Shihlin electric SF3 Series User Manual

X0 is ON, the number in D0 is subtracted from the data in D10, and the difference is stored in D20. If the difference
obtained is zero, M8020 will be set to 1.
X
Y
M
K
T
C
D
S1
O
O
O
O
S2
O
O
O
O
D
O
O
O
Flag bit: None.
S1
: The multiplicand.
S2
: Multiplier.
D
: Product.
Store the product obtained by multiplying
S1
and
S2
in
D
. The data involved in the operation are all
unsigned 16-bit binary numbers.
X0 ON, the data in D0 is multiplied by the data in D10, and the product is sent to D20 for storage.
X
Y
M
K
T
C
D
S1
O
O
O
O
S2
O
O
O
O
D
O
O
O
Flag bit: M8023 0: The divisor is not 0.
1: The divisor is 0.
X0
SUB D0 D10 D20
X0
MUL D0 D10 D20
