PRICE
RANK
DESCRIPTION
NO.
PARTS CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
XL-S10
OTHER CIRCUITRY PARTS
CFA701 QCNWN0215SJZZ J AA Lead Wire (Serial
No.40100001~40104000)
CFA702 QCNWN0300SJZZ J AA Lead Wire (Serial
No.40100001~40104000)
CFW701 QCNWN0505SJZZ J AA Flat Wire,2Pin
CFW801 QCNWNA053SJZZ J AE Flat Cable,16Pin
CNA501 QCNWNA026SJZZ J AD Connector Ass’y,4Pin
CNA502 QCNWNA027SJZZ J AC Connector Ass’y,3Pin
CNP101 QCNCM998CAFZZ J AE Plug,3Pin
CNP301 QCNCM042CSJZZ J AB Plug,3Pin
CNP501 QCNCM999DAFZZ J AG Plug,4Pin
CNP502 QCNCM999CAFZZ J AG Plug,3Pin
CNP503 QCNCM010TAWZZ J AD Plug,18Pin
CNP702 QCNCM932BAFZZ J AA Plug,2Pin
CNS701 QCNCW010TAWZZ J AE Socket,18Pin
CNS801 QCNCW011RSJZZ J AF Socket,16Pin
CNW101/CNS101
QCNWNA025SJZZ J AD Connector Ass’y,4/3Pin
CNW702/CNS702
QCNWNA001SJZZ J AC Connector Ass’y,2/2Pin
CNW802/CNS802
QCNWNA028SJZZ J AE Connector Ass’y,7/6Pin
1 F653 QFS-D631BSJNI J AE Fuse,630mA/125V
J101 QTANA0008SJZZ J AE Terminal,Speakers
J102 QSOCJ0301SJZZ J AG Jack,VIDEO/AUX In/Sub Woofer
Out
J103 QJAKM0001SJZZ J AG Jack,Headphone
LCD701 RV-LX0008SJZZ J AM LCD Display
M501 ———— –– Motor with Pulley [Tape]
(Supplied at REF No.226)
RX701 VHLGP1U281X-1 J AH Remote Sensor,GP1U281X
S501 QSW-SA001SJZZ J AE Switch,Slide Type
[Record/Playback]
SW501 ———— –– Switch,Leaf Type [Play]
(Supplied at REF No.226)
SW700 QSW-Z0003SJZZ J AG Switch,Rotary Type [VOLUME]
SW701 QSW-P0004AWZZ J AE Switch,Push Type [CD LID]
SW702 QSW-K0002SJZZ J AC Switch,Key Type
[ON/STAND-BY]
SW703 QSW-K0002SJZZ J AC Switch,Key Type [FUNCTION]
SW704 QSW-K0002SJZZ J AC Switch,Key Type [BASS/TRBLE]
SW705 QSW-K0002SJZZ J AC Switch,Key Type
[MEMORY/SET]
SW707 QSW-K0002SJZZ J AC Switch,Key Type [TUNING UP]
SW708 QSW-K0002SJZZ J AC Switch,Key Type
[TUNING DOWN]
SW709 QSW-K0002SJZZ J AC Switch,Key Type [PRESET UP]
SW710 QSW-K0002SJZZ J AC Switch,Key Type
[PRESET DOWN]
SW711 QSW-K0002SJZZ J AC Switch,Key Type [CLEAR]
CABINET PARTS
201 CCABBA007SJ01 J Rear Panel Ass’y
[Except for U.S.A.]
201 CCABBA008SJ01 J Rear Panel Ass’y [For U.S.A.]
201- 1 ———— –– Rear Panel
201- 2 PCUSGA002SJSA J AB Cushion,Leg
202 CDORT0010SJ04 J CD Lid Ass’y
202- 1 ———— –– CD Lid
202- 2 HDECQ0109SJSA J AD CD Lid Window
203 CHLDM1011SJ01 J AE Stabilizer Ass’y
203- 1 ———— –– Stabilizer
203- 2 PMAGF0002AWZZ J AE Magnet
203- 3 PCUSZA001SJZZ J Cushion Sheet
204 GCABCA001SJSA J AL Top Cabinet
205 GCABDA001SJSA J AK Bottom Chassis
206 GCOVAA001SJSA J AG Cover,Cassette Holder
207 GCOVAA002SJSA J AD Cover,Remote Sensor
208 GDORFA001SJSA J AF Cassette Holder
209 GITASA001SJSA J AK Side Panel,Right
210 GITASA002SJSA J AK Side Panel,Left
211 HDECQA035SJSA J AL Front Clear Panel
212 HDECQA002SJSA J AE Cassette Holder Window
213 HDECQA003SJSA J AF Ring,VOLUME Knob
214 HPNLCA001SJSA J AQ Front Panel
215 JBTN-A001SJSA J AE Cassette Button,RECORD
216 JBTN-A002SJSA J AE Cassette Button,PLAY
217 JBTN-A003SJSA J AE Cassette Button,REW
218 JBTN-A004SJSA J AE Cassette Button,FF
219 JBTN-A005SJSA J AE Cassette Button,STOP/EJECT
220 JBTN-A006SJSA J AE Cassette Button,PAUSE
– 3 –
R551~559 VRS-CY1JB682J J AA 6.8 kohms,1/16W
R560 VRS-CY1JB222J J AA 2.2 kohms,1/16W
R561,562 VRS-CY1JB333J J AA 33 kohms,1/16W
R563,564 VRS-CY1JB682J J AA 6.8 kohms,1/16W
R701 VRD-ST2CD102J J AA 1 kohm,1/6W
R702~710 VRD-ST2CD332J J AA 3.3 kohms,1/6W
R711 VRD-ST2CD102J J AA 1 kohm,1/6W
R712,713 VRD-ST2CD332J J AA 3.3 kohms,1/6W
R714~716 VRS-CY1JB332J J AA 3.3 kohms,1/16W
R717 VRS-CY1JB472J J AA 4.7 kohms,1/16W
R718 VRD-ST2CD104J J AA 100 kohm,1/6W
R719 VRS-CY1JB122J J AA 1.2 kohms,1/16W
R720 VRD-ST2CD122J J AA 1.2 kohms,1/6W
R721 VRS-CY1JB102J J AA 1 kohm,1/16W
R723 VRD-ST2CD103J J AA 10 kohm,1/6W
R724 VRD-ST2CD473J J AA 47 kohms,1/6W
R725 VRD-ST2CD331J J AA 330 ohms,1/6W
R726,727 VRS-CY1JB223J J AA 22 kohms,1/16W
R728 VRD-ST2CD103J J AA 10 kohm,1/6W
R729 VRD-ST2CD104J J AA 100 kohm,1/6W
R730,731 VRD-ST2CD103J J AA 10 kohm,1/6W
R732 VRD-ST2CD104J J AA 100 kohm,1/6W
R733 VRD-ST2CD334J J AA 330 kohms,1/6W
R734 VRD-ST2CD154J J AA 150 kohms,1/6W
R735 VRS-CY1JB102J J AA 1 kohm,1/16W
R736 VRD-ST2CD334J J AA 330 kohms,1/6W
R737 VRS-CY1JB104J J AA 100 kohm,1/16W
R739,740 VRS-CY1JB102J J AA 1 kohm,1/16W
R741 VRS-CY1JB104J J AA 100 kohm,1/16W
R742,743 VRD-ST2CD392J J AA 3.9 kohms,1/6W
R744,745 VRD-ST2CD682J J AA 6.8 kohms,1/6W
R746,747 VRD-ST2CD123J J AA 12 kohms,1/6W
R749~752 VRS-CY1JB221J J AA 220 ohms,1/16W
R753 VRD-ST2EE121J J AA 120 ohms,1/4W
R755 VRD-ST2CD100J J AA 10 ohm,1/6W
R756 VRS-CY1JB473J J AA 47 kohms,1/16W
R757,758 VRS-CY1JB470J J AA 47 ohms,1/16W
R759 VRD-ST2CD471J J AA 470 ohms,1/6W
R760 VRS-CY1JB223J J AA 22 kohms,1/16W
R761 VRS-CY1JB392J J AA 3.9 kohms,1/16W
R762 VRD-ST2CD223J J AA 22 kohms,1/6W
R763 VRS-CY1JB102J J AA 1 kohm,1/16W
R764 VRS-CY1JB392J J AA 3.9 kohms,1/16W
R765 VRS-CY1JB102J J AA 1 kohm,1/16W
R771 VRD-ST2CD223J J AA 22 kohms,1/6W
R799 VRS-CY1JB104J J AA 100 kohm,1/16W
R801 VRD-ST2CD102J J AA 1 kohm,1/6W
R802 VRD-ST2EE120J J AA 12 ohms,1/4W
R803 VRS-CY1JB103J J AA 10 kohm,1/16W
R804 VRD-ST2EE120J J AA 12 ohms,1/4W
R806 VRS-CY1JB153J J AA 15 kohms,1/16W
R808 VRD-ST2CD682J J AA 6.8 kohms,1/6W
R809 VRD-ST2CD153J J AA 15 kohms,1/6W
R810 VRD-ST2CD103J J AA 10 kohm,1/6W
R811 VRD-ST2CD123J J AA 12 kohms,1/6W
R812 VRD-ST2CD102J J AA 1 kohm,1/6W
R813 VRS-CY1JB101J J AA 100 ohm,1/16W
R814 VRS-CY1JB102J J AA 1 kohm,1/16W
R815 VRD-ST2CD473J J AA 47 kohms,1/6W
R816 VRD-ST2CD331J J AA 330 ohms,1/6W
R817,818 VRD-ST2CD101J J AA 100 ohm,1/6W
R821 VRS-CY1JB100J J AA 10 ohm,1/16W
R822 VRS-CY1JB471J J AA 470 ohms,1/16W
R823 VRS-CY1JB470J J AA 47 ohms,1/16W
R824 VRS-CY1JB101J J AA 100 ohm,1/16W
R825 VRS-CY1JB221J J AA 220 ohms,1/16W
R826 VRS-CY1JB471J J AA 470 ohms,1/16W
R827 VRS-CY1JB104J J AA 100 kohm,1/16W
R828~831 VRS-CY1JB333J J AA 33 kohms,1/16W
R832,833 VRS-CY1JB104J J AA 100 kohm,1/16W
R834 VRS-CY1JB273J J AA 27 kohms,1/16W
R836 VRS-CY1JB331J J AA 330 ohms,1/16W
R837 VRS-CY1JB103J J AA 10 kohm,1/16W
R838 VRS-CY1JB122J J AA 1.2 kohms,1/16W
R839,840 VRS-CY1JB681J J AA 680 ohms,1/16W
R841 VRD-ST2CD103J J AA 10 kohm,1/6W
R842 VRS-CY1JB123J J AA 12 kohms,1/16W
