05-25757-0DPage 3
10' x 20' MAX AP Canopy - 6 Leg - Parts List - Model #25757
Quantity Part #
4 - Way Frame Connectors
3 13102
Bungee Cords
Description of Parts:
Rafter Poles, Swedge 24 3/8"
6
13104
Poles, Swedge 40 11/16"
24 13103
Cross Poles 40 11/16" 6 13106
3 - Way Frame Connectors
6 13101
1Canopy Cover
10072
6Base Feet
10075
24 10066
4Anchors
10431
Leg Poles 39" 6 13105
1Rope 40'
10432
1. LAYOUT ROOF FRAME
13106 13106
13106 13106
13106 13106
13103 13103
13103 13103
13103 13103
13103 13103
13103 13103
13103 13103
13102 13101
13102 13101
13101
13101
13103 13103 13103
13104 13104 13104
13104 13104 13104
13103 13103 13103
13102 13101
13101
FRONT
REAR
