuit,LC72723M
IC401 VHILC78646E-1 AY CD Servo,LC78646E
IC402 VHILA6568//-1 Focus/Tracking/Spin/Sled Driver,LA6568
IC403 VHILC78684E-1 AZ MP3 DECODER,LC78684E
IC404 VHIK4S16E60-1 DRAM,K4S16E60
IC405 RH-IXA020SJZZ Microcomputer,IXA020SJ
IC601 VHILC75341M-1 AM Signal Control,LC75341M
IC602 VHINJM4558D-1 AH Buffer Amp.,NJM4558D or AN4558 [MP444H Only]
IC603 VHILC75341M-1 AM Signal Control,LC75341M [MP444H Only]
IC701 RH-IX0058SJZZ BH System Microcomputer,IX0058SJ
[2] TRANSISTORS
Q101 VS2SC3052F+-1 AD Silicon,NPN,2SC3052 F+
Q102 VS2SC3052F+-1 AD Silicon,NPN,2SC3052 F+
Q103 VS2SC3052F+-1 AD Silicon,NPN,2SC3052 F+ [MP444H Only]
Q104 VS2SC3052F+-1 AD Silicon,NPN,2SC3052 F+
Q105 VS2SA1235F+-1 AD Silicon,PNP,2SA1235 F+
Q107 VSKTC3199GR-1 AB Silicon,NPN,KTC3199 GR
Q108 VSKTC3199GR-1 AB Silicon,NPN,KTC3199 GR
Q109 VSKTC3199GR-1 AB Silicon,NPN,KTC3199 GR [MP444H Only]
Q110 VSKRA107M//-1 AE Digital,PNP,KRA107 M
Q111 VSKRC107M//-1 AC Digital,NPN,KRC107 M
Q112 VSKTC3199GR-1 AB Silicon,NPN,KTC3199 GR
Q113 VSKTC3199GR-1 AB Silicon,NPN,KTC3199 GR
Q114 VSKTC3199GR-1 AB Silicon,NPN,KTC3199 GR [MP444H Only]
Q201 VSKTA1266GR-1 AB Silicon,PNP,KTA1266 GR
Q202 VS2SC535-C/-1 AC Silicon,NPN,2SC535 C [MP444H Only]
Q203 VSKTC3200GR-1 AC Silicon,NPN,KTC3200 GR [MP444H Only]
Q204 VSKTA1266GR-1 AB Silicon,PNP,KTA1266 GR [MP444H Only]
Q205 VSKTC3199GR-1 AB Silicon,NPN,KTC3199 GR [MP444H Only]
Q209 VSKTC3199GR-1 AB Silicon,NPN,KTC3199 GR
Q301 VS2SC380-O/-1 AC Silicon,NPN,2SC380 O
Q321 VSKTC3199GR-1 AB Silicon,NPN,KTC3199 GR
Q351 VSKRC104M//-1 AC Digital,NPN,KRC104 M
Q360 VSKTA1266GR-1 AB Silicon,PNP,KTA1266 GR
Q401 VS2SC3052F+-1 AD Silicon,NPN,2SC3052 F+
Q402 VS2SC3052F+-1 AD Silicon,NPN,2SC3052 F+
Q403 VS2SC3052F+-1 AD Silicon,NPN,2SC3052 F+
Q404 VS2SC3052F+-1 AD Silicon,NPN,2SC3052 F+
Q405 VS2SA1235F+-1 AD Silicon,PNP,2SA1235 F+
Q406 VS2SC3052F+-1 AD Silicon,NPN,2SC3052 F+
Q413 VS2SB562-C/-1 AD Silicon,PNP,2SB562 C
Q414 VSKTC3199GR-1 AB Silicon,NPN,KTC3199 GR
Q502 VSKRC107M//-1 AC Digital,NPN,KRC107 M
Q503 VS2SB562-C/-1 AD Silicon,PNP,2SB562 C
Q504 VSKTC3203Y/-1 AC Silicon,NPN,KTC3203 Y
Q505 VSKTA1271Y/-1 AC Silicon,PNP,KTA1271 Y
Q506 VSKTC3199GR-1 AB Silicon,NPN,KTC3199 GR
Q507 VSKTC3199GR-1 AB Silicon,NPN,KTC3199 GR
Q508 VSKTA1271Y/-1 AC Silicon,PNP,KTA1271 Y
Q509 VSKTC3203Y/-1 AC Silicon,NPN,KTC3203 Y
Q510 VSKTC3203Y/-1 AC Silicon,NPN,KTC3203 Y
Q511 VSKTC3203Y/-1 AC Silicon,NPN,KTC3203 Y
Q702 VSKRC102M//-1 AC Digital,NPN,KRC102 M
Q703 VSKTC3199GR-1 AB Silicon,NPN,KTC3199 GR
Q704 VSKTC3199GR-1 AB Silicon,NPN,KTC3199 GR
Q705 VSKTC3199GR-1 AB Silicon,NPN,KTC3199 GR
[3] DIODES
D104 VHD1N4004//-1 AB Silicon,1N4004 [MP444H Only]
D105 VHD1N4004//-1 AB Silicon,1N4004 [MP444H Only]
D106 VHD1N4004//-1 AB Silicon,1N4004 [MP444H Only]
D107 VHD1N4004//-1 AB Silicon,1N4004 [MP444H Only]
D108 VHD1N4148//-1 AA Silicon,1N4148
D109 VHD1N4004//-1 AB Silicon,1N4004
D110 VHD1N4004//-1 AB Silicon,1N4004 [MP444H Only]
!
D201 VHDTS6B04GM-1 AP Silicon,TS6B04GM-1
!
D205 VHD1N4004//-1 AB Silicon,1N4004
!
D206 VHD1N4004//-1 AB Silicon,1N4004
!
D207 VHD1N4004//-1 AB Silicon,1N4004
!
D208 VHD1N4004//-1 AB Silicon,1N4004
D209 VHD1N4004//-1 AB Silicon,1N4004
D210 VHD1N4004//-1 AB Silicon,1N4004
D211 VHD1N4004//-1 AB Silicon,1N4004
D212 VHD1N4004//-1 AB Silicon,1N4004
D213 VHD1N4004//-1 AB Silicon,1N4004 [MP444H Only]
D214 VHD1N4004//-1 AB Silicon,1N4004
