Shibaura CM314 - International Symbols

1-3
GENERAL INFORMATION
INTERNATIONAL SYMBOLS
As a guide to the operation of your tractor, various international symbols have been used on instruments
and controls. These symbols are depicted and described below.
Hours Recorded
Engine Water
Temperature
Air Filter
Engine Oil
Pressure
Full Tiem 4WD
Auto 4WD
Continulusly
Variable
Increase
Decrease
Fuel Level
High Range
Low Range
Neutral
Diesel Fuel
Glow
Engine Stop
Engine Oil
Engine Start
Parking Brake
Lock
Release Lock
Differential Lock
Vloume Empty
Volume Full
Battery
Power Take-off
(ON)
Power Take-off
(OFF)
“Tortoise”-SLOW
or Minimum Setting
“Hare”-FAST
or Maximum Setting
Warning
Control Lever
Hold
Rock Shaft
(Raised)
Rock Shaft
(Lowered)
Remote Cylinder
(Retracted)
Remote Cylinder
(Extended)
