1.4.4 Clear PLC internal storage
 Erase PLC program
When the value of P.782 is written as 1, the inverter will clear the PLC program. After the clear is successful,
the value of P.782 will be restored to 0, and the value of P.782 will not be restored to 0 if the clearing fails.
The clearing procedure must be in the STOP state of the PLC, otherwise the clearing will fail.
 Erase power off keep part of the memory
When the special M relay M8032 is ON, the storage content of the latched area is cleared.
1.4.5 PLC component monitoring
P.783 selects the type of monitoring element, P.784 is the status of the current monitoring element.
P.783
P.784
P.783
P.784
1
X0~X17(Name is octal)
20
T0~T7（Bit）
2
X20~X25(Name is octal)
21
C0~C7（Bit）
3
Y0~Y17(Name is octal)
22
M8000~M8015
4
Y20~Y23(Name is octal)
23
M8016~M8031
5
M0~M15
24
M8032~M8047
6
M16~M31
25
M8048~M8063
7
M32~M47
26
M8064~M8079
8
M48~M63
27~52
reserved
9
M64~M79
53~60
T0~T7 value（word）
10
M80~M95
61~68
reserved
11
M96~M111
69~76
C0~C7 value
12
M112~M127
77~84
reserved
13
M128~M143
85~92
T0~T7 value（word）
14
M144~M159
93~100
reserved
15
M160~M175
101~108
C0~C7 value（word）
16
M176~M191
109~116
reserved
17
M192~M207
117~164
D0~D47
18
M208~M223
165~326
D8000~D8161
19
M224~M239
For example, when P.783 = 5, P.784 = 4241, converted to binary is 0001000010010001, 16-bit bit from low
to high corresponds to the state of M0~M15, 1 is ON, 0 is OFF. Therefore, it can be seen that M0, M4, M7, and
M12 are in the ON state, and the others are in the OFF state.
