Sharp XL-S10 Service Manual

NO.
PARTS CODE
PRICE
RANK
DESCRIPTION
XL-S10
– 4 –
221 JKNBKA001SJSA J AG Button,Power
222 JKNBZ0081SJSA J AD Button,CD Eject
223 JKNBZA001SJSA J AF Knob,VOLUME
224 JKNBZA002SJSA J AG Button,Function
225 JKNBZA003SJSA J AG Button,Tuning
226 KMECBA001SJ01 J AY Tape Mechanism Ass’y
226- 1 ———— –– Tape Mechanism Ass’y
(Not Replacement Item)
226- 2 LANGKA003SJFW J AB Bracket,Record Lver
1 227 KRPLE0022SJM2 J BC CD Mechanism Ass’y
228 LANGKA002SJFW J AB Bracket,PWB
229 LHLDTA002SJSA J AD Holder,Transformer
230 LHLDW1001SJZZ J AD Nylon Band
231 LHLDZA001SJSA J AE Holder,LCD Display
232 LHLDZA002SJSA J AD Holder,LED
233 LHLDZA003SJSA J AC Lever,Record
234 MLEVP0003SJZZ J AB Lever,CD Eject Button
235 MLEVPA001SJSA J AD Holder,Cassette Button
236 MSPRD0025SJFJ J AD Spring,CD Lid
237 MSPRDA001SJFJ J AD Spring,Cassette Holder
238 MSPRDA002SJFJ J AD Spring,Record Lver
239 NGERH0003SJSA J AE Damper Gear
240 GCOVA1038SJSA J AD Cover,Mechanism
241 PCUSG0001AWSA J AD Cushion (GREEN)
242 PCUSG0004AWSA J AD Cushion (BROWN)
243 PCUSGA001SJSA J AB Cushion,Leg
244 PRDARA001SJFW J AF Heat Sink
245 PSHEP0002SJZZ J AH Sheet,LCD Display
1 246 QACCUA001SJ00 J AH AC Power Supply Cord
1 247 QFSHD1013CEZZ J AB Holder,Fuse
1 248 QLUGP0165AFZZ J AA Lug Terminal
250 TSPC-A026SJZZ J Label,Specification [For U.S.A.]
250 TSPC-A027SJZZ J Label,Specification
[Except for U.S.A.]
251 PCOVZA003SJSA J Cover
601 LX-EZ0001SJFN J AB Screw,ø2.5×10mm
602 LX-JZ0010AFFD J AA Screw,ø3×10mm
604 XHBSD20P03000 J AA Screw,ø2×3mm
605 XJBSD25P10000 J AD Screw,ø2.5×10mm
606 XJBSD30P08000 J AA Screw,ø3×8mm
607 XJBSD30P10000 J AA Screw,ø3×10mm
608 XJBSF25P08000 J AA Screw,ø2.5×8mm
609 XJBSF30P12000 J AA Screw,ø3×12mm
610 XJBSF30P10000 J AA Screw,ø3×10mm
SPEAKER BOX PARTS
B3CPXLS10 J Speaker Box Ass’y,L-CH/R-CH
PACKING PARTS [Except for U.S.A.]
SPAKAA003SJZZ J AE Packing Add.,Top
SPAKAA004SJZZ J AE Packing Add.,Bottom
SPAKCA044SJZZ J Packing Case
SPAKSA002SJZZ J AE Side Pad,Set
SSAKAA007SJZZ J AB Polyethylene Bag,AC Cord
SSAKA0002SJZZ J AE Polyethylene Bag,Accessories
SSAKHA002SJZZ J AC Polyethylene Bag,Unit
TLABZA008SJZZ J AC Label,Pop
ACCESSORIES
QANTL0004SJZZ J AG AM Loop/FM Antenna
TINSEA018SJZZ J AE Operation Manual [For U.S.A.]
TINSKA004SJZZ J Operation Manual
[Except for U.S.A.]
TINSZA012SJZZ J AD Quic Guide [For U.S.A. Only]
RRMCGA002SJSA J AP Remote Control
GCOVAA003SJSA J AG Battery Lid,Remote Control
P.W.B. ASSEMBLY (Not Replacement Item)
1 PWB-A1~5 DCEKKV429SJ03 J –– Main/Display/Power/LED/Switch
OTHER SERVICE PARTS
UDSKA0004AFZZ J AZ CD Optical Pickup Lens Cleaner
Disc
