Shihlin electric SF3 Series User Manual

2.2 Function instruction
Detailed function instructions
Classification
FNC NO.( Decimal)
Instruction Symbol
Function Description
Number of parameters
Transmission
comparison
10
CMP
compare
3
11
ZCP
Interval comparison
4
12
MOV
Send
2
15
BMOV
Batch send
3
Arithmetic
operation
20
ADD
Binary addition operation
3
21
SUB
Binary subtraction operation
3
22
MUL
Binary multiplication
3
23
DIV
Binary division operation
3
24
INC
Binary plus 1 operation
1
25
DEC
Binary minus 1 operation
1
Rotation and
shift
30
ROR
Rotate right
2
31
ROL
Rotate left
2
X
Y
M
K
T
C
D
S1
O
O
O
O
S2
O
O
O
O
D
O
O
Flag bit: none
Source operand
S1
：The comparison value is 1. Source operand
S2
：The comparison value is 2. Source operand
D
：Comparing results.
Show the comparison result of
S1
S2
through
D
.
The numbers to be compared are all unsigned 16-bit binary numbers.
If the target points to M0, it will automatically occupy M0~M2.
CMP instruction is executed when X0 is ON. CMP is not executed when X0 is OFF, and the state remains as before X0 is
OFF.
