SHERCO 300 SE-R Repair Manual

15
250/300 SE
DISMANTLING THE ENGINE
❱❘ Removing the primary transmission
• Remove the screws and extract the ignition
housing with its gasket
❱❘ Removing the torque limiter and the starter drive
• Remove the 3 shoulder screws [1]
• Remove the torque limiter lug [2]
• Remove the starter drive [3]
• Remove the torque limiter [4]
2
1
2
2

SHERCO 300 SE-R Specifications

General

Transmission	6-speed
Dry Weight	105 kg
Seat Height	950 mm
Displacement	293.1 cc
Bore x Stroke	72 mm x 72 mm
Clutch	Wet multi-disc
Frame	Chrome-molybdenum steel semi-perimeter
Front Brake	Single disc
Rear Brake	220 mm disc
