PRICE
RANK
DESCRIPTION
NO.
PART CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
XL-T200H
– 5 –
306 PCUSG0001AWSA J AD Cushion (Green)
307 PCUSG0004AWSA J AD Cushion (Red-Brown)
1 308 DCTRH8005SJ01 J BA Pickup Unit Ass’y
308- 1 ———— — Pickup Unit
(Not Replacement Item)
308- 2 MSPRC0961AFZZ J AA Spring,Rack
308- 3 NGERR0043AFZZ J AC Gear,Rack
701 LX-WZ1070AFZZ J AA Washer,ø1.5×ø3.8×0.25mm
702 XBBSD20P03000 J AA Screw,ø2×3mm
703 XBSSD26P06000 J AA Screw,ø2.6×6mm
704 XHBSD20P05000 J AA Screw,ø2×5mm
M701 RMOTV0408SJM4 J AQ Motor with Chassis [Spindle]
M702 RMOTV0409AFM1 J AN Motor with Gear [Sled]
SW702 QSW-F9001AWZZ J AE Switch, Push Type [Pickup In]
CABINET PARTS
201 GCABA1079SJSA J AQ Top Cabinet
202 GCABB1086SJSA J AN Bottom Cabinet
203 GCOVA1018SJSA J AD Cover,Remote Sensor
204 GFTAT1015SJSA J AN CD Lid
205 HDECA1018SJSA J AS Plate,Operation
206 HDECQ0079SJSA J AN CD Window
207 HDECQ0080SJSA J AF CD Illuminator
208 HDECQ0081SJSA J AE LCD Window
209 HDECQ0093SJSA J AF Plate,Decoration
210 HDECQ0083SJSA J Indicator Panel,LCD
211 JKNBZ0063SJSA J AF Knob,Operation
212 CMECB0004SJ02 J Tape Mechanism Ass’y
212- 1 94R19210703 J AE Belt,FF/REW
212- 2 9GD19210943 J AG Belt,Main
212- 3 94R192104309 J AG Pinch Roller Arm Ass’y
212- 4(SOL901)
9GD19212118 J AP Solenoid Ass’y
212- 5 9GD62161401 J AN Head,Erase
212- 6 94R62010111 J AT Head,Record/Playback
212- 7(SW901) 9GD640101210 J AE Switch,Leaf Type [Fool Proof]
212- 8(SW902) 9GD640101210 J AE Switch,Leaf Type [Cam]
212- 9(M901) 9GD192112344 J AY Motor with Pulley [Tape]
212-10(PWB-E) 9GD192121303 J AZ Tape Mechanism PWB Ass’y
212-11(PWB-F) 9GD192121304 J AW Tape Mechanism PWB Ass’y
213 LANGF0040SJFW J Bracket,Lid,Top
214 LANGF0041SJFW J Bracket,Lid,Side
216 LCHSM0016SJFW J Chassis
217 LHLDM1005SJSB J AE Stabilizer
218 LHLDW1001SJZZ J AD Nylon Band
219 LHLDZ1048SJSA J Holder,Gear Box
220 LHLDZ1049SJSA J LCD Holder
221 LHLDZ1056SJSA J Holder,LED
222 LHLDZ1057SJSA J Holder,LED
223 MLEVP0009SJZZ J Lock Lever,Tape
224 MSPRD0019SJFJ J Spring,GND
227 PCOVS1003SJSA J Tape Mechanism Cover
228 PCOVS1004SJSA J PWB Shield Cover
229 PCOVS1005SJSA J PWB Shield Cover (Back)
230 PCOVS3008SJFW J PWB Shield
231 PCOVS7002SJFW J Shield Cover
233 PCUSG0011SJSA J Cushion,Lid
234 PCUSG0013SJSA J Cushion,Leg
235 PMAGF0002AWZZ J AE Magnet
236 PRDAR0059SJFW J Radiator
238 PSHEP0006SJSA J Sheet,Diffuse
239 PSPAI0001SJZZ J AB Spacer
240 QFSHD0001AWZZ J AB Holder,Fuse
241 TLABS0042SJZZ J Label,Laser
242 TSPC-0322SJZZ J
Label,Specification [Except for U.K.]
242 TSPC-0330SJZZ J Label,Specification [For U.K.]
243 CGERW0008SJ01 J AP Gear Box Ass’y
243- 1 LHLDZ1041SJSA J Lid,Gear Box
243- 2 LHLDZ1042SJSA J Gear Box
243- 3 NGERW0008SJSA J Gear,Drive
243- 4 NGERW0009SJSA J Worm Wheel
243- 5 NGERW0010SJSA J Worm Gear
243- 6 RMOTV0004SJZZ J AL Motor [CD Lid],M801
601 LX-HZ0087AFFD J AA Screw,ø3×8mm
603 LX-JZ0001SJFD J AA Screw,ø3×10mm
604 LX-JZ0010AFFD J AA Screw,ø3×10mm
605 XEBSD25P08000 J AA Screw,ø2.5×8mm
606 XEBSD25P10000 J AA Screw,ø2.5×10mm
607 XEBSD25P12000 J AA Screw,ø2.5×12mm
608 XEBSD30P10000 J AA Screw,ø3×10mm
609 XEBSF25P10000 J AC Screw,ø2.5×10mm
610 XHBSD20P03000 J AA Screw,ø2×3mm
611 XHBSD20P04000 J AA Screw,ø2×4mm
612 XHBSD20P06500 J Screw,ø2×6.5mm
613 XHBSD40P06000 J AA Screw,ø4×6mm
616 XJBSD30P08000 J AA Screw,ø3×8mm
619 XJBSF30P10000 J AA Screw,ø3×10mm
620 XWHSD40-08000 J Washer,ø4×8mm
SPEAKER BOX PARTS
901 GBOXS6003SJSA J AS Box Ass’y
902 GLEGP0003SJSB J AD Leg
903 GWAKP1020SJ01 J AL Net Flame Ass’y
903- 1 ———— — Net Flame
(Not Replacement Item)
903- 2 PGUMM0003SJSA J AD Net Catcher
903- 3 HBDGA1002SJSA J AF Badge,SHARP
904 HPNLS1011SJ01 J AQ Front Panel Ass’y
904- 1 ———— — Front Panel
(Not Replacement Item)
904- 2 HDECQ0073SJSA J AG Panel,Tweeter
904- 3 PCOVZ1003SJSA J AG Duct Cap
904- 4 PDUC-0005SJZZ J AE Duct Pipe
905 PSPAG0005SJZZ J AE Gsket
906 QTANA9011SJZZ J AE Terminal
907 ———— — Specification Label
908 XTBSF40P12000 J AA Screw,ø4×12mm
SP601,602 RSPA00020SJ8W J AQ Woofer
SP603,604 RALMB0001SJZZ J AH Tweeter
ACCESSORIES/PACKING PARTS
1 QACCB0003SJ00 J
AC Power Supply Cord [For U.K.]
1 QACCE0002SJZZ J AC Power Supply Cord
[Except for U.K.]
2 QANTL0001SJZZ J AK AM Loop Antenna
3 QANTW0002SJZZ J AH FM Antenna
4 QCNWH0009SJZZ J Speaker Wire
5 RRMCG0044SJSA J AU Remote Control
5- 1 GCABB1064SJSB J Battery Lid,Remote Control
6 SPAKA0118SJZZ J Packing Add.,Left
7 SPAKA0119SJZZ J Packing Add.,Right
8 SPAKC0223SJZZ J Packing Case
9 SPAKZ0066SJZZ J Pad,Accessories
10 SPAKZ0067SJZZ J Support Pad
11 SSAKA0009SJZZ J Polyethylene Bag,Accessories
12 SSAKH0018SJZZ J Polyethylene Bag,Unit
13 TCADN0003SJZZ J Register Card [U.K.Only]
14 TINSE0099SJZZ J Operation Manual [For U.K.]
14 TINSZ0138SJZZ J AP
Operation Manual [Except for U.K.]
15 TINSE0100SJZZ J Quick Guide [U.K.Only]
16 SPAKZ0061SJZZ J Polyethylene Bag,Speaker
17 TLABE0110SJ01 J Label,Bar Code
18 TLABN0187SJZZ J Label,Serial No. [Except for U.K.]
19 TLABN0211SJZZ J Label,Serial No. [For U.K.]
20 TLABZ0067SJZZ J Label,Serial No. [Except for U.K.]
21 ———— — Battery (UM-4) (Not Replace-
ment Item) [Except for U.K.]
22 SPAKA0110SJZZ J Packing Add.,Speaker
[Top/Bottom]
23 SPAKS0006SJZZ J Sleeve Carton,Speaker
P.W.B. ASSEMBLY (Not Replacement Item)
1 PWB-A1~4 DCEKMV196SJ03 J Main/Terminal/Motor/Holder
PWB-B1~5 DCEKNV196SJ03 J Display/Switch/Switch/Led/Led
PWB-C1,C2 DCEKJV155SJ03 J BF Tuner/Holder
PWB-D QPWBF3895AFZZ J AC CD Motor (PWB Only)
PWB-E 9GD192121303 J AZ Tape Mechanism PWB Ass’y
PWB-F 9GD192121304 J AW Tape Mechanism PWB Ass’y
OTHER SERVICE PART
UDSKA0004AFZZ J AZ CD Pickup Lens Cleaner Disc
