Component Where to use Tool
Crank arm
Cap
TL-FC16/TL-FC18
Stopper plate
5mm hexagon wrench
Chain device
Guide fixing bolt (M5)
4mm hexagon wrench
Back plate fixing bolt (M6)
3mm hexagon wrench
Front chainring Lock ring
TL-FC39+TL-FC36
LIST OF TOOLS
The following tools are needed for installation, adjustment, and maintenance purposes.
Component Where to use Tool
Cycle computers Clamp bolt 3mm hexagon wrench
Assist switch
Unit fixing bolt
3mm hexagon wrench
Lever fixing bolt
2mm hexagon wrench
Electric wire Connector
TL-EW02
Battery mount
(BM-E8010)
Mount lower case
3mm hexagon wrench / 8mm spanner
Key unit
3mm hexagon wrench
Key unit cover
2.5mm hexagon wrench
Mount upper case
2.5mm hexagon wrench
Battery mount
(BM-E8020)
Mount lower case
5mm hexagon wrench
Mount upper case
Screwdriver [#2]
Key cylinder
2mm hexagon wrench
Key unit
5mm hexagon wrench
Key unit cover
Screwdriver [#2]
Speed sensor
(SM-DUE10)
Speed sensor fixing bolt
4mm hexagon wrench
Speed sensor
(SM-DUE11)
Speed sensor fixing bolt
HEXALOBULAR [#10]
Magnet unit Fixing bolt
Screwdriver [#2]
Light cable Mounting bolt
Screwdriver [#2]
Drive unit
Drive unit fixing bolt (M8) - -
Cover fixing bolt (M3)
Screwdriver [#2]
