Shimano Steps SC-E5000 User Manual

16
Installation/removal
Electric wires
2. Insert the plug on the electric wire into the E-TUBE port.
Push it straight in until you feel it click into place.
E-TUBE port
Plug
` Removing the electric wire (EW-SD50)
1. Remove the electric wire.
(1) Insert the TL-EW02 into the groove on the plug of the electric wire.
(2) Disconnect the electric wire from the E-TUBE port.
* As shown in the figure, use part (A) of the TL-EW02 as a fulcrum, move the tool like a
lever, then disconnect the plug part. If there is limited space to insert the tool, lift the
TL-EW02 straight up and disconnect the electric wire.
(1) (2)
(A)
