Shenchen Pump LabV Series
4.9 Flow Rate Calibration Interface
Flow Rate Calibration Interface as below:
The top left corner displays the function, when fixed volume measurement turn on,
displays fixed volume; When dispensing turned on, displays dispensing. Others
displays transferring mode.
If dispensing turned on, the target volume and running time are set up parameter,
unable to amend. Other modes, the running time is 60s, you can click the run time
button to amend the running time.
Before the pump works, need to calibrate the flow rate to ensure the
transferring or dispensing accuracy
Process as below:
(1) Confirm the running time, if dispensing function, the running time is set up
time, unable to change.
(2) Click Test button to start the test, countdown displays the run time, it will stop
automatically, and display numerical keyboard, input the actual volume, then it
will ask whether continue test (suggest more than 3 times), choose Yes, the
pump will test again, choose No, back to the calibration interface.
(3) After click the Test button, during the pump running, you can click the Stop
button to stop the test.
(4) After finish the tests, the actual volume area display the average data, click the
