7.2 Adjusting the angle of the drill stand with AB52
CAUTION
 Before tilting the column, ensure that the drill stand is firmly fastened by an anchor bolt to
the material to be drilled, and the drill motor with the carriage block is removed from the
column.
 Take care not to pinch fingers between the column and the base.
 Wear protective gloves.
NOTE
The angle scale indicates approximate angle degrees. If higher precision is required, alternative
measuring method should be used.
Follow the procedure below.
1) Loosen and remove hex. bolt (M12x70) which fixes the column to the base on the front side of the
base. Also, remove the spring washers (2-12). Keep them for the future use.
2) Loosen 2 pieces of hex. bolts (M12x90) on the side of the column so that the column tilts.
3) Tilt the column to a desired angle.
4) Tighten 2 pieces of the hex. bolts (M12x90) on the side of the column. The tightening torque is 60
Nm (44 lbf・ft) each.
5) When using it as a fixed drill stand, ensure to re-attach hex. bolt (M12x70) and spring washers
(2-12) and tighten the bolt. The tightening torque is 60 Nm (44 lbf・ft).
7.3 Mounting the drill motor with the carriage block on the drill stand
WARNING
Make sure the drill motor is switched off and disconnected from the power supply.
7.3.1 Attaching the quick release handle to the carriage block
CAUTION
Take care not to pinch fingers between the retainer and the quick release handle (feed handle).
Follow the procedure below.
1) Attach the quick release handle (feed handle) to either left or right side of the carriage block.
2) Insert the retainer (pin) to fix the quick release handle to the carriage block.
Make sure that the handle is firmly-fastened.
7.3.2 Attaching the drill motor with the carriage block to the drill stand
CAUTION
 Take care not to pinch fingers between the carriage block and the column when mounting
the motor.
 Hold the motor tightly with both hands as below when mounting the motor on the drill
stand.
 The quick release handle (feed handle) starts turning once the pinion gear of the carriage
block and the rack gear of the column are engaged. Take care not to hit the handle against
your body when the carriage block is sliding.
 Tighten the stopper-knob (carriage brake) to prevent unintentional sliding down of the
carriage block.
Follow the procedure below.
1) Loosen the stopper-knob.
2) Mount the drill motor with the carriage block on the drill stand.
3) Turn the quick release handle to feed the drill motor to a suitable position.
4) Tighten the stopper-knob.
