1.5. PLC configuration
1.5.1 SA3 PLC specifications
Item
SA3 PLC function specifications
Control method
Repeated operation
I/O control mode
Refresh input and output
Programming language
Relay symbolic language (ladder)
Function block
No. of instructions
Basic instructions
21
Application instructions
12
Processing speed
Basic instructions
Several us
Application instructions
Dozens us
Program capacity
400 (0 to 399 steps)
Number of analog I/O points
3 input points built-in (Terminals 2, 3 and 4)
2 output points (AM1 and AM2)
High-speed pulse input function
HDI High-speed input count
I/O configuration
InputX
22 pointsX0~X25octal
OutputY
20 pointsY0~Y23octal
Auxiliary relay M(coil)
General
160 points M0~M159
Power off keep
80 points M160~M239
Special
80 points M8000~M8079
TimerT
100ms
8 pointsT0~T7, range0~6553.5s
CounterC
Up-counter
8 pointsC0~C7, range0~65535
Data registerD
General
32 pointsD0~D31
Power off keep
16 pointsD32~D47
Parameter
1300 pointsD1000~D2299
Special
162 pointsD8000~D8161
ConstantK
0~65535
