XL-MP9H
8 – 5
In this unit, the terminal with asterisk mark (*) is (open) terminal which is not connected to the outside.
60* LRSY Output L L/R ch clock output
61 VVDD2 - - For EFM
PLL
Power supply for built-in VCO
62 VPREF2 Input Input Input for oscillation range setting of built-in VCO.
63 VCOC2 Input Input Input for control voltage setting of built-in VCO.
64 VPDOUT2 Output Unfix Output for controlling built-in VCO.
65 VVSS2 - - GND for built-in VCO. Connected to 0V.
66 DVDD1.8 Output H To power supply capacitor for digital circuit.
67 DVSS - - Digital GND. Connected to 0V.
68 DVDD - - Digital power supply.
69* DOUT Output L Digital OUT output. EIAJ format.
70* AMUTEB Output L AMUTEB (general-purpose) output.
71 XVSS - - Digital GND. Connected to 0V.
72 XOUT Output Oscillator For crystal
oscillation
To 16.9344 MHz oscillator
73 XIN Input Oscillator
74 XVDD - - Digital power supply
75 LCHO Output LRVDD/2 D/A con-
verter
L channel output.
76 LRVDD - - Power supply for LR channel.
77 LRVSS - - GND for LR channel. Connected to 0V.
78 RCHO Output LRVDD/2 R channel output.
79 AVDD - - Analog power supply.
80 SLCO Output Unfix Slice level control output.
Pin No. Terminal Name Input/Output Setting in Reset Function
