1.5.8 Analog output
P.54 is set to 13, the output of AM1-5 is controlled by PLC. M8049 ON AM1-5 output starts. OFF output stops.
P.64 controls the signal type (voltage or current and range) output by AM1-5, switch SW3 is set to output voltage
from AM1-5, and switch SW3 is set to output current from AM1-5.
D8045 is used to set the percentage of AM1-5 output signal (the minimum unit is 0.1%, the range is 0~100%, the
range corresponding to the percentage is set by P.64.)
P.537 is set to 13, the output of AM2-5 is controlled by PLC. M8049 ON AM2-5 output starts. OFF output stops.
P.538 controls the type of AM2-5 output signal (voltage or current and range). Switch SW4 dials AM2-5 to output
voltage, switch SW4 dials AM2-5 to output current.
D8046 is used to set the percentage of AM2-5 output signal (the minimum unit is 0.1%, the range is 0~100%, the
range corresponding to the percentage is set by P.538).
Note: 1. SA3 and SF3 have two output terminals, namely AM1-5, AM2-5, SE3 has only one analog output, that is,
AM-5 usage and parameter settings are the same as AM1-5.
