Chain Pin
For 11-speed chain
(with sharp nose)
3 pcs. Y0AH98030
50 pcs.
Y0AH98010
For 10-speed chain
(except CN-7800,
with two lines)
3 pcs. Y08X98031
50 pcs.
Y08X98021
QUICK-LINK
For 11-speed chain QUICK-LINK
SM-CN900-11 single use, 2 pairs
ISMCN90011A
For 11-speed chain QUICK-LINK
SM-CN900-11 single use, 50 pairs
work shop jar
ISMCN90011BS
Others (Common with E6000 Series )
Model
Number
Description Code. No
EW-SD50
E-TUBE electric wire black
(1600mm) for connecting cycle
computer (SC) and drive unit (DU)
IEWSD50L160
E-TUBE electric wire black
(550mm) for connecting drive unit
(DU) and motor unit (MU) for DI2
shifting
IEWSD50L55
EW-SD50-I
Wire holder (cable-tie) for electric
wire EW-SD50 for internal routing.
1unit = 20pcs
IEWSD50ISM1
TL-EW02
Plug tool for connection and
disconnection of E-TUBE electric
wires
Y6VE16000
1 3
Systemkontrolle, PC-Link-Kabel (x2) 2m, USB-Kabel (x1) 50cm : SM-PCE1 (ISMPCE1)
Elektrische Kabel : EW-SD50 L=1400mm (IEWSD50L140)
Mehrfachsteckplatz (B) : SM-JC41 (ISMJC41)
Kabelwerkzeug : TL-EW02 (Y6VE16000)
1
2
3
4
2
4
E-TUBE ANSCHLUSS- UND EINSTELL-KIT
Case kit
E-TUBE PROJECT connecting &
setting device case kit
including:
- SM-PCE1 (PC linkage device with
USB cable)
- EW-SD50 (electric wire 1400mm)
- SM-JC41 (Junction B)
- TL-EW02 (Plug tool)
IETUBEKIT2E
Assist Switch / Shift Switch
Model
Number
Description Code. No
SW-E8000-L
Switch unit (left) for power mode
change clamp band type
ISWE8000L
Chain (Common with E6000 Series )
Model
Number
Description Code. No
CN-HG701-11
11 speed chain (HG-X11) 1pcs SIL-TECH
surface treatment (outer/inner link plate)
116 links QUICK-LINK (SM-CN900-11)
ICNHG70111116Q
11 speed chain (HG-X11) 1pcs SILTECH
surface treatment 138 links
QUICK-LINK (SM-CN900-11)
ICNHG70111138Q
CN-HG601-11
11 speed chain (HG-X11) 1pcs SIL-TECH
surface treatment (inner link plate) 116
links QUICK-LINK (SM-CN900-11)
ICNHG60111116Q
11 speed chain (HG-X11) 1pcs SIL-TECH
surface treatment (inner link plate)
138 links QUICK-LINK (SM-CN900-11)
ICNHG60111138Q
11 speed chain (HG-X11) 20pcs SILTECH
surface treatment (inner link
plate) Work shop package 138 links
QUICK-LINK (SM-CN900-11)
ICNHG60111116QS
CN-E6090-10
10 speed chain (HG-X) 1pcs
118 links front single only two lines
connecting pin
ICNE609010118I
10 speed chain (HG-X) 1pcs
138 links front single only two lines
connecting pin
ICNE609010138I
10 speed chain (HG-X) 20pcs Work
Shop package 118 links front single
only two lines connecting pin
ICNE609010118IS
TL-CN28
Chain tool for cutting and
connecting SHIMANO 6-11speed
chain
Y13098500
TL-CN10
Chain tool for connecting and
removing SHIMANO QUICK-LINK
Y13022000
