E8000 Series
E6000 MANUALE8000 CONCEPT E8000 MANUAL E6000 CONCEPT
BT-E8020
Battery
BM-E8020
Battery Mount
Battery / Battery Mount
BT-E8020 Batter
y
BM-E8020 Batter
y
Mount
SHIMANO
CODE NO.
DESCRIPTION
1
Y72V00007
CG PORT CAP
2
Y72V00008
FRAME CG PORT CAP
3
Y72V00006
M2.6 BOLT CG PORT
4
Y72W00002
M4 BOLT KEY UNIT
5
Y72W00001
RATCHET ASSY
6
Y72W00004
RUBBER M8 FIXING
7
Y72W00003
M8 BOLT RATCHET
8
Y72W00014
RAIL ASSY
9
Y72W00015
KEY CAP
10
Y72W00006
M3 BOLT
Y72W00009
CONNECTOR ASSY 250
Y72W00013
CONNECTOR ASSY 400
12
Y72W00011
M8 BOLT LOWER FRAME
13
Y72W00008
HOLDER FRAME ASSY
Mar.-2017-4156
© Shimano Inc. I
Specifications are subject to change without notice.
ITEM
NO.
11
1
2
3
3
3
4 4
6
6
5
7
7
9
8
11
12
12
13
BM-E8020
BT-E8020
10
10
10
10
ITEM
NO.
SHIMANO
CODE NO.
DESCRIPTION
1 Y72V00007 CG PORT CAP
2 Y72V00008 FRAME CG PORT CAP
3
Y72V00006 M2.6 BOLT CG PORT
4
Y72W00002 M4 BOLT KEY UNIT
5
Y72W00001 RATCHET ASSY
6 Y72W00004 RUBBER M8 FIXING
7
Y72W00003 M8 BOLT RATCHET
8 Y72W00014 RAIL ASSY
9 Y72W00015 KEY CAP
10 Y72W00006 M3 BOLT
11
Y72W00009 CONNECTOR ASSY 250
Y72W00013 CONNECTOR ASSY 400
12 Y72W00011 M8 BOLT LOW ER FRAME
13 Y72W00008 HOLDER FRAME ASSY
Mar.-2017-4156
© Shimano Inc. I
BM-E8010
Battery Mount
Battery Mount
BM-E8010
SHIMANO
CODE NO.
DESCRIPTION
1 Y72U00003 M4 BOLT KEY COVER
2 Y72U00008 KEY UNIT COVER ASSY
3 Y72U00001 M5 BOLT KEY UNIT
4 Y72U00007 SPACER KEY UNIT
5 Y72U00004 M3 BOLT LOWER CASE
Y72U00015 UPPER CASE ASSY 250
Y72U00014 UPPER CASE ASSY 300
Y72U00017 UPPER CASE ASSY 600
7 Y72U00005 M5 BOLT LOWER CASE F
8 Y72U00006 M5 BOLT LOWER CASE R
9 Y72U00010 SPACER LOWER CASE
10 Y72U00011 RUBBER LOWER CASE
11 Y72U00012 LOWER CASE ASSY
Mar.-2017-4043
© Shimano Inc. I
Specifications are subject to change without notice.
ITEM
NO.
6
1
1
3
2
4
3
4
9
8
7
5
5
5
5
6
10
11
ITEM
NO.
SHIMANO
CODE NO.
DESCRIPTION
1 Y72U00003 M4 BOLT KEY COVER
2 Y72U00008 KEY UNIT COVER ASSY
3 Y72U00001 M5 BOLT KEY UNIT
4 Y72U00007 SPACER KEY UNIT
5 Y72U00004 M3 BOLT LOWER CASE
6
Y72U00015 UPPER CASE ASSY 250
Y72U00014 UPPER CASE ASSY 300
Y72U00017 UPPER CASE ASSY 600
7 Y72U00005 M5 BOLT LOWER CASE F
8 Y72U00006 M5 BOLT LOWER CASE R
9 Y72U00010 SPACER LOWER CASE
10 Y72U00011 RUBBER LOWER CASE
11 Y72U00012 LOWER CASE ASSY
Mar.-2017-4043
© Shimano Inc. I
