Sharp XL-S10 Service Manual

NO.
PRICE
RANK
DESCRIPTIONPARTS CODE
NO.
PARTS CODE
PRICE
RANK
DESCRIPTION
XL-S10
– 2 –
C513 VCKYCY1HB332K J AA 0.0033 µF,50V
C514 VCKYCY1HB272K J AA 0.0027 µF,50V
C515,516 RC-GZA224AF1H J AA 0.22 µF,50V,Electrolytic
C517 RC-GZA227AF1C J AB 220 µF,16V,Electrolytic
C518 VCKYCY1HB103K J AA 0.01 µF,50V
C519,520 VCKYCY1HB471K J AA 470 pF,50V
C521 VCCCCY1HH470J J AA 47 pF (CH),50V
C522 VCKYCY1EF104Z J AA 0.1 µF,25V
C523 VCQYKA1HM562J J AA 0.0056 µF,50V,Mylar
C524 VCCCCY1HH470J J AA 47 pF (CH),50V
C525,526 VCKYCY1HB122K J AA 0.0012 µF,50V
C527,528 VCKYCY1HB103K J AA 0.01 µF,50V
C529,530 VCKYCY1HB821K J AA 820 pF,50V
C531,532 VCKYCY1HB153K J AA 0.015 µF,50V
C533,534 RC-GZA107AF1V J AB 100 µF,35V,Electrolytic
C535 RC-GZA476AF1E J AB 47 µF,25V,Electrolytic
C701 RC-GZA227AF1A J AB 220 µF,10V,Electrolytic
C702 VCKYCY1HB473K J AB 0.047 µF,50V
C703 VCKYCY1HB102K J AA 0.001 µF,50V
C704 RC-GZA336AF1C J AB 33 µF,16V,Electrolytic
C705 VCKYCY1EF104Z J AA 0.1 µF,25V
C706,707 VCCCCY1HH100J J AA 10 pF (CH),50V
C708,709 VCCCCY1HH150J J AA 15 pF (CH),50V
C710 VCKYCY1EF104Z J AA 0.1 µF,25V
C711 VCKYCY1HB102K J AA 0.001 µF,50V
C714,715 VCKYCY1HB102K J AA 0.001 µF,50V
C716 VCCCCY1HH151J J AA 150 pF (CH),50V
C717,718 VCKYCY1EF104Z J AA 0.1 µF,25V
C720 VCKYCY1HB103K J AA 0.01 µF,50V
C721,722 VCKYCY1EB101K J AA 100 pF,25V
C723 VCKYCY1HB103K J AA 0.01 µF,50V
C724 VCKYCY1EB101K J AA 100 pF,25V
C801 VCKYCY1EF104Z J AA 0.1 µF,25V
C802 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
C803,804 VCKYCY1EF104Z J AA 0.1 µF,25V
C806 VCKYCY1EF104Z J AA 0.1 µF,25V
C807,808 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C809 VCKYCY1EF104Z J AA 0.1 µF,25V
C810 RC-GZA107AF0J J AB 100 µF,6.3V,Electrolytic
C811 RC-GZA106AF1C J AB 10 µF,16V,Electrolytic
C812 VCKYCY1EF104Z J AA 0.1 µF,25V
C813 VCCSCY1HL470J J AA 47 pF,50V
C814 VCKYCY1EF104Z J AA 0.1 µF,25V
C815 RC-GZA107AF0J J AB 100 µF,6.3V,Electrolytic
C816 VCKYCY1HB222K J AA 0.0022 µF,50V
C817 RC-GZA106AF1C J AB 10 µF,16V,Electrolytic
C818 VCCCCY1HH120J J AA 12 pF (CH),50V
C819,820 VCKYCY1EF104Z J AA 0.1 µF,25V
C821 VCCCCY1HH120J J AA 12 pF (CH),50V
C823 VCKYCY1EF104Z J AA 0.1 µF,25V
C824 RC-GZA107AF0J J AB 100 µF,6.3V,Electrolytic
C825 RC-GZA336AF1C J AB 33 µF,16V,Electrolytic
C826 VCKYCY1EF104Z J AA 0.1 µF,25V
C827 RC-GZA107AF0J J AB 100 µF,6.3V,Electrolytic
C828 VCKYCY1HB222K J AA 0.0022 µF,50V
C829 VCKYCY1EF104Z J AA 0.1 µF,25V
C830 VCKYCY1HB101K J AB 100 pF,50V
C831 VCKYCY1EB104K J AD 0.1 µF,25V
C832 VCKYCY1EF473Z J AB 0.047 µF,25V
C833,834 VCCCCY1HH101J J AA 100 pF (CH),50V
C835 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C836 VCKYCY1EF473Z J AB 0.047 µF,25V
C837 VCKYCY1EB104K J AD 0.1 µF,25V
C838 VCKYCY1EB101K J AA 100 pF,25V
RESISTORS
JR302~304 VRS-CY1JB000J J AA 0 ohm,Jumper,0.8×1.55mm,Green
JR701,702 VRS-CY1JB000J J AA 0 ohm,Jumper,0.8×1.55mm,Green
JR801 VRS-CY1JB000J J AA 0 ohm,Jumper,0.8×1.55mm,Green
R7A1 VRS-CY1JB104J J AA 100 kohm,1/16W (Serial
No.40100001~40104000)
R7A2 VRS-CY1JB104J J AA 100 kohm,1/16W (Serial
No.40100001~40104000)
R7A3 VRS-CY1JB104J J AA 100 kohm,1/16W (Serial
No.40100001~40104000)
R101,102 VRD-ST2CD221J J AA 220 ohms,1/6W
R103,104 VRD-ST2CD100J J AA 10 ohm,1/6W
R105 VRS-CY1JB472J J AA 4.7 kohms,1/16W
R106,107 VRD-ST2CD100J J AA 10 ohm,1/6W
R108 VRS-CY1JB472J J AA 4.7 kohms,1/16W
R109 VRS-CY1JB101J J AA 100 ohm,1/16W
R110 VRS-CY1JB152J J AA 1.5 kohms,1/16W
R111 VRS-CY1JB681J J AA 680 ohms,1/16W
R112,113 VRS-CY1JB332J J AA 3.3 kohms,1/16W
R114 VRS-CY1JB472J J AA 4.7 kohms,1/16W
R115 VRS-CY1JB332J J AA 3.3 kohms,1/16W
R116,117 VRS-CY1JB333J J AA 33 kohms,1/16W
R118 VRS-CY1JB101J J AA 100 ohm,1/16W
R119 VRS-CY1JB102J J AA 1 kohm,1/16W
R120,121 VRS-CY1JB822J J AA 8.2 kohms,1/16W
R131,132 VRS-CY1JB682J J AA 6.8 kohms,1/16W
R302 VRD-ST2CD100J J AA 10 ohm,1/6W
R303 VRD-ST2CD104J J AA 100 kohm,1/6W
R304,305 VRS-CY1JB104J J AA 100 kohm,1/16W
R306 VRS-CY1JB100J J AA 10 ohm,1/16W
R307 VRS-CY1JB222J J AA 2.2 kohms,1/16W
R308 VRS-CY1JB102J J AA 1 kohm,1/16W
R309 VRS-CY1JB000J J AA 0
ohm,Jumper,0.8×1.55mm,Green
R310 VRD-ST2CD104J J AA 100 kohm,1/6W
R311 VRD-ST2CD102J J AA 1 kohm,1/6W
R312 VRS-CY1JB332J J AA 3.3 kohms,1/16W
R313 VRS-CY1JB103J J AA 10 kohm,1/16W
R314,315 VRS-CY1JB472J J AA 4.7 kohms,1/16W
R316 VRS-CY1JB103J J AA 10 kohm,1/16W
R317,318 VRS-CY1JB102J J AA 1 kohm,1/16W
R319 VRS-CY1JB104J J AA 100 kohm,1/16W
R320 VRS-CY1JB473J J AA 47 kohms,1/16W
R321 VRS-CY1JB102J J AA 1 kohm,1/16W
R322 VRS-CY1JB104J J AA 100 kohm,1/16W
R323 VRD-ST2CD391J J AA 390 ohms,1/6W
R324 VRS-CY1JB102J J AA 1 kohm,1/16W
R325 VRD-ST2CD470J J AA 47 ohms,1/6W
R326 VRS-CY1JB473J J AA 47 kohms,1/16W
R327 VRS-CY1JB221J J AA 220 ohms,1/16W
R328 VRS-CY1JB104J J AA 100 kohm,1/16W
R329 VRS-CY1JB331J J AA 330 ohms,1/16W
R371 VRS-CY1JB330J J AA 33 ohms,1/16W
R372 VRS-CY1JB331J J AA 330 ohms,1/16W
R374 VRD-ST2CD101J J AA 100 ohm,1/6W
R375 VRS-CY1JB222J J AA 2.2 kohms,1/16W
R376 VRS-CY1JB681J J AA 680 ohms,1/16W
R501 VRD-ST2EE100J J AA 10 ohm,1/4W
R502 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R503 VRD-ST2EE100J J AA 10 ohm,1/4W
R504 VRS-CY1JB334J J AA 330 kohms,1/16W
R505 VRS-CY1JB223J J AA 22 kohms,1/16W
R506 VRD-ST2CD101J J AA 100 ohm,1/6W
R507 VRS-CY1JB334J J AA 330 kohms,1/16W
R508 VRS-CY1JB223J J AA 22 kohms,1/16W
R509,510 VRS-CY1JB682J J AA 6.8 kohms,1/16W
R511 VRD-ST2CD473J J AA 47 kohms,1/6W
R512 VRS-CY1JB183J J AA 18 kohms,1/16W
R513,514 VRS-CY1JB332J J AA 3.3 kohms,1/16W
R515 VRD-ST2CD473J J AA 47 kohms,1/6W
R516 VRD-ST2CD332J J AA 3.3 kohms,1/6W
R517 VRS-CY1JB8R2J J AA 8.2 ohms,1/16W
R518 VRS-CY1JB332J J AA 3.3 kohms,1/16W
R519 VRD-ST2CD332J J AA 3.3 kohms,1/6W
R520 VRS-CY1JB332J J AA 3.3 kohms,1/16W
R521 VRS-CY1JB682J J AA 6.8 kohms,1/16W
R522 VRD-ST2CD473J J AA 47 kohms,1/6W
R523 VRS-CY1JB682J J AA 6.8 kohms,1/16W
R524 VRD-ST2CD473J J AA 47 kohms,1/6W
R525,526 VRD-ST2CD102J J AA 1 kohm,1/6W
R527 VRS-CY1JB101J J AA 100 ohm,1/16W
R528 VRS-CY1JB153J J AA 15 kohms,1/16W
R529 VRS-CY1JB101J J AA 100 ohm,1/16W
R530 VRS-CY1JB153J J AA 15 kohms,1/16W
R531 VRD-ST2CD391J J AA 390 ohms,1/6W
R532 VRD-ST2CD223J J AA 22 kohms,1/6W
R533 VRS-CY1JB394J J AA 390 kohms,1/16W
R534 VRS-CY1JB123J J AA 12 kohms,1/16W
R535 VRS-CY1JB394J J AA 390 kohms,1/16W
R536 VRS-CY1JB123J J AA 12 kohms,1/16W
R537,538 VRS-CY1JB473J J AA 47 kohms,1/16W
R539 VRD-ST2CD103J J AA 10 kohm,1/6W
R540 VRD-ST2CD562J J AA 5.6 kohms,1/6W
R541,542 VRS-CY1JB680J J AA 68 ohms,1/16W
R543 VRS-CY1JB222J J AA 2.2 kohms,1/16W
R544~546 VRD-ST2EE180J J AA 18 ohms,1/4W
R547,548 VRS-CY1JB104J J AA 100 kohm,1/16W
R549,550 VRS-CY1JB102J J AA 1 kohm,1/16W
