– 7 –
XL-T200H
Figure 7-1
Chassis
(E1) x3
ø3 x10mm
(E1) x3
ø3 x10mm
(D1) x1
ø3 x10mm
(E1) x1
ø3 x10mm
(D1) x1
ø3 x8mm
(C1) x1
ø3 x8mm
(C2) x1
(C1) x1
ø3 x12mm
(E1) x1
ø3 x14mm
(E2) x2
(D2) x1
Main PWB
Tuner PWB
Terminal
PWB
Figure 7-3
Top Cabinet
CD
Mechanism
CNW909
Tape
Mechanism
(F1) x4
ø2.5 x10mm
(G1) x4
ø3 x10mm
Holder PWB
Hook
(L2) x4
Holder PWB
Top Panel
(L1) x3
ø2.5 x10mm
(K1) x1
ø2.5 x10mm
(H2) x1
(L1) x4
ø2.5 x8mm
(J1) x1
ø2.5 x8mm
(H1) x2
ø2.5 x10mm
(H1) x1
ø2.5 x10mm
Switch PWB
LED PWB
Switch PWB
Gear Box
Display PWB
( A3 ) x4
ø3.5 x12mm
Tweeter
Net Frame
( A1 ) x1
Front Panel
( A2 ) x1
Woofer
Screwdriver
Figure 7-2
Figure 7-4
1 Speaker 1. Net Frame ........... (A1) x1 7-4
2. Front Panel ......... (A2) x1
3. Screw .................. (A3) x4
STEP
REMOVAL
PROCEDURE
FIGURE
