Shibaura CM314 - Section 2 Operation; Operator Seat Adjustments; Seat Belt and ROPS

2-1
SEAT, SEAT BELT AND ROPS
OPERATORS SEAT
Your seat is adjustable to obtain the most
comfortable position.
Seat Travel Lever
By tilting the Seat Travel Lever outward, the seat
can be moved in a range of 6.50 in. (165 mm) in
forward and backward direction, and it can be
fixed in a position as you like.
Seat Flotation
To adjust for operator weight, turn the flotation
adjuster knob: turn it to the right and it will be
for move (+), and turn it to the left, it will be for
less (-).
IMPORTANT: If not adjusted properly, the seat
switch will not close to allow engine to start.
WARNING: DO NOT ATTEMPT BYPASS
SEAT SAFETY INTERLOCK SWITCH.
Reclining Lever
By tilting the reclining lever forward, the
inclination of the back of the seat can be
changed to any position you like.
Seat Belt
Always fasten the seat belt before starting.
Flip-up Armrest
The armrest is used by tilting it forward.
Pocket
A storage pocket is located at the rear of the
seat. This is the recommended storage area for
the operator’s Manual.
SECTION 2
OPERATION
CONTROLS AND INSTRUMENTS
Flip-uparmrest
SeatBelt
SeatTravelLever
Flotationadjusterknob
RecliningLever
Pocket
