ShelterLogic Max AP 25757 Assembly Instructions

05-25757-0DPage 4
2. ASSEMBLE ROOF FRAME
Swedged Tubes Connections
13104 13103
NOTE: Swedged tubes insert into plain ends at the crimp marks.
3. ASSEMBLE LEGS & ATTACH TO ROOF FRAME
Attach all legs to one side rst. Let the other side of roof frame rest on the
ground. Repeat for opposite side.
4. ANCHOR THE FRAME
Insert the (4) Anchor pins into the ground and tie ropes from the anchors to the corner tees as shown below.
These are temporary spike anchors. Not intended for permanent use.
Tie Rope Around Frame Corners
13105
rope
13101
Leg Pole Assembly
13105
13103
10075

ShelterLogic Max AP 25757 Specifications

General

Brand	ShelterLogic
Model	Max AP 25757
Category	Tent
Language	English
