PRICE
RANK
DESCRIPTION
NO.
PARTS CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
XL-S10
– 1 –
INTEGRATED CIRCUITS
IC7A1 ———— J Patch Cpu,AT24C16 (Not
Replacement Item)
IC101 VHILA4631++-1 J AM Power Amp.,LA4631++
IC201 VHIBD3881FV-1 J AP Record/Playback Amp.,
BD3881FV
IC301 VHILV23002M-1 J AS FM FRONT END/PLL (Tuner)/
FM IF Det./FM Mpx./AM IF,
LV23002M
IC701 ———— J –– System Microcomputer,
IXA007SJ (Not Replacement
Item)
IC701 RH-IXA019SJZZ J AW System Microcomputer,
IXA019SJ
IC801 VHILC78646E-1 J AY Servo/Signal,LC78646E
IC802 VHILA6548ND-1 J Focus/Tracking/Spin/Sled Driver,
LA6548ND
TRANSISTORS
Q101 VS2SB1370E+-1 J AG Silicon,PNP,2SB1370 E+
Q102,103 VS2SC3052F+-1 J AD Silicon,NPN,2SC3052 F+
Q301 VS2SC3052F+-1 J AD Silicon,NPN,2SC3052 F+
Q302 VS2SC5477++-1 J AD Silicon,NPN,2SC5477++
Q371 VS2SC5477++-1 J AD Silicon,NPN,2SC5477++
Q502 VS2SC5395F+-1 J AD Silicon,NPN,2SC5395 F+
Q503 VS2SC3052F+-1 J AD Silicon,NPN,2SC3052 F+
Q701 VS2SC3052F+-1 J AD Silicon,NPN,2SC3052 F+
Q702,703 VS2SC5395F+-1 J AD Silicon,NPN,2SC5395 F+
Q704~706 VS2SC3052F+-1 J AD Silicon,NPN,2SC3052 F+
Q801 VS2SC3052F+-1 J AD Silicon,NPN,2SC3052 F+
Q802 VS2SC5395F+-1 J AD Silicon,NPN,2SC5395 F+
Q803 VS2SA1235F+-1 J AD Silicon,PNP,2SA1235 F+
DIODES
1 D101~104 VHD1N4004A/-1 J AB Silicon,1N4004A
D105 VHD1SS133//-1 J AA Silicon,1SS133
D106 VHEMTZJ6R8B-1 J AC Zener,6.8V,MTZJ6.8B
D302,303 VHD1SS133//-1 J AA Silicon,1SS133
D305 VHCSVC347S/-1 J AG Variable Capacitance,SVC347S
D306,307 VHCSVC201//-1 J AE Variable Capacitance,SVC201
D308 VHEMTZJ3R6B-1 J AC Zener,3.6V,MTZJ3.6B
D309 VHEMTZJ120B-1 J AC Zener,12V,MTZJ120B
D501 VHD1SS133//-1 J AA Silicon,1SS133
D701 VHEMTZJ5R1B-1 J AC Zener,5.1V,MTZJ5.1B
D703,704 VHD1SS133//-1 J AA Silicon,1SS133
D801 VHEMTZJ5R1B-1 J AC Zener,5.1V,MTZJ5.1B
D802 VHEMTZJ3R9B-1 J AC Zener,3.9V,MTZJ3.9B
LED701~704 VHPMPG3372X-V J AD LED,Green,MPG3372X
FILTERS
CF301 RFILFA001SJZZ J AE FM IF
CF302 RFILF0003AWZZ J AK FM IF
CF303 RFILA0003SJZZ J AF AM IF
CF304 RFILFA001SJZZ J AE FM IF
CF306 RFILR0008AWZZ J AE Band Pass Filter
TRANSFORMERS
1 PT1 RTRNPA007SJZZ J AX Power
COILS
L101 VP-DH1R0K0000 J AC 1 µH
L102,103 RCILZA001SJZZ J AC Line Filter
L301 VP-DH1R0K0000 J AC 1 µH
L302 RCILA0007SJZZ J AG AM Antenna
L303 VP-DH100K0000 J AB 10 µH,Choke
L304 RCILRA001SJZZ J AA FM RF
L305 RCILIA001SJZZ J AC AM IF
L306 RCILB0009SJZZ J AG AM OSC.
L307 RCILBA005SJZZ J FM OSC.
L308 VP-DH470K0000 J AB 47 µH,Choke
L501 RCILBA001SJZZ J AE BIAS OSC.
L701 VP-DH220K0000 J AB 22 µH,Choke
L801 VP-DH100K0000 J AB 10 µH,Choke
VIBRATORS
X301 RCRSPA001SJZZ J AE Crystal,75 kHz
X702 RCRSP0007SJZZ J AE Crystal,32.768 kHz
X801 RCRSP0011SJZZ J AE Crystal,16.9344 MHz
CAPACITORS
C7A1 VCKYCY1HF104Z J AB 0.1 µF,50V (Serial
No.40100001~40104000)
C101 VCKYCY1EF473Z J AB 0.047 µF,25V
C102~110 VCKYCY1EF104Z J AA 0.1 µF,25V
C111,112 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
1 C113,114 VCKYCY1EF104Z J AA 0.1 µF,25V
C115,116 RC-GZV108AF1C J AD 1000 µF,16V,Electrolytic
C117 RC-GZA226AF1H J AB 22 µF,50V,Electrolytic
C118 RC-GZW688AF1E J AH 6800 µF,25V,Electrolytic
C119 RC-GZA107AF1C J AB 100 µF,16V,Electrolytic
C120 VCKYCY1EF104Z J AA 0.1 µF,25V
C121 RC-GZA475AF1H J AB 4.7 µF,50V,Electrolytic
C122 RC-GZA226AF1H J AB 22 µF,50V,Electrolytic
C123 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C124 VCKYCY1HB103K J AA 0.01 µF,50V
C125 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C126,127 VCKYCY1HB222K J AA 0.0022 µF,50V
C128 VCKYCY1EF104Z J AA 0.1 µF,25V
C129 RC-GZA227AF1C J AB 220 µF,16V,Electrolytic
C130 VCKYCY1EF104Z J AA 0.1 µF,25V
C133,134 VCKYCY1HB222K J AA 0.0022 µF,50V
C301 VCKYCY1HB102K J AA 0.001 µF,50V
C302 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C303 VCKYCY1EF104Z J AA 0.1 µF,25V
C305 VCCCPA1HH120J J AA 12 pF (CH),50V
C306 VCKYCY1HB103K J AA 0.01 µF,50V
C307 VCCUPA1HJ100D J AA 10 pF (UJ),50V
C308 VCKYCY1EB183K J AB 0.018 µF,25V
C309 VCKYPA1HB102J J AA 0.001 µF,50V
C310 VCCCPA1HH270J J AA 27 pF (CH),50V
C311 VCCSPA1HL561J J AA 560 pF,50V
C312,313 VCKYCY1EF104Z J AA 0.1 µF,25V
C314 VCKYCY1HB103K J AA 0.01 µF,50V
C315 RC-GZA226AF1H J AB 22 µF,50V,Electrolytic
C316 VCCUPA1HJ330D J AA 33 pF (UJ),50V
C317 VCKYPA1HB102J J AA 0.001 µF,50V
C318 VCKYCY1HB103K J AA 0.01 µF,50V
C319 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C320 VCCCCY1HH101J J AA 100 pF (CH),50V
C321 RC-GZA334AF1H J AA 0.33 µF,50V,Electrolytic
C322 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C323 RC-GZA474AF1H J AA 0.47 µF,50V,Electrolytic
C324 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C325 RC-GZA226AF1H J AB 22 µF,50V,Electrolytic
C326 VCKYCY1EF104Z J AA 0.1 µF,25V
C327 VCKYCY1HB103K J AA 0.01 µF,50V
C328 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C329 VCKYCY1HB223K J AA 0.022 µF,50V
C330 RC-GZA226AF1H J AB 22 µF,50V,Electrolytic
C331 VCKYCY1HB103K J AA 0.01 µF,50V
C332 VCKYCY1HB102K J AA 0.001 µF,50V
C333 RC-GZA475AF1H J AB 4.7 µF,50V,Electrolytic
C334 VCKYCY1HB101K J AB 100 pF,50V
C335 RC-GZA226AF1H J AB 22 µF,50V,Electrolytic
C336,337 VCKYCY1HB101K J AB 100 pF,50V
C338~340 VCKYCY1EF104Z J AA 0.1 µF,25V
C341,342 VCCCCY1HH100J J AA 10 pF (CH),50V
C343 VCCCCY1HH5R0C J AA 5 pF (CH),50V
C344 VCCUPA1HJ330D J AA 33 pF (UJ),50V
C345 VCKYPA1HB5R0J J AA 5 pF,50V
C351 VCKYCY1HB223K J AA 0.022 µF,50V
C372 VCKYCY1EF104Z J AA 0.1 µF,25V
C399 VCKYCY1HB472K J AA 0.0047 µF,50V
C501 RC-GZA476AF1E J AB 47 µF,25V,Electrolytic
C502 RC-GZA227AF0J J AB 220 µF,6.3V,Electrolytic
C503,504 VCKYCY1EB104K J AD 0.1 µF,25V
C505 RC-GZA476AF1E J AB 47 µF,25V,Electrolytic
C506 RC-GZA104AF1H J AB 0.1 µF,50V,Electrolytic
C507 VCCCCY1HH100J J AA 10 pF (CH),50V
C508~510 RC-GZA104AF1H J AB 0.1 µF,50V,Electrolytic
C511 VCKYCY1HB332K J AA 0.0033 µF,50V
C512 VCKYCY1HB272K J AA 0.0027 µF,50V
