Sharp XL-MP9H Service Manual

XL-MP9H
1 – 4
1. Timer Play Indicator
2. MP3 Track Indicator
3. WMA Track Indicator
4. Sleep Indicator
5. Memory Indicator
6. Random Play Indicator
7. Repeat Play Indicator
8. Pause Indicator
9. Play Indicator
10. RDS Indicator
11. Dynamic PTY Indicator
12. FM Stereo Mode Indicator
13. FM Stereo Receiving Indicator
14. Traffic Programme Indicator
15. Traffic Announcement In dicator
16. Full-Range Speaker
17. Bass Reflex Duct
18. Speaker Wire
Notes:
The speaker grilles are not removable.
There is no distinction between the right and the l eft speakers.
16
17
18
1
9
7
8
13
12
23 4 5 6
14
15
10
11
1. Remote Control Transmitter
2. On/Stand-by Button
3. CD Select Button
4. Random/Repeat Button
5. Fast Reverse/Tuning Down Button
6. Track Down/Preset Down Button
7. Disc Stop Button
8. Memory Button
9. Clear Button
10. Clock Button
11. RDS Display Mode Select Button
12. Shift Bu tton
13. Bass/Treble Selector Button
14.Volume Up and Down Buttons
15. Tuner and Band Selector Button
16. MP3/WMA Display Button
17. Auxiliary Button
18. Fast Forward/Tuning Up Button
19. Track Up/Preset Up Button
20. Disc Play Button
21. Disc Pause Button
22. Timer Button
23. Sleep Button
24. Direct Search Buttons
25. RDS ASPM (Auto Station Programme Memory) Button
26. RDS Programme Type/
Traffic Information Search Button
4
5
7
13
20
17
18
21
1
3
2
14
12
16
19
22
23
15
6
8
10
24
9
11
25
26

Sharp XL-MP9H Specifications

General

Brand	Sharp
Model	XL-MP9H
Category	Stereo System
Language	English
